CQF-05 Mencom Electronic Components

Mencom CQF-05 Standard, CQ series, Female Rectangular Insert, size 21.21, 5 pin, 16 amp, Crimp
Mencom

Part#:CQF-05

Manufacturer:Mencom

Product Lifecycle:Active

In-stock parts: 9

Sep 19, 2024

Standard, CQ series, Female Rectangular Insert, size 21.21, 5 pin, 16 amp, Crimp

About the manufacturer: Mencom is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. Since 1987, Mencom Corporation has been your go-to source for affordable industrial electrical connector solutions. Count on our experienced team to deliver top-quality products with unwavering dedication.

Check out the CQF-05 Mencom price in the box on the right side or send a quick quote.

Product Details

  • Weight (lbs.)
    0.031000
  • Temperature Range in Degrees Celsius
    -40 C to +125 C
  • Lower AWG
    20
  • Termination
    Crimp
  • Upper AWG
    12
  • Cover
    No
  • Gender
    Female
  • Amperage Rating
    16
  • Voltage Rating
    600
  • Insert Dimension
    21.21
  • Gasket/O-Ring
    No
  • Pin Count
    5
  • Housing/Insert Type
    Standard
  • Number of Entries
    0
  • Product Type
    Rectangular Connectors
  • Enclosure Dimension
    21.21
  • ILME Series
    CQ
  • Component Type
    Insert

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents CQF-05 Specs

CQF-05 CQF-05.PDF.pdf
CQF-05 CQF-05.ZIP.zip
CQF-05 CQF-05.DWG.dwg
CQF-05 CQF-05.DXF.dxf
CQF-05 186.pdf.pdf

This item can ship within 24h!

Manufacturer warranty

$6.56

Stock:

9

Select Qty:

$6.56

$6.56 each
