L1037862 Mersen Electronic Components

Mersen L1037862 NH fuse-link gPV, 1500VDC, size 3L, 315A
Mersen

Part#:L1037862

Manufacturer:Mersen

Alt. Part#:3605340547399

Product Lifecycle:Active

In-stock parts: 10

Sep 19, 2024

NH fuse-link gPV, 1500VDC, size 3L, 315A

About the manufacturer: Mersen is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the L1037862 Mersen price in the box on the right side or send a quick quote.

Product Details

  • Sell Pack Height
    4.33 in
  • Sell Pack Weight
    3.726 lb
  • Product Height
    3.33 in
  • Sell Pack Width
    4.53 in
  • Sell Pack Length
    9.06 in
  • Sell Pack Quantity
    1 EACH
  • Product Weight
    3.726 lb
  • Product Length
    8.07 in
  • Product Width
    2.76 in
  • Connection/Terminal Type
    Plain Blades
  • Connection/Terminal Material
    Silver-Plated Copper
  • Speed/Characteristic
    gPV
  • Catalogue No.
    HP15NH3LGPV315
  • Power Dissipation at Intermediate Current Value
    23W @ 0.7 In W
  • Mounting
    Clip
  • Rated voltage DC IEC
    1500 V
  • Ampere Rating
    315 A
  • Power Dissipation at Rated Current Value
    57 W
  • Fuse Size
    3L
  • Rated voltage DC UL
    1500 V

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents L1037862 Specs

L1037862 DS-Special-Purpose-Fuse-Links-HelioProtection-Photovoltaic-Fuses-HP15NH-1500VDC-EN (EN,PDF,2198Ko).pdf

This item can ship within 24h!
