CP10.241-R2 Puls AC/DC Power Supplies

PULS CP10.241-R2 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 39mm. The unit consumes current differently based on the input, including 1.14A with 230Vac input, 2.17A with 120Vac input, 2.63A with 100Vac input, and 2.35A with 110Vdc input, all at full output. It features a peak inrush current of 11A at 230Vac input and 7A at 120Vac input. With an IP20 degree of protection, the efficiency rates are 0.947 at 230Vac input and 0.93 at 120Vac input. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms and rise times of 30ms and 75ms under specified conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or redundancy. The power dissipation/losses are 13.4W and 18.1W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 4400µF. Electrical durability varies with conditions, offering up to 531000 hours at 25°C with 5A output and 1AC 230Vac input. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the CP-series, is designed with a built-in decoupling MOSFET for 1+1 or N+1 redundancy and includes a 20% power reserve. It features DC-OK relay contact output and hot-swappable connectors. The supply voltage ranges from 88Vdc to 180Vdc for DC and 85Vac to 264Vac for AC, with specific tolerances for overvoltage and shutdown voltages. The rated current is 12A at 48Vdc up to +45°C, decreasing at higher temperatures. It supports single-phase (1AC) or DC networks and provides a rated power of 288W at -25 to +45°C, with linear derating up to +70°C. The output voltage is adjustable from 24Vdc to 25.4Vdc, with a 200mV turn-ON overshoot and a hold time of 37ms at 120/230Vac input.

About the manufacturer: Puls is one of the manufacturers that offers AC/DC Power Supplies that you can order at Advantage Electric Supply site. Puls specializes in AC/DC power supplies, dedicating its efforts solely to the development of premium DIN rail power supplies. As a leading authority in power conversion, Puls distinguishes itself through focused engineering and an unwavering commitment to quality, positioning itself as the top leader in the field. This dedication ensures the highest standard in the industry, reflecting in every product they offer.

Check out the CP10.241-R2 Puls price in the box on the right side or send a quick quote.
