36051T Mersen Fuse Holders
Part#:36051T
Manufacturer:Mersen
Alt. Part#:782001675806
Product Lifecycle:Active
Get a quick Quote!
36051T Mersen - Fuse Block 300VAC 300VDC Class T 600A 1-Pole Copper Box
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the 36051T Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 1 Pole
- Current Rating 600 A
- Weight 862.6 g
- Voltage 300 VAC
- Sell Pack Width 3.12 in
- Sell Pack Weight 2 lb
- Sell Pack Length 7 in
- Sell Pack Height 3.06 in
- Sell Pack Quantity 1 Each
- Product Length 5.75 in
- Product Height 3.09 in
- Product Weight 1.9 lb
- Installation Mounting Direct Screw Mount
- Max Fuse Rating 600 A
- Body/Insulating Material Phenolic
- Product Width 3 in
- Short Circuit Current Rating (SCCR) 200
- Fuse Class Class T
- Fuse Type/Class Class T
- Rated voltage AC UL 300 V
- Fuse Installation Method Clip-in
- ROHS Compliant Yes
- Ampere Rating 600 A
- Number of Poles 1-pole
- Rated voltage DC UL 300 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
36051T Description
36051T Mersen - Fuse Block 300VAC 300VDC Class T 600A 1-Pole Copper Box | Mersen Class T fuse blocks accommodate Class T fuses up to 600A. Insulators are either durable, glass-filled polycarbonate (GFPC) or phenolic with verified dielectric strength in excess of 2500V. Mersen is the only manufacturer to offer Class T blocks with copper connectors | Features: *Unique integral DIN-rail adapters for 600V, 30 & 60A blocks
*Full barrier design (30 & 60A) increases pole to pole safety
*Unique adder-block design (30 & 60A) for design flexibility
*Spring reinforcing standard for all 30 & 60A clips
*Features high conductivity copper alloy fuse clips
*Cool running high amperage (100 - 600A) connectors
*Copper connectors available 30 - 600A | Application:
Related documents 36051T Specs
