MPDB68111 Mersen Fuse Holders
Part#:MPDB68111
Manufacturer:Mersen
Alt. Part#:782001458782
Product Lifecycle:Active
In-stock parts: 7
Sep 30, 2024
MPDB68111 Mersen Open-Style PDB UL 1953 1000V Tin-plated Copper - 760A 1-Pole 2 - 12 openings; 500-#4 --- #4-#14 Box to Box
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the MPDB68111 Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 1 Pole
- Current Rating 760 A
- Weight 1679.8 g
- Voltage 1000 V
- Sell Pack Height 17.75 in
- Sell Pack Weight 23.31 lb
- Sell Pack Length 5.69 in
- Sell Pack Width 4 in
- Product Height 3.55 in
- Sell Pack Quantity 6 Each
- Product Length 5.7 in
- Product Width 2.73 in
- Wire Range (Secondary) #4-#14
- Installation Mounting Direct Screw Mount
- Wire Range (Primary) 500-#4
- Product Weight 3.7 lb
- Hex/Screw Size & Type (Primary) 13/16-16 x 1.06
- Torque Rating (Secondary) #4-#6 45; #8 40; #10-#14 35
- Hex/Screw Size & Type (Secondary) 5/16-24 x .38
- Torque Rating (Primary) 500-#4 375
- Hole Diameter (Secondary) 0.27 in
- Hole Diameter (Primary) 0.88 in
- Short Circuit Rating (Class RK5) 600 kA
- Short Circuit Rating (Class T) 800 kA
- Number of Openings per Pole (Secondary) 12
- Body/Insulating Material GFPC
- Connector Type (Secondary) Box
- Number of Openings per Pole (Primary) 2
- Number of Poles 1-pole
- Connector Material Tin-plated Copper
- Connector Type (Primary) Box
- Short Circuit Rating (Class G) 60 kA
- Rated voltage AC UL 1000 V
- Short Circuit Rating (Class CC) 30 kA
- Short Circuit Rating (Standalone) 10 kA
- ROHS Compliant Yes
- Rated voltage DC UL 1000 V
- Short Circuit Rating (Class RK1) 600 kA
- Short Circuit Rating (Class L) 800 kA
- Short Circuit Rating (Class J) 600 kA
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
MPDB68111 Description
MPDB68111 Mersen Open-Style PDB UL 1953 1000V Tin-plated Copper - 760A 1-Pole 2 - 12 openings; 500-#4 --- #4-#14 Box to Box | The Next Generation Power Distribution Block (PDB). Mersen power distribution blocks provide a safe and easy method of splicing cables, splitting primary power into secondary circuits and fulfilling requirements for fixed junction tap-off points. All blocks are UL and CSA approved while meeting spacing requirements for feeder and branch circuits in conjunction with UL508A and the National Electrical Code®. PDB options include single or dual conductor primary inputs and up to 30 secondary outputs. Specialty blocks are available allowing for up to 7 primary inputs. The MPDB series is offered in three size categories: miniature (MPDB62 and MPDB63 series), intermediate (MPDB66 and MPDB67 series), and large (MPDB68 and MPDB69 series), in both aluminum and copper. | *Adder Poles: All sizes have optional adder poles for increased flexibility and ease-of-use. Adder poles can be stacked to form multi-pole units in the field without the use of tools. Adder poles allow for customization of primary and secondary wire combinations. End barriers are also available for sale, catalog numbers can be found in the catalog number selection tables for each size block.
*Wire Connectors: Standard aluminum and copper wire connectors are available. Aluminum connectors accept both AL or CU wire while copper connectors accept CU wire only. Connectors are all 1-piece tin-plated. Many part numbers are rated to accept DLO-type fine-strand wire, allowing users to connect flexible conductors.
*Insulators: Insulators are virtually unbreakable, made of glass-filled polycarbonate. “See-through,” hinged safety covers are optional and provide a greater degree of safety and shock resistance where required. Hinged covers can be installed without tools.
*Spacings: 1 inch through air and 2 inches over surface between uninsulated live parts of opposite polarity meets requirements
