AC/DC Power Supplies
AC/DC power supplies are power supplies that convert alternating current from the grid into direct current that is needed to power most electronics. AC/DC power supplies are integral components in systems that make the world go round.
PULS CPS20.121 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and supports a net width of 65 mm. The unit consumes 1.8A, 3.3A, and 4A under 230Vac, 120Vac, and 100Vac input conditions respectively, with a peak inrush current of 13A at both 230Vac and 120Vac inputs. It boasts an efficiency of up to 0.926, 0.914, and 0.909 under 230Vac, 120Vac, and 100Vac inputs respectively. The dimensions are W65mm x H124mm x D127mm. It features a start-up delay of 700-900ms and rise times of 72ms and 120ms under nominal input conditions. The CPS20.121 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation to increase output power. It is designed to handle back-feeding loads up to 16V without malfunctioning. Power dissipation/losses are calculated at 28.8 W, with an output stage capacitance of 5600 µF. Its electrical durability ranges from 50,000 to 492,000 hours, depending on operating conditions. The ripple is maintained at 100mVpp. This AC/DC power supply unit offers a 20% power reserve, is part of the C-series, and includes ATEX approval, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage range of 85Vac-264Vac, with specific shutdown voltages under varying loads. The rated current is 30A at 12Vdc, with a rated power of 405W at 15Vdc and 360W at 12Vdc. The output voltage is adjustable between 12Vdc and 15Vdc, featuring a 200mV turn-ON overshoot and a hold time of 35ms.
Quick Quote
PULS ML15.051 is a power supply unit (PSU) / converter designed for DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and adheres to NEC Class 2 design specifications. This unit provides a rated current of 3A at 5Vdc, with screw-clamp connections for secure installation. It supports a wide range of supply voltages from 85Vac to 264Vac (with specific nominal values listed) at 47-63Hz, featuring a 59Vac turn-ON voltage and a 54Vac shutdown voltage. Additionally, it accepts DC supply voltages between 88Vdc and 375Vdc. The ML15.051 is housed in a PC / ABS blend, measuring 22.5mm in width, 75mm in height, and 91mm in depth. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 15W and an adjustable output voltage range of 5Vdc to 5.5Vdc. The unit includes an NTC for input inrush current limiting, achieves efficiencies of 0.772, 0.768, and 0.758 at 230Vac, 120Vac, and 100Vac inputs respectively, and has a current consumption with a peak max inrush of 16A at 120Vac input and 31A at 230Vac input. It features a 630ms start-up delay and a 10ms rise time at nominal input, with power dissipation/losses rated at 4.5W. The electrical durability of the ML15.051 is rated at a minimum of 93,000 hours at +40°C, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω, with an output stage capacitance of 4800µF.
Quick Quote
PULS CT5.241 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 40mm and dimensions of W40mm x H124mm x D117mm. The unit consumes 0.68A with a 480Vac input and 0.75A with a 400Vac input for a full 24Vdc output, with a peak inrush current of 10A at both 480Vac and 400Vac inputs. It boasts an efficiency of 0.9 at 480Vac input and 0.904 at 400Vac input. The CT5.241 offers a 75ms start-up delay and a rise time of 35-36ms under nominal input with a constant full current load and 0mF load capacitance, extending to 64-68ms with 5mF load capacitance. It includes protection functions such as output overvoltage protection and an active input inrush current limiter, with overload/short-circuit protection up to 13A continuous current. The unit supports series/parallel operation for increased output power and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 13.3W and 12.7W for 480Vac and 400Vac inputs, respectively, under full output load. The output stage capacitance is 3800µF, and the electrical durability ranges from 72,000 to 526,000 hours depending on the operating conditions. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter, part of the CT-series, is designed with a 20% power reserve and includes a DC-OK relay contact output. It features screw-clamp connections and accepts a wide range supply voltage of 323Vac-576Vac (2-phase input) with various shutdown voltages based on load conditions. The rated current is 6A at 24Vdc from -25 to +45°C and 3.75A at 24Vdc from -25 to +70°C, with a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a hold time of 60ms at 480Vac input and 40ms at 400Vac input.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| CPS20.121 PULS CPS20.121 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and supports a net width of 65 mm. The unit consumes 1.8A, 3.3A, and 4A under 230Vac, 120Vac, and 100Vac input conditions respectively, with a peak inrush current of 13A at both 230Vac and 120Vac inputs. It boasts an efficiency of up to 0.926, 0.914, and 0.909 under 230Vac, 120Vac, and 100Vac inputs respectively. The dimensions are W65mm x H124mm x D127mm. It features a start-up delay of 700-900ms and rise times of 72ms and 120ms under nominal input conditions. The CPS20.121 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation to increase output power. It is designed to handle back-feeding loads up to 16V without malfunctioning. Power dissipation/losses are calculated at 28.8 W, with an output stage capacitance of 5600 µF. Its electrical durability ranges from 50,000 to 492,000 hours, depending on operating conditions. The ripple is maintained at 100mVpp. This AC/DC power supply unit offers a 20% power reserve, is part of the C-series, and includes ATEX approval, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage range of 85Vac-264Vac, with specific shutdown voltages under varying loads. The rated current is 30A at 12Vdc, with a rated power of 405W at 15Vdc and 360W at 12Vdc. The output voltage is adjustable between 12Vdc and 15Vdc, featuring a 200mV turn-ON overshoot and a hold time of 35ms. | Puls | Quick Quote | ||
| ML15.051 PULS ML15.051 is a power supply unit (PSU) / converter designed for DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and adheres to NEC Class 2 design specifications. This unit provides a rated current of 3A at 5Vdc, with screw-clamp connections for secure installation. It supports a wide range of supply voltages from 85Vac to 264Vac (with specific nominal values listed) at 47-63Hz, featuring a 59Vac turn-ON voltage and a 54Vac shutdown voltage. Additionally, it accepts DC supply voltages between 88Vdc and 375Vdc. The ML15.051 is housed in a PC / ABS blend, measuring 22.5mm in width, 75mm in height, and 91mm in depth. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 15W and an adjustable output voltage range of 5Vdc to 5.5Vdc. The unit includes an NTC for input inrush current limiting, achieves efficiencies of 0.772, 0.768, and 0.758 at 230Vac, 120Vac, and 100Vac inputs respectively, and has a current consumption with a peak max inrush of 16A at 120Vac input and 31A at 230Vac input. It features a 630ms start-up delay and a 10ms rise time at nominal input, with power dissipation/losses rated at 4.5W. The electrical durability of the ML15.051 is rated at a minimum of 93,000 hours at +40°C, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω, with an output stage capacitance of 4800µF. | Puls | Quick Quote | ||
| CT5.241 PULS CT5.241 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 40mm and dimensions of W40mm x H124mm x D117mm. The unit consumes 0.68A with a 480Vac input and 0.75A with a 400Vac input for a full 24Vdc output, with a peak inrush current of 10A at both 480Vac and 400Vac inputs. It boasts an efficiency of 0.9 at 480Vac input and 0.904 at 400Vac input. The CT5.241 offers a 75ms start-up delay and a rise time of 35-36ms under nominal input with a constant full current load and 0mF load capacitance, extending to 64-68ms with 5mF load capacitance. It includes protection functions such as output overvoltage protection and an active input inrush current limiter, with overload/short-circuit protection up to 13A continuous current. The unit supports series/parallel operation for increased output power and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 13.3W and 12.7W for 480Vac and 400Vac inputs, respectively, under full output load. The output stage capacitance is 3800µF, and the electrical durability ranges from 72,000 to 526,000 hours depending on the operating conditions. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter, part of the CT-series, is designed with a 20% power reserve and includes a DC-OK relay contact output. It features screw-clamp connections and accepts a wide range supply voltage of 323Vac-576Vac (2-phase input) with various shutdown voltages based on load conditions. The rated current is 6A at 24Vdc from -25 to +45°C and 3.75A at 24Vdc from -25 to +70°C, with a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a hold time of 60ms at 480Vac input and 40ms at 400Vac input. | Puls | Quick Quote | ||
