61008J Mersen Fuse Holders
Part#:61008J
Manufacturer:Mersen
Alt. Part#:782001759520
Product Lifecycle:Active
In-stock parts: 8
Sep 30, 2024
61008J Mersen - Fuse Block 600VAC 600VDC Class J 100A 3-Pole Box with Reinforced Clip
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the 61008J Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 3 Pole
- Current Rating 100 A
- Weight 1511.82 g
- Voltage 600 VAC
- Sell Pack Length 8.44 in
- Sell Pack Height 2.44 in
- Sell Pack Width 5.12 in
- Sell Pack Weight 3.5 lb
- Sell Pack Quantity 1 Each
- Product Height 2.36 in
- Product Length 7 in
- Product Width 5 in
- Max Fuse Rating 100 A
- Installation Mounting Direct Screw Mount
- Product Weight 3.33 lb
- Body/Insulating Material GFPC
- ROHS Compliant Yes
- Rated voltage AC UL 600 V
- Ampere Rating 100 A
- Fuse Type/Class Class J
- Fuse Class Class J
- Rated voltage DC UL 600 V
- Short Circuit Current Rating (SCCR) 200
- Fuse Installation Method Clip-in
- Number of Poles 3-pole
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
61008J Description
61008J Mersen - Fuse Block 600VAC 600VDC Class J 100A 3-Pole Box with Reinforced Clip | A choice of screw, pressure plate, box and special order stud connectors fit a wide range of stranded or solid copper or aluminum conductors. Insulators are either molded glass-filled polycarbonate (GFPC) or phenolic with verified dielectric strength in excess of 2500V. 30A, 60A and the new 100A SJ fuse blocks feature a unique adder block configuration which can be snapped onto 1-, 2-, or 3-pole blocks to form multi-pole segmented blocks of as many poles as desired. All fuse clips are made of high conductivity tin-plated copper, with a choice of spring-reinforced or non-spring reinforced clips. Space saving options are now available in the 30A and 100A configurations which are noted in the product selection tables. | Features: *Class J Blocks (600V) use with AJT, A4J, HSJ | Application:
Related documents 61008J Specs
