AC/DC Power Supplies
AC/DC power supplies are power supplies that convert alternating current from the grid into direct current that is needed to power most electronics. AC/DC power supplies are integral components in systems that make the world go round.
PULS ML30.106 is a dual output voltage single-phase power supply unit (PSU) and AC/DC-Converter designed for DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is classified as NEC Class 2. This unit provides a rated current of 2.5A at 12Vdc with spring-clamp connections for ease of installation. It supports a wide supply voltage range from 85Vac to 264Vac (with nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz), featuring a 46Vac turn-ON voltage and a 44Vac shutdown voltage. Additionally, it can be powered by DC voltages ranging from 88Vdc to 375Vdc, with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc. The ML30.106 has dimensions of W45mm x H75mm x D91mm and is housed in a PC/ABS blend. It is suitable for single-phase (1AC) or DC networks, has a net width of 45 mm, and offers a rated power of 36W. The output voltage is symmetrical +/-12Vdc to +/-15Vdc, adjustable with a 250mV turn-ON overshoot. It features protection functions including NTC for input inrush current limiting, achieves an efficiency of 0.86 with a 230Vac input, and has a current consumption of 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. Power dissipation/losses are rated at 5.9 W, and it has a ripple of 50mVpp across 20Hz to 20MHz at 50Ω.
Quick Quote
PULS QS10.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 10A at 24Vdc and 9A at 28Vdc, with spring-clamp connections for secure installation. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, accommodating both single-phase AC or DC networks. The QS10.241 measures 60mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing for durability. It delivers a rated power of 240W at 24V and 252W at 28V, with a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, featuring comprehensive protection functions including overvoltage and overload/short-circuit protection. This unit is capable of series or parallel operation for increased output power, with an efficiency up to 93.5% depending on the input voltage. It has a peak current consumption of 10A, with specific start-up and rise times, and maintains power with a hold time of 28ms at 230Vac input. The QS10.241 is designed for electrical durability, offering up to 200,000 hours of operation at 25°C with a 10A output and 1AC 230Vac input, and features a ripple of 50mVpp at 20Hz to 20MHz with an output stage capacitance of 7000µF.
Quick Quote
PULS CP10.241-C1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 39mm. The unit consumes 1.13A at 230Vac input, 2.15A at 120Vac input, 2.6A at 100Vac input, and 2.35A at 110Vdc input for a 24Vdc / 10A output, with peak inrush currents of 11A at 230Vac input and 7A at 120Vac input. It offers an efficiency of 0.952 at 230Vac input and 0.936 at 120Vac input. The CP10.241-C1 features IP20 degree of protection and is resistant to harsh environments due to its conformal coated PCB. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms and a rise time of 30ms to 160ms depending on the load capacitance. It includes protection functions such as output overvoltage, overload/short-circuit, and over-temperature protection with automatic restart. The power supply supports series/parallel operation for increased output voltages or power, and 1+1 redundancy with a redundancy module. It can handle back-feeding loads up to 35V without malfunctioning. Power dissipation/losses are 12.1W at 230Vac input and 16.4W at 120Vac input, with an output stage capacitance of 4400µF. Electrical durability ranges from 39,000 to 499,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series, featuring ATEX approval, conformal coating, 20% power reserve, and a DC-OK relay contact output. It uses screw-clamp connections and accepts a supply voltage of 88Vdc-180Vdc or 85Vac-264Vac, with specific tolerances for overvoltage and shutdown voltages. The rated current is 12A at 48Vdc in temperatures up to +45°C, decreasing to 7.5A at 24Vdc at +70°C. It is suitable for single-phase (1AC) or DC networks, providing a rated power of 288W at -25 to +45°C, 240W at -25 to +60°C, and 180W at +70°C, with a linear derating between +60°C and +70°C. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 37ms at 120/230Vac input.
Quick Quote
PULS CS10.241-S1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and supports various current consumptions based on input voltage: 2.23A at 230Vac, 3.73A at 120Vac, and 4.34A at 100Vac, all for full 24Vdc output, with a peak inrush current of 10A across all input voltages. The unit boasts an efficiency of up to 0.916 at 230Vac input. Its dimensions are 60mm in width, 124mm in height, and 117mm in depth. The CS10.241-S1 features a start-up delay of 850ms and rise times of 35ms to 75ms depending on load capacitance. It includes protection functions such as output overvoltage protection and an active input inrush current limiter, alongside capabilities for series or parallel operation for redundancy. The power dissipation at full output load is 22W for 230Vac input and 23.7W for 120Vac input. The output stage capacitance is 7000µF, and electrical durability ranges from 34,000 to 334,000 hours depending on operating conditions. The ripple is maintained at 50mVpp. This AC/DC power supply unit, part of the C-Line series, is designed with a 20% power reserve and features a DC-OK relay contact output and spring-clamp connections. It accepts a supply voltage of 85Vac-132Vac / 184Vac-264Vac with auto-selection and has a rated current of up to 12A at 24Vdc in environments below 45°C. The output voltage is adjustable between 24Vdc and 28Vdc, with minimal turn-on overshoot, and the hold time is 47ms at 230Vac input.
Quick Quote
PULS CP10.241-S1 is a DIN rail mounting power supply unit housed in aluminium, designed to operate within an ambient air temperature range of -25 to +70°C. It consumes 1.13A with a 230Vac input for full output, 2.15A with a 120Vac input, 2.6A with a 100Vac input, and 2.35A with a 110Vdc input for a 24Vdc / 10A output, featuring a peak max. inrush of 11A at 230Vac input and 7A at 120Vac input. This unit offers an IP20 degree of protection and achieves an efficiency of 0.952 at 230Vac input and 0.936 at 120Vac input. Its dimensions are W39mm x H124mm x D117mm. The start-up delay ranges from 240-300ms for 100-230Vac input, with a rise time of 30ms under nominal input with a full constant current load and 0mF load capacitance, extending to 160ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection, overload/short-circuit current protection, and over-temperature protection with automatic restart. The unit supports series/parallel operation for increased output voltages or power, and redundancy for higher system availability, and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 12.1W at 230Vac input and 16.4W at 120Vac input with a full output load. The output stage capacitance is 4400µF. Electrical durability is rated at various hours across different conditions, with a ripple of 50mVpp at 20Hz to 20MHz. This AC/DC power supply unit offers a 20% power reserve, is part of the CP-series, and features ATEX approval, DC-OK relay contact output, and spring-clamp connections. It accepts a supply voltage of 88Vdc-180Vdc and 85Vac-264Vac, with specific tolerances for overvoltage and shutdown voltages, and provides a rated current of 12A at 48Vdc in temperatures up to +45°C, adjusting for higher temperatures. The rated power varies from 288W at -25 to +45°C to 180W at +70°C, with the output voltage adjustable between 24Vdc and 28Vdc, and a hold time of 37ms at 120/230Vac input.
Quick Quote
PULS CP10.361 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It features a net width of 39 mm and operates within an ambient air temperature range of -25 to +70°C. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.954 at 230Vac input, 0.938 at 120Vac input, and 0.931 at 100Vac input. The dimensions of the CP10.361 are W39mm x H124mm x D117mm. It includes a time delay of 240-300ms for start-up and a rise time of 60ms under nominal input with a constant full current load without load capacitance, and 120ms with 7mF load capacitance. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It can handle back-feeding loads up to 50V without malfunctioning. Power dissipation/losses are 11.6W at full output load with 230Vac input and 15.9W with 120Vac input. The output stage capacitance is 1500µF. Electrical durability varies with conditions, reaching up to 553000 hours at 25°C with 3.35A output and 1AC 230Vac input. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit offers a 20% power reserve and includes ATEX approval, DC-OK relay contact output, and screw-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 6.7A at 36Vdc, and provides an adjustable output voltage of 36Vdc-42Vdc. The hold time is 38ms at both 120/230Vac input.
Quick Quote
PULS CPS20.361 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 65mm. This unit has a current consumption of 2.33A at 230Vac input for full 36Vdc output, 4.36A at 120Vac input, and 5.25A at 100Vac input, with a peak inrush current of 13A at both 230Vac and 120Vac inputs. It features an IP20 degree of protection and boasts efficiencies of 0.943, 0.93, and 0.924 at 230Vac, 120Vac, and 100Vac inputs respectively. The dimensions of the CPS20.361 are W65mm x H124mm x D127mm. It includes a 900ms start-up delay and offers rise times of 90ms and 200ms under specified conditions. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, and it supports series/parallel operation for increased output power. The power dissipation/losses are rated at 29W, and the output stage capacitance is 3800µF. Its electrical durability varies based on conditions, with up to 516000 hours at 25°C and 6.7A output with 1AC 230Vac input. The ripple is specified at 100mVpp. This AC/DC power supply unit features a 20% power reserve, is part of the C-series, and has ATEX approval. Connection is facilitated through screw-clamp connections, and it accepts a supply voltage range of 85Vac-264Vac. The rated current is 13.3A at 36Vdc, suitable for single-phase networks, with a rated power of 576W under PowerBoost at ambient temperatures less than 45°C and 480W at less than 60°C. The output voltage is adjustable between 36Vdc and 42Vdc, with a 1V turn-ON overshoot, and it offers a hold time of 26ms.
Quick Quote
PULS CT5.121 is a power supply unit designed for DIN rail mounting with an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 40mm. The unit consumes 0.56A with a 480Vac input and 0.64A with a 400Vac input for a full 12Vdc output, with a peak inrush current of 10A for both input voltages. It features an efficiency of 0.858 at 480Vac input and 0.854 at 400Vac input. The dimensions are W40mm x H124mm x D117mm. It includes a 75ms start-up delay and a rise time of 50ms under nominal input with a constant full current load and 0mF load capacitance, extending to 85ms with 8mF load capacitance. The unit is equipped with protection functions including output overvoltage protection and an active input inrush current limiter, supporting overload/short-circuit conditions with a continuous current of max. 15A. It allows for series/parallel operation to increase output power, with a back-feeding load resistance up to 25V. Power dissipation losses are 15.9W and 16.4W for 480Vac and 400Vac inputs, respectively, under full output load. The output stage capacitance is 5200µF. Electrical durability ranges from 51,000 to 430,000 hours, depending on operating conditions. Ripple is maintained at 100mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the CT-series, features a DC-OK relay contact output and screw-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac, with various shutdown voltages based on load conditions. The rated current is 8A at 12Vdc within a -25 to +60°C range, adjusting with temperature and output voltage. The rated power is 96W, with an adjustable output voltage of 12Vdc to 15Vdc and minimal turn-on overshoot. Hold time is specified at 63ms and 43ms for 480Vac and 400Vac inputs, respectively.
Quick Quote
PULS ML100.200 is a power supply unit designed for AC/DC conversion with DIN rail mounting capabilities. It operates within an ambient air temperature range of -10 to +70°C and offers a rated current of 4.2A at 24Vdc, with a derating of 2.5W from +60°C to +70°C. The unit features spring-clamp connections for secure installation and supports a wide supply voltage range of 323Vac to 576Vac, accommodating various nominal voltages such as 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac across a frequency range of 47-63Hz, suitable for 2-phase input networks. With dimensions of W72.5mm x H75mm x D103mm and constructed from a PC/ABS blend housing, the ML100.200 has a net width of 72.5 mm. It delivers a rated power of 100W and an adjustable output voltage range of 24Vdc to 28Vdc. The unit is equipped with an NTC for input inrush current limitation, achieving efficiencies of 0.895 and 0.89 at 400Vac and 480Vac inputs, respectively. It has a maximum inrush current consumption of 36A at 2x400Vac input and 45A peak at 2x480Vac input, with power dissipation/losses of 11.7W and a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS ML50.105 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is classified under NEC Class 2 design. The unit provides a rated current of 1.05A at 48Vdc with a power derating from 1.3W at +60°C to +70°C. It features spring-clamp connections for secure and reliable connectivity. The supply voltage ranges from 85Vac to 264Vac for AC input (with specific nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, a turn-ON voltage of 65Vac, and a shutdown voltage of 55Vac) and from 88Vdc to 375Vdc for DC input (with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc). The housing is made from a PC / ABS blend, ensuring durability within its specified environment. This unit is compatible with single-phase (1AC) or DC networks, has a net width of 45 mm, and offers a rated power of 50W. The output voltage is adjustable between 48Vdc and 56Vdc, with a 400mV turn-ON overshoot. It boasts an efficiency of 0.9 with a 230Vac input, a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input, and includes a 32s start-up delay for 100-230Vac input with a 48ms rise time under nominal input conditions. Power dissipation/losses are rated at 6W, with a ripple of 200mVpp across a frequency range of 20Hz to 20MHz at 50Ω, and an output stage capacitance of 1600 µF.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| ML30.106 PULS ML30.106 is a dual output voltage single-phase power supply unit (PSU) and AC/DC-Converter designed for DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is classified as NEC Class 2. This unit provides a rated current of 2.5A at 12Vdc with spring-clamp connections for ease of installation. It supports a wide supply voltage range from 85Vac to 264Vac (with nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz), featuring a 46Vac turn-ON voltage and a 44Vac shutdown voltage. Additionally, it can be powered by DC voltages ranging from 88Vdc to 375Vdc, with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc. The ML30.106 has dimensions of W45mm x H75mm x D91mm and is housed in a PC/ABS blend. It is suitable for single-phase (1AC) or DC networks, has a net width of 45 mm, and offers a rated power of 36W. The output voltage is symmetrical +/-12Vdc to +/-15Vdc, adjustable with a 250mV turn-ON overshoot. It features protection functions including NTC for input inrush current limiting, achieves an efficiency of 0.86 with a 230Vac input, and has a current consumption of 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. Power dissipation/losses are rated at 5.9 W, and it has a ripple of 50mVpp across 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| QS10.241 PULS QS10.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 10A at 24Vdc and 9A at 28Vdc, with spring-clamp connections for secure installation. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, accommodating both single-phase AC or DC networks. The QS10.241 measures 60mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing for durability. It delivers a rated power of 240W at 24V and 252W at 28V, with a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, featuring comprehensive protection functions including overvoltage and overload/short-circuit protection. This unit is capable of series or parallel operation for increased output power, with an efficiency up to 93.5% depending on the input voltage. It has a peak current consumption of 10A, with specific start-up and rise times, and maintains power with a hold time of 28ms at 230Vac input. The QS10.241 is designed for electrical durability, offering up to 200,000 hours of operation at 25°C with a 10A output and 1AC 230Vac input, and features a ripple of 50mVpp at 20Hz to 20MHz with an output stage capacitance of 7000µF. | Puls | Quick Quote | ||
| CP10.241-C1 PULS CP10.241-C1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 39mm. The unit consumes 1.13A at 230Vac input, 2.15A at 120Vac input, 2.6A at 100Vac input, and 2.35A at 110Vdc input for a 24Vdc / 10A output, with peak inrush currents of 11A at 230Vac input and 7A at 120Vac input. It offers an efficiency of 0.952 at 230Vac input and 0.936 at 120Vac input. The CP10.241-C1 features IP20 degree of protection and is resistant to harsh environments due to its conformal coated PCB. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms and a rise time of 30ms to 160ms depending on the load capacitance. It includes protection functions such as output overvoltage, overload/short-circuit, and over-temperature protection with automatic restart. The power supply supports series/parallel operation for increased output voltages or power, and 1+1 redundancy with a redundancy module. It can handle back-feeding loads up to 35V without malfunctioning. Power dissipation/losses are 12.1W at 230Vac input and 16.4W at 120Vac input, with an output stage capacitance of 4400µF. Electrical durability ranges from 39,000 to 499,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series, featuring ATEX approval, conformal coating, 20% power reserve, and a DC-OK relay contact output. It uses screw-clamp connections and accepts a supply voltage of 88Vdc-180Vdc or 85Vac-264Vac, with specific tolerances for overvoltage and shutdown voltages. The rated current is 12A at 48Vdc in temperatures up to +45°C, decreasing to 7.5A at 24Vdc at +70°C. It is suitable for single-phase (1AC) or DC networks, providing a rated power of 288W at -25 to +45°C, 240W at -25 to +60°C, and 180W at +70°C, with a linear derating between +60°C and +70°C. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 37ms at 120/230Vac input. | Puls | Quick Quote | ||
| CS10.241-S1 PULS CS10.241-S1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and supports various current consumptions based on input voltage: 2.23A at 230Vac, 3.73A at 120Vac, and 4.34A at 100Vac, all for full 24Vdc output, with a peak inrush current of 10A across all input voltages. The unit boasts an efficiency of up to 0.916 at 230Vac input. Its dimensions are 60mm in width, 124mm in height, and 117mm in depth. The CS10.241-S1 features a start-up delay of 850ms and rise times of 35ms to 75ms depending on load capacitance. It includes protection functions such as output overvoltage protection and an active input inrush current limiter, alongside capabilities for series or parallel operation for redundancy. The power dissipation at full output load is 22W for 230Vac input and 23.7W for 120Vac input. The output stage capacitance is 7000µF, and electrical durability ranges from 34,000 to 334,000 hours depending on operating conditions. The ripple is maintained at 50mVpp. This AC/DC power supply unit, part of the C-Line series, is designed with a 20% power reserve and features a DC-OK relay contact output and spring-clamp connections. It accepts a supply voltage of 85Vac-132Vac / 184Vac-264Vac with auto-selection and has a rated current of up to 12A at 24Vdc in environments below 45°C. The output voltage is adjustable between 24Vdc and 28Vdc, with minimal turn-on overshoot, and the hold time is 47ms at 230Vac input. | Puls | Quick Quote | ||
| CP10.241-S1 PULS CP10.241-S1 is a DIN rail mounting power supply unit housed in aluminium, designed to operate within an ambient air temperature range of -25 to +70°C. It consumes 1.13A with a 230Vac input for full output, 2.15A with a 120Vac input, 2.6A with a 100Vac input, and 2.35A with a 110Vdc input for a 24Vdc / 10A output, featuring a peak max. inrush of 11A at 230Vac input and 7A at 120Vac input. This unit offers an IP20 degree of protection and achieves an efficiency of 0.952 at 230Vac input and 0.936 at 120Vac input. Its dimensions are W39mm x H124mm x D117mm. The start-up delay ranges from 240-300ms for 100-230Vac input, with a rise time of 30ms under nominal input with a full constant current load and 0mF load capacitance, extending to 160ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection, overload/short-circuit current protection, and over-temperature protection with automatic restart. The unit supports series/parallel operation for increased output voltages or power, and redundancy for higher system availability, and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 12.1W at 230Vac input and 16.4W at 120Vac input with a full output load. The output stage capacitance is 4400µF. Electrical durability is rated at various hours across different conditions, with a ripple of 50mVpp at 20Hz to 20MHz. This AC/DC power supply unit offers a 20% power reserve, is part of the CP-series, and features ATEX approval, DC-OK relay contact output, and spring-clamp connections. It accepts a supply voltage of 88Vdc-180Vdc and 85Vac-264Vac, with specific tolerances for overvoltage and shutdown voltages, and provides a rated current of 12A at 48Vdc in temperatures up to +45°C, adjusting for higher temperatures. The rated power varies from 288W at -25 to +45°C to 180W at +70°C, with the output voltage adjustable between 24Vdc and 28Vdc, and a hold time of 37ms at 120/230Vac input. | Puls | Quick Quote | ||
| CP10.361 PULS CP10.361 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It features a net width of 39 mm and operates within an ambient air temperature range of -25 to +70°C. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.954 at 230Vac input, 0.938 at 120Vac input, and 0.931 at 100Vac input. The dimensions of the CP10.361 are W39mm x H124mm x D117mm. It includes a time delay of 240-300ms for start-up and a rise time of 60ms under nominal input with a constant full current load without load capacitance, and 120ms with 7mF load capacitance. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It can handle back-feeding loads up to 50V without malfunctioning. Power dissipation/losses are 11.6W at full output load with 230Vac input and 15.9W with 120Vac input. The output stage capacitance is 1500µF. Electrical durability varies with conditions, reaching up to 553000 hours at 25°C with 3.35A output and 1AC 230Vac input. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit offers a 20% power reserve and includes ATEX approval, DC-OK relay contact output, and screw-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 6.7A at 36Vdc, and provides an adjustable output voltage of 36Vdc-42Vdc. The hold time is 38ms at both 120/230Vac input. | Puls | Quick Quote | ||
| CPS20.361 PULS CPS20.361 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 65mm. This unit has a current consumption of 2.33A at 230Vac input for full 36Vdc output, 4.36A at 120Vac input, and 5.25A at 100Vac input, with a peak inrush current of 13A at both 230Vac and 120Vac inputs. It features an IP20 degree of protection and boasts efficiencies of 0.943, 0.93, and 0.924 at 230Vac, 120Vac, and 100Vac inputs respectively. The dimensions of the CPS20.361 are W65mm x H124mm x D127mm. It includes a 900ms start-up delay and offers rise times of 90ms and 200ms under specified conditions. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, and it supports series/parallel operation for increased output power. The power dissipation/losses are rated at 29W, and the output stage capacitance is 3800µF. Its electrical durability varies based on conditions, with up to 516000 hours at 25°C and 6.7A output with 1AC 230Vac input. The ripple is specified at 100mVpp. This AC/DC power supply unit features a 20% power reserve, is part of the C-series, and has ATEX approval. Connection is facilitated through screw-clamp connections, and it accepts a supply voltage range of 85Vac-264Vac. The rated current is 13.3A at 36Vdc, suitable for single-phase networks, with a rated power of 576W under PowerBoost at ambient temperatures less than 45°C and 480W at less than 60°C. The output voltage is adjustable between 36Vdc and 42Vdc, with a 1V turn-ON overshoot, and it offers a hold time of 26ms. | Puls | Quick Quote | ||
| CT5.121 PULS CT5.121 is a power supply unit designed for DIN rail mounting with an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 40mm. The unit consumes 0.56A with a 480Vac input and 0.64A with a 400Vac input for a full 12Vdc output, with a peak inrush current of 10A for both input voltages. It features an efficiency of 0.858 at 480Vac input and 0.854 at 400Vac input. The dimensions are W40mm x H124mm x D117mm. It includes a 75ms start-up delay and a rise time of 50ms under nominal input with a constant full current load and 0mF load capacitance, extending to 85ms with 8mF load capacitance. The unit is equipped with protection functions including output overvoltage protection and an active input inrush current limiter, supporting overload/short-circuit conditions with a continuous current of max. 15A. It allows for series/parallel operation to increase output power, with a back-feeding load resistance up to 25V. Power dissipation losses are 15.9W and 16.4W for 480Vac and 400Vac inputs, respectively, under full output load. The output stage capacitance is 5200µF. Electrical durability ranges from 51,000 to 430,000 hours, depending on operating conditions. Ripple is maintained at 100mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the CT-series, features a DC-OK relay contact output and screw-clamp connections. It supports a wide supply voltage range of 323Vac to 576Vac, with various shutdown voltages based on load conditions. The rated current is 8A at 12Vdc within a -25 to +60°C range, adjusting with temperature and output voltage. The rated power is 96W, with an adjustable output voltage of 12Vdc to 15Vdc and minimal turn-on overshoot. Hold time is specified at 63ms and 43ms for 480Vac and 400Vac inputs, respectively. | Puls | Quick Quote | ||
| ML100.200 PULS ML100.200 is a power supply unit designed for AC/DC conversion with DIN rail mounting capabilities. It operates within an ambient air temperature range of -10 to +70°C and offers a rated current of 4.2A at 24Vdc, with a derating of 2.5W from +60°C to +70°C. The unit features spring-clamp connections for secure installation and supports a wide supply voltage range of 323Vac to 576Vac, accommodating various nominal voltages such as 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac across a frequency range of 47-63Hz, suitable for 2-phase input networks. With dimensions of W72.5mm x H75mm x D103mm and constructed from a PC/ABS blend housing, the ML100.200 has a net width of 72.5 mm. It delivers a rated power of 100W and an adjustable output voltage range of 24Vdc to 28Vdc. The unit is equipped with an NTC for input inrush current limitation, achieving efficiencies of 0.895 and 0.89 at 400Vac and 480Vac inputs, respectively. It has a maximum inrush current consumption of 36A at 2x400Vac input and 45A peak at 2x480Vac input, with power dissipation/losses of 11.7W and a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| ML50.105 PULS ML50.105 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and is classified under NEC Class 2 design. The unit provides a rated current of 1.05A at 48Vdc with a power derating from 1.3W at +60°C to +70°C. It features spring-clamp connections for secure and reliable connectivity. The supply voltage ranges from 85Vac to 264Vac for AC input (with specific nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz, a turn-ON voltage of 65Vac, and a shutdown voltage of 55Vac) and from 88Vdc to 375Vdc for DC input (with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc). The housing is made from a PC / ABS blend, ensuring durability within its specified environment. This unit is compatible with single-phase (1AC) or DC networks, has a net width of 45 mm, and offers a rated power of 50W. The output voltage is adjustable between 48Vdc and 56Vdc, with a 400mV turn-ON overshoot. It boasts an efficiency of 0.9 with a 230Vac input, a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input, and includes a 32s start-up delay for 100-230Vac input with a 48ms rise time under nominal input conditions. Power dissipation/losses are rated at 6W, with a ripple of 200mVpp across a frequency range of 20Hz to 20MHz at 50Ω, and an output stage capacitance of 1600 µF. | Puls | Quick Quote | ||
