AC/DC Power Supplies
AC/DC power supplies are power supplies that convert alternating current from the grid into direct current that is needed to power most electronics. AC/DC power supplies are integral components in systems that make the world go round.
PULS XT40.241 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x360-440Vac (380Vac / 400Vac / 415Vac nominal; 47-63Hz), with a turn-ON voltage of 3 x 325Vac and a shutdown voltage of 3 x 295Vac. The unit's dimensions are W96mm x H124mm x D159mm, and it is encased in an aluminium housing with screw-clamp connections for installation. It has a rated current of 40A at 24Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.241 has a net width of 96 mm and a peak current consumption of 4A max. inrush at 3x400Vac input. Its rated power is 24W/+60°C...+70°C (derating) 960W at 24Vdc and 1200W for a typical 15s. Protection functions include output overvoltage protection (29.9Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It supports 1+1 redundancy for higher system availability and is resistant to back-feeding loads up to 28.9V. The efficiency is rated at 0.955 with a 3x400Vac input, and it features a 400ms start-up delay, 40ms rise time with nominal input at constant full current load without load capacitance, and 70ms with 40mF load capacitance. The output voltage is fixed at 24Vdc with a 480mV turn-ON overshoot, and it has a 2ms buffer time at 3x400Vdc input. Power dissipation/losses are 45.2 W at full output load with 3x400Vdc input. Electrical durability is rated at 51000 hours at 40°C and 142000 hours at 25°C, with a 40A output and 3AC 400Vdc input. The output stage capacitance is 20000 µF, and the ripple is 1500mVpp (20Hz...2KHz; 50Ω).
Quick Quote
PULS XT40.361 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates with a supply voltage of 3x360-440Vac (380Vac / 400Vac / 415Vac nominal; 47-63Hz), a turn-ON voltage of 3 x 325Vac, and a shutdown voltage of 3 x 295Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and features screw-clamp connections for installation. It is designed for DIN rail mounting in a 3-phase (3AC) network environment. The XT40.361 operates efficiently within an ambient air temperature range of -25 to +70°C, has a net width of 96 mm, and a peak inrush current consumption of 4A (at 3x400Vac input). It offers a rated current of 26.6A (at 36Vdc), with a rated power of 960W (at 36 Vdc) and 1200W for a typical 15s, adjusting to 24W/+60°C...+70°C (derating). Protection features include output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection—typically 115A at load impedance. The unit is not designed for series or parallel operation to increase output power but supports 1+1 redundancy for higher system availability. It can handle back-feeding loads up to 41.1V without malfunctioning. The XT40.361 boasts an efficiency of 0.955 (with 3x400Vac input), a 400ms start-up delay, and a rise time of 40ms (nominal input; constant full current load; 0mF load capacitance) to 70ms (nominal input; constant full current load; 27mF load capacitance). The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, and it offers a hold time of 2.6ms (buffer time at 3x400Vdc input). Power dissipation/losses are calculated at 45.2 W (3x400Vdc input; full output load), and the electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 400Vdc input) to 156000 hours (at 25°C; 26.6A output; 3AC 400Vdc input). The output stage capacitance is 11100 µF, with a ripple of 2000mVpp (20Hz...2KHz; 50Ω).
Quick Quote
PULS XT40.722 is a power supply unit part of the X-series, designed to function as an AC/DC PSU/converter with a semi-regulated 25% power reserve and a DC-OK relay contact output. It operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit's dimensions are W96mm x H124mm x D159mm, and it is encased in an aluminium housing with screw-clamp connections for installation. It has a rated current of 13.3A at 72Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.722 has a net width of 96 mm and a peak current consumption of 4A max. inrush at 3x480Vac input. Its rated power is 24W/+60°C...+70°C (derating) 960W at 72Vdc and 1200W for a typical 15s, with protection functions including output overvoltage protection (91.1Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not designed for series or parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 87.9V. It has an efficiency of 0.955 at 3x480Vac input, with a 350ms start-up delay, 40ms rise time at nominal input and full current load without load capacitance, and 70ms with 13.3mF load capacitance. The output voltage is fixed at 72Vdc with a 1.4V turn-ON overshoot, a hold time of 3.6ms at 3x480Vdc input, power dissipation/losses of 45.2W at full output load, an output stage capacitance of 4050µF, and a ripple of 3000mVpp at 20Hz...2KHz with a 50Ω load.
Quick Quote
PULS CS10.243 is a DIN rail mounting power supply unit with an aluminium housing designed for a single-phase network. It operates within an ambient air temperature range of 0 to +70°C and has a net width of 60mm. The unit consumes 3.71A with a 120Vac input and 4.32A with a 100Vac input for a full 24Vdc output, featuring a peak inrush current of 108A at 120Vac input and 90A at 100Vac input. It offers an efficiency of 0.913 at 120Vac input and 0.91 at 100Vac input. The dimensions are W60mm x H124mm x D117mm. It includes a 250ms start-up delay for 100-120Vac input, with a rise time of 35ms under nominal input at constant full current load with 0mF load capacitance and 75ms with 10mF load capacitance. The power supply unit is equipped with protection functions including output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. It supports series/parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 22.9W at 120Vac input with full output load, and the output stage capacitance is 7000µF. Electrical durability ranges from 27,000 to 281,000 hours depending on conditions. Ripple is maintained at 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the C-Line series, features a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage of 90Vac-132Vac (47-63Hz) with a turn-ON voltage of 82Vac and a shutdown voltage of 78Vac in steady-state. The rated current is 12A at 24Vdc for ambient temperatures less than 45°C and 10A at 24Vdc for less than 60°C, with an adjustable output voltage of 24Vdc-28Vdc. The hold time is 46ms at 120Vac input.
Quick Quote
PULS CS5.243 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for a single-phase network. It operates within an ambient air temperature range of -10 to +70°C and has a net width of 32mm. The unit consumes 1.88A with a 120Vac input and 2.23A with a 100Vac input for a full 24Vdc output, featuring a peak inrush current of 56A at 120Vac and 47A at 100Vac. It boasts an efficiency of 0.9 at 120Vac input and 0.895 at 100Vac input. The dimensions are W32mm x H124mm x D117mm. It has a 120ms start-up delay and a rise time of 8ms under nominal input with a constant full current load without load capacitance, and 25ms with 5mF load capacitance. The CS5.243 includes protection functions such as output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. It supports series or parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation is 13.5W at full output load with a 120Vac input, and the output stage capacitance is 1800µF. Its electrical durability ranges from 27,000 to 363,000 hours depending on the conditions. The ripple is 50mVpp, and it features a 20% power reserve. Part of the C-Line series, it includes a DC-OK relay contact output and screw-clamp connections. The supply voltage ranges from 90Vac to 132Vac, with a rated current of 6A at 24Vdc under 45°C and a rated power of 144W under 45°C. The output voltage is adjustable between 24Vdc and 28Vdc, with a 400mV turn-ON overshoot and a hold time of 78ms at 120Vac input.
Quick Quote
PULS PIM60.245 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The design includes a NEC Class 2 DC-OK relay contact output. It provides a rated current of 5A at 12Vdc from -10 to +60°C and 3.8A at 12Vdc at +70°C, utilizing screw-clamp connections. The supply voltage (AC) ranges from 90Vac to 264Vac for various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. Part of the PIM-series, it measures W36mm x H90mm x D91mm and has an IP20 degree of protection with a polycarbonate (PC) housing. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable DC output voltage of 12Vdc to 15Vdc. Protection functions include output overvoltage and overload/short-circuit current protection, with specific resistance and current values provided. The unit is resistant to back-feeding loads up to 16V. Efficiency rates are noted for 230Vac and 120Vac inputs, alongside current consumption details for various input voltages and inrush current peaks. Time delay for start-up and rise, hold time, power dissipation/losses, and electrical durability at different conditions and temperatures are specified. Ripple and capacitance values are also provided, highlighting the unit's electrical characteristics.
Quick Quote
PULS CP10.241-R2 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 39mm. The unit consumes current differently based on the input, including 1.14A with 230Vac input, 2.17A with 120Vac input, 2.63A with 100Vac input, and 2.35A with 110Vdc input, all at full output. It features a peak inrush current of 11A at 230Vac input and 7A at 120Vac input. With an IP20 degree of protection, the efficiency rates are 0.947 at 230Vac input and 0.93 at 120Vac input. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms and rise times of 30ms and 75ms under specified conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or redundancy. The power dissipation/losses are 13.4W and 18.1W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 4400µF. Electrical durability varies with conditions, offering up to 531000 hours at 25°C with 5A output and 1AC 230Vac input. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the CP-series, is designed with a built-in decoupling MOSFET for 1+1 or N+1 redundancy and includes a 20% power reserve. It features DC-OK relay contact output and hot-swappable connectors. The supply voltage ranges from 88Vdc to 180Vdc for DC and 85Vac to 264Vac for AC, with specific tolerances for overvoltage and shutdown voltages. The rated current is 12A at 48Vdc up to +45°C, decreasing at higher temperatures. It supports single-phase (1AC) or DC networks and provides a rated power of 288W at -25 to +45°C, with linear derating up to +70°C. The output voltage is adjustable from 24Vdc to 25.4Vdc, with a 200mV turn-ON overshoot and a hold time of 37ms at 120/230Vac input.
Quick Quote
PULS CP10.241-R2-C1 is a power supply unit designed for DIN rail mounting with an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C. The unit has a net width of 39 mm and features current consumption rates of 1.14A with a 230Vac input, 2.17A with a 120Vac input, 2.63A with a 100Vac input, and 2.35A with a 110Vdc input, all at full output. It offers a peak max. inrush of 11A at 230Vac input and 7A at 120Vac input. With an IP20 degree of protection and an efficiency of 0.947 at 230Vac input, this power supply unit is also chemically resistant with a conformal coated PCB. Its dimensions are W39mm x H124mm x D117mm. The time delay for start-up is 240-300ms for 100-230Vac input, with a rise time of 30ms at nominal input for a full constant current load without load capacitance and 75ms with 2mF load capacitance. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation for increased output voltages or redundancy. The unit is resistant to back-feeding loads up to 35V. Power dissipation/losses are 13.4 W at 230Vac input and 18.1 W at 120Vac input, with an output stage capacitance of 4400 µF. Electrical durability ranges from 47,000 to 531,000 hours depending on conditions. The ripple is 50mVpp. This AC/DC power supply unit is part of the CP-series and is designed with built-in decoupling MOSFET for 1+1 or N+1 redundancy, hot-swappable connectors, conformal coating, and a 20% power reserve. It features a DC-OK relay contact output and supports a supply voltage range of 88Vdc-180Vdc for DC and 85Vac-264Vac for AC, with a rated current of 12A at 48Vdc up to +45°C. The rated power is 288W up to +45°C, and the output voltage is adjustable between 24Vdc and 25.4Vdc. The hold time is 37ms at 120/230Vac input.
Quick Quote
PULS CP20.241-R2-C1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -40 to +70°C and has a net width of 48 mm. The unit consumes current differently based on the input, including 2.25A with 230Vac input, 4.28A with 120Vac input, 5.17A with 100Vac input, and 4.64A with 110Vdc input for a 24Vdc / 10A output, with peak inrush currents of 5.5A and 12A for 230Vac and 120Vac inputs respectively. It features an IP20 degree of protection and achieves efficiencies of 0.952 and 0.938 with 230Vac and 120Vac inputs, respectively. The power supply is resistant to harsh environments, thanks to its conformal coated PCB, and has dimensions of W48mm x H124mm x D127mm. It includes a 450ms start-up delay and rise times of 145ms and 160ms under specified conditions. Protection functions include output overvoltage protection and overload/short-circuit protection, with capabilities for series/parallel operation and resistance to back-feeding loads up to 35V. Power dissipation losses are 24.2W and 31.7W for 230Vac and 120Vac inputs, respectively, with an output stage capacitance of 8000 µF. Electrical durability varies with conditions, offering up to 465,000 hours at 25°C with a 10A output and 1AC 230Vac input. The ripple is specified as 100mVpp. This AC/DC power supply unit, part of the CP-series, is designed with built-in decoupling MOSFET for redundancy, hot-swappable connectors, ATEX approval, and a 20% power reserve. It supports a supply voltage range of 88Vdc-180Vdc for DC and 85Vac-264Vac for AC, with specific shutdown and turn-on voltages. The rated current is 24A at 48Vdc in temperatures up to +45°C, with derating at higher temperatures. It provides a fixed 24Vdc output voltage and includes a 32ms hold time at standard AC inputs.
Quick Quote
PULS CP20.481 is a power supply unit designed for DIN rail mounting with an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 48mm. The unit features a current consumption of 5.5A peak max. inrush at 230Vac input and 12A peak max. inrush at 120Vac input. Its efficiency rates are 0.963 at 230Vac input, 0.95 at 120Vac input, and 0.944 at 100Vac input. The dimensions of the CP20.481 are W48mm x H124mm x D127mm. It has a 450ms start-up delay and a rise time of 120ms under nominal input with a constant full current load and 0mF load capacitance, and 170ms with 10mF load capacitance. The unit includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 63V. Power dissipation/losses are 18.4W at 230Vac input and 25.1W at 120Vac input with full output load. The output stage capacitance is 2500µF. Electrical durability varies with conditions, reaching up to 509000 hours at 25°C and 5A output with 1AC 230Vac input. The ripple is 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit offers a 20% power reserve and includes a DC-OK relay contact output. It features screw-clamp connections and supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 10A at 48Vdc, and a rated power of 480W. The output voltage is adjustable between 48Vdc and 56Vdc, with a 500mV turn-ON overshoot and a hold time of 32ms at 120/230Vac input. It is suitable for single-phase (1AC) or DC networks.
Quick Quote
