IM001A ifm Electronic Electronic Components

Name: IM001A
Brand: ifm Electronic

Part#:IM001A

Category:Electronic Components

Product Lifecycle:Active

Product description

Inductive sensor, For applications in hazardous areas, Output function: normally open / closed; (selectable), Sensing range [mm]: 20, Housing: rectangular, Dimensions [mm]: 40 x 40 x 105

Product Details

Overload protection
no
Short-circuit proof
no
Notes on switching frequency
only for resistive loads; 2 Hz for utilization category AC-140
Short-time current rating of switching output [mA]
2200; (20 ms / 0,5 Hz)
Switching frequency DC [Hz]
10
Switching frequency AC [Hz]
10
Permanent current rating of switching output DC [mA]
100
Max. leakage current [mA]
2.5 (250 V AC) / 1.3 (130 V AC) / 0.8 (24 V DC)
Max. voltage drop switching output AC [V]
6.5
Minimum load current [mA]
5
Permanent current rating of switching output AC [mA]
150
Operating voltage [V]
20...250 AC/DC
Sensing range [mm]
20
Protection class
II
Max. voltage drop switching output DC [V]
6
Reverse polarity protection
no
Housing
rectangular
Dimensions [mm]
40 x 40 x 105
Output function
normally open / closed; (selectable)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

IM001A Related Documents

PDF data sheet-1631071498193.pdf CAD_DXF_100_0695.ZIP-1631071498186.zip CAD_SAT_100_0695.ZIP-1631071498185.zip CAD_STP_100_0695.ZIP-1631071498183.zip CAD_DWG_100_0695.ZIP-1631071498181.zip

Manufacturer warranty
