PULS CS5.244 is a DIN rail mounting power supply unit enclosed in an aluminium housing, designed for a single-phase network. It operates within an ambient air temperature range of -10 to +70°C and consumes 1.16A at 230Vac input for full 24Vdc output, with a peak inrush current of 38A at 230Vac input. The unit boasts an efficiency of 0.902 at 230Vac input and has dimensions of W32mm x H124mm x D117mm. It features a 130ms start-up delay, an 8ms rise time at nominal input with a constant full current load and 0mF load capacitance, and a 25ms rise time under the same conditions with 5mF load capacitance. Protection functions include output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection with a minimum of 10A and a maximum of 14A at load impedance. It supports series/parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 13.2W at 230Vac input with full output load, and the output stage capacitance is 1800µF. The electrical durability ranges from 42,000 to 408,000 hours depending on the conditions, with a ripple of 50mVpp. This AC/DC power supply unit, part of the C-Line series, includes a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage of 180Vac-264Vac, with a rated current of 6A at 24Vdc in ambient temperatures less than 45°C and 5A at 24Vdc in temperatures less than 60°C. The rated power is 144W in ambient temperatures less than 45°C and 120W in temperatures less than 60°C, with an adjustable output voltage of 24Vdc-28Vdc and a 78ms hold time at 230Vac input.
Quick Quote
PULS CT10.241-C1 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a current consumption of 0.6A with a 3 x 480Vac input for full 24Vdc output, and 0.7A with a 3 x 400Vac input for full 24Vdc output, with a peak inrush current of 10A for both input conditions. The unit boasts an efficiency of 0.929 and 0.928 for 3x480Vac and 3x400Vac inputs respectively. It is designed to resist harsh environments with its conformal coated PCB. The dimensions are W62mm x H124mm x D117mm. It features a 90ms start-up delay, a 40ms rise time under nominal input with a constant full current load and 0mF load capacitance, and an 85ms rise time under the same conditions with 10mF load capacitance. The power supply unit includes protection functions such as output overvoltage protection and is capable of series/parallel operation for increased output power. It has a power dissipation/loss of 18.3W and 18.6W for 3x480Vac and 3x400Vac inputs respectively, with an output stage capacitance of 6500µF. The electrical durability ranges from 36,000 to 410,000 hours depending on the operating conditions. The ripple is 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter offers a 20% power reserve and is part of the CT-series, featuring a conformal coating, 20% power reserve, and a DC-OK relay contact output. It utilizes screw-clamp connections and supports a supply voltage of 323Vac-576Vac with a wide range, 3-phase input. The rated current is 12A at 24Vdc from -25 to +45°C and 7.5A at 24Vdc from -25 to +70°C, with a rated power of 240W. The output voltage is adjustable between 24Vdc and 28Vdc, and the hold time is 54ms at 3x480Vac input and 34ms at 3x400Vac input.
Quick Quote
PULS ML100.102 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and offers a rated current of 7.5A at 12Vdc. This unit features spring-clamp connections for secure and efficient connectivity. It supports a wide range of supply voltages, including AC inputs from 85Vac to 132Vac and 184Vac to 264Vac across various nominal values (100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac) with auto-selection and a frequency range of 47-63Hz, as well as DC inputs from 213Vdc to 377Vdc (220Vdc, 250Vdc nominal). The ML100.102 is housed in a PC / ABS blend, ensuring durability, and measures W72.5mm x H75mm x D103mm. It is suitable for single-phase (1AC) or DC networks, with a net width of 72.5 mm. The unit's rated power is 90W, and it provides an adjustable output voltage range of 12Vdc to 15Vdc. It incorporates an NTC for input inrush current limiting, achieves an efficiency of 0.885 with a 230Vac input, and has a maximum inrush current consumption of 22A at 120Vac input and 37A peak at 230Vac input. Power dissipation/losses are calculated at 11.7 W, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS ML50.100 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a NEC Class 2 DC-OK relay contact output. The unit provides a rated current of 2.1A at 24Vdc and utilizes spring-clamp connections for connectivity. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac; 47-63Hz), a turn-ON voltage of 65Vac, and a shutdown voltage of 55Vac. Additionally, it can operate with DC supply voltages between 82Vdc and 380Vdc, with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc. The PSU's housing is made from a PC / ABS blend, and it is compatible with single-phase (1AC) or DC networks. Its dimensions are W45mm x H75mm x D91mm, and it has a net width of 45 mm. The rated power is 50W, and the output voltage is adjustable between 24Vdc and 28Vdc, with a 400mV turn-ON overshoot. It features protection functions including an NTC (input inrush current limiter) and boasts efficiencies of 0.89 (230Vac input), 0.884 (120Vac input), and 0.875 (100Vac input). The current consumption can reach up to 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. The PSU has a 32ms start-up delay for 100-230Vac input, a rise time of 33-48ms under nominal input with a constant full current load and 0mF load capacitance, and a rise time of 45-60ms under the same conditions with 2mF load capacitance. Power dissipation/losses are calculated at 6.2 W, and the electrical durability is rated at a minimum of 54kh (54,000 hours) at +40°C. The ripple is specified as 50mVpp (20Hz...20MHz; 50Ω), and the output stage capacitance is 1600 µF.
Quick Quote
PULS UB10.245 is an Uninterruptible Power Supply (UPS) control module from the UB-series, featuring an external battery with a 50% power reserve and a green status LED. This module is housed in aluminium and utilizes spring-clamp connections for its connections. It measures W49mm x H124mm x D117mm and operates on a supply voltage range of 22.5Vdc-30Vdc (24Vdc nominal). The rated current is 10A at 22.5Vdc with Output 1 providing 15A in normal mode and 10A/15A (360W) in buffer mode. Output 2 delivers 12V; 5A in both normal and buffer modes. Designed for DIN rail mounting, it can operate in ambient air temperatures ranging from -25 to +70°C. The current consumption is 1.1A at a 24Vdc input, and it is designed for DC networks. Visual position indicators include Ready, Buffering, Inhibit, and Replace Battery. It features protection functions against output overvoltage (32Vdc typical / 35Vdc max.) and overload/short-circuit current (min. 17.9A, max. 21A at load impedance). The output voltage is 22.5Vdc and 12Vdc (regulated) in buffer mode with a 23Vdc turn-ON. The efficiency is rated at 0.975 with a 24Vdc input, and the rated power is 360W (at 24Vdc) and 240W/360W in buffer mode. Power dissipation/losses are 3.4 W at no load and 6 W with a 10A output current at 24Vdc input. Ripple is 20mVpp (20Hz...20MHz; 50Ω), and electrical durability is rated at 114000 hours at 40°C with a 10A output and 24Vdc input, 148000 hours at 40°C with a 5A output and 24Vdc input, and 380000 hours at 25°C with a 10A output and 24Vdc input.
Quick Quote
PULS XT40.362 is a power supply unit part of the X-series, designed to convert AC to DC power with a semi-regulated 25% power reserve. It features a DC-OK relay contact output and operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 26.6A at 36Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.362 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 36 Vdc (1200W for typ. 15s with derating applicable from +60°C to +70°C), and includes protection functions such as output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 41.1V, has an efficiency of 0.955 (at 3x480Vac input), a start-up delay of 350ms, and a rise time of 40ms (70ms with 27mF load capacitance) at nominal input. The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, a hold time of 2.6ms at 3x480Vdc input, and power dissipation/losses of 45.2W at full output load. Its electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 480Vdc input), with higher durability at reduced loads or temperatures. The output stage capacitance is 11100µF, and the ripple is 2000mVpp (20Hz...2KHz; 50Ω).
Quick Quote
PULS YR40.245 is a redundancy unit within the Y-series, designed for single-input redundancy module applications, featuring 1 x input and 1 x output with built-in decoupling MOSFETs suitable for 1+1 or N+1 redundancy configurations. It has ATEX approval for hot-swappable connectors and operates on a supply voltage range of 8.4Vdc to 36.4Vdc, with nominal voltages of 12Vdc and 24Vdc. The unit measures 46mm in width, 124mm in height, and 127mm in depth, and utilizes screw-clamp connections for secure installation. It is rated for a current of 40A at 28Vdc, with a derating to 1A at temperatures ranging from +60°C to +70°C. Designed for DIN rail mounting, it can operate in ambient air temperatures from -40°C to +70°C. The YR40.245 has a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 22A threshold at 6V. It supports both series and parallel operation for 1+1 and N+1 redundancy, ensuring continued operation through the use of two or more identical power supplies in parallel. The output voltage range is 12-28Vdc, with power dissipation/losses of 1.8W at 20A input and 6.2W at 40A input. Its electrical durability is rated at 557,000 hours at 40°C and 20A output, and 1,576,000 hours at 25°C and 40A output. The output stage capacitance is 320µF, with a ripple of 80mVpp at 1x20A and 150mVpp at 40A, across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS YR80.241 is a redundancy unit belonging to the Y-series, designed with a built-in decoupling MOSFET for 1+1 or N+1 redundancy and ATEX approval. It operates with a supply voltage range of 8.4Vdc to 36.4Vdc, nominally at 12Vdc or 24Vdc, and can handle a rated current of 80A at 28Vdc. The unit features screw-clamp connections for secure installation and is designed for DIN rail mounting. It operates efficiently within an ambient air temperature range of -40 to +70°C. The YR80.241 has dimensions of W46mm x H124mm x D127mm and a net width of 46 mm. It is capable of a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 130A threshold at 6V. This model supports both series and parallel operation for 1+1 redundancy, utilizing two identical power supplies, and N+1 redundancy, using three or more identical power supplies, with all outputs isolated by diodes or other switching arrangements. The output voltage range is 12-28Vdc, nominally at 12Vdc or 24Vdc. Power dissipation/losses are rated at 2.7 W for 8.4-36.4Vdc input with 2x20A input and 3.6 W for 40A input. Its electrical durability is notable, with up to 1450000 hours at 25°C for 80A output with 2x20A input. The output stage capacitance is 320 µF, and the ripple is measured at 49mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS CP5.241-S2 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It offers a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S2 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3W and 8.2W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 1800µF. Electrical durability ranges from 96000 to 775000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and push-in spring connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms.
Quick Quote
PULS CP5.242 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac inputs. Efficiency rates are 0.943 at 230Vac input, 0.935 at 120Vac input, and 0.927 at 100Vac input. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.242 provides protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 1800 µF. Electrical durability ranges from 96,000 to 775,000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with an enhanced DC input and a 20% power reserve, featuring a DC-OK relay contact output and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and offers an adjustable output voltage of 24Vdc-28Vdc. The unit is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W, with a hold time of 35ms.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| CS5.244 PULS CS5.244 is a DIN rail mounting power supply unit enclosed in an aluminium housing, designed for a single-phase network. It operates within an ambient air temperature range of -10 to +70°C and consumes 1.16A at 230Vac input for full 24Vdc output, with a peak inrush current of 38A at 230Vac input. The unit boasts an efficiency of 0.902 at 230Vac input and has dimensions of W32mm x H124mm x D117mm. It features a 130ms start-up delay, an 8ms rise time at nominal input with a constant full current load and 0mF load capacitance, and a 25ms rise time under the same conditions with 5mF load capacitance. Protection functions include output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection with a minimum of 10A and a maximum of 14A at load impedance. It supports series/parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 13.2W at 230Vac input with full output load, and the output stage capacitance is 1800µF. The electrical durability ranges from 42,000 to 408,000 hours depending on the conditions, with a ripple of 50mVpp. This AC/DC power supply unit, part of the C-Line series, includes a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage of 180Vac-264Vac, with a rated current of 6A at 24Vdc in ambient temperatures less than 45°C and 5A at 24Vdc in temperatures less than 60°C. The rated power is 144W in ambient temperatures less than 45°C and 120W in temperatures less than 60°C, with an adjustable output voltage of 24Vdc-28Vdc and a 78ms hold time at 230Vac input. | Puls | Quick Quote | ||
| CT10.241-C1 PULS CT10.241-C1 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a current consumption of 0.6A with a 3 x 480Vac input for full 24Vdc output, and 0.7A with a 3 x 400Vac input for full 24Vdc output, with a peak inrush current of 10A for both input conditions. The unit boasts an efficiency of 0.929 and 0.928 for 3x480Vac and 3x400Vac inputs respectively. It is designed to resist harsh environments with its conformal coated PCB. The dimensions are W62mm x H124mm x D117mm. It features a 90ms start-up delay, a 40ms rise time under nominal input with a constant full current load and 0mF load capacitance, and an 85ms rise time under the same conditions with 10mF load capacitance. The power supply unit includes protection functions such as output overvoltage protection and is capable of series/parallel operation for increased output power. It has a power dissipation/loss of 18.3W and 18.6W for 3x480Vac and 3x400Vac inputs respectively, with an output stage capacitance of 6500µF. The electrical durability ranges from 36,000 to 410,000 hours depending on the operating conditions. The ripple is 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit/converter offers a 20% power reserve and is part of the CT-series, featuring a conformal coating, 20% power reserve, and a DC-OK relay contact output. It utilizes screw-clamp connections and supports a supply voltage of 323Vac-576Vac with a wide range, 3-phase input. The rated current is 12A at 24Vdc from -25 to +45°C and 7.5A at 24Vdc from -25 to +70°C, with a rated power of 240W. The output voltage is adjustable between 24Vdc and 28Vdc, and the hold time is 54ms at 3x480Vac input and 34ms at 3x400Vac input. | Puls | Quick Quote | ||
| ML100.102 PULS ML100.102 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and offers a rated current of 7.5A at 12Vdc. This unit features spring-clamp connections for secure and efficient connectivity. It supports a wide range of supply voltages, including AC inputs from 85Vac to 132Vac and 184Vac to 264Vac across various nominal values (100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac) with auto-selection and a frequency range of 47-63Hz, as well as DC inputs from 213Vdc to 377Vdc (220Vdc, 250Vdc nominal). The ML100.102 is housed in a PC / ABS blend, ensuring durability, and measures W72.5mm x H75mm x D103mm. It is suitable for single-phase (1AC) or DC networks, with a net width of 72.5 mm. The unit's rated power is 90W, and it provides an adjustable output voltage range of 12Vdc to 15Vdc. It incorporates an NTC for input inrush current limiting, achieves an efficiency of 0.885 with a 230Vac input, and has a maximum inrush current consumption of 22A at 120Vac input and 37A peak at 230Vac input. Power dissipation/losses are calculated at 11.7 W, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| ML50.100 PULS ML50.100 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a NEC Class 2 DC-OK relay contact output. The unit provides a rated current of 2.1A at 24Vdc and utilizes spring-clamp connections for connectivity. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values including 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, 240Vac; 47-63Hz), a turn-ON voltage of 65Vac, and a shutdown voltage of 55Vac. Additionally, it can operate with DC supply voltages between 82Vdc and 380Vdc, with nominal values such as 100Vdc, 110Vdc, 120Vdc, 127Vdc, 200Vdc, 220Vdc, and 250Vdc. The PSU's housing is made from a PC / ABS blend, and it is compatible with single-phase (1AC) or DC networks. Its dimensions are W45mm x H75mm x D91mm, and it has a net width of 45 mm. The rated power is 50W, and the output voltage is adjustable between 24Vdc and 28Vdc, with a 400mV turn-ON overshoot. It features protection functions including an NTC (input inrush current limiter) and boasts efficiencies of 0.89 (230Vac input), 0.884 (120Vac input), and 0.875 (100Vac input). The current consumption can reach up to 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. The PSU has a 32ms start-up delay for 100-230Vac input, a rise time of 33-48ms under nominal input with a constant full current load and 0mF load capacitance, and a rise time of 45-60ms under the same conditions with 2mF load capacitance. Power dissipation/losses are calculated at 6.2 W, and the electrical durability is rated at a minimum of 54kh (54,000 hours) at +40°C. The ripple is specified as 50mVpp (20Hz...20MHz; 50Ω), and the output stage capacitance is 1600 µF. | Puls | Quick Quote | ||
| UB10.245 PULS UB10.245 is an Uninterruptible Power Supply (UPS) control module from the UB-series, featuring an external battery with a 50% power reserve and a green status LED. This module is housed in aluminium and utilizes spring-clamp connections for its connections. It measures W49mm x H124mm x D117mm and operates on a supply voltage range of 22.5Vdc-30Vdc (24Vdc nominal). The rated current is 10A at 22.5Vdc with Output 1 providing 15A in normal mode and 10A/15A (360W) in buffer mode. Output 2 delivers 12V; 5A in both normal and buffer modes. Designed for DIN rail mounting, it can operate in ambient air temperatures ranging from -25 to +70°C. The current consumption is 1.1A at a 24Vdc input, and it is designed for DC networks. Visual position indicators include Ready, Buffering, Inhibit, and Replace Battery. It features protection functions against output overvoltage (32Vdc typical / 35Vdc max.) and overload/short-circuit current (min. 17.9A, max. 21A at load impedance). The output voltage is 22.5Vdc and 12Vdc (regulated) in buffer mode with a 23Vdc turn-ON. The efficiency is rated at 0.975 with a 24Vdc input, and the rated power is 360W (at 24Vdc) and 240W/360W in buffer mode. Power dissipation/losses are 3.4 W at no load and 6 W with a 10A output current at 24Vdc input. Ripple is 20mVpp (20Hz...20MHz; 50Ω), and electrical durability is rated at 114000 hours at 40°C with a 10A output and 24Vdc input, 148000 hours at 40°C with a 5A output and 24Vdc input, and 380000 hours at 25°C with a 10A output and 24Vdc input. | Puls | Quick Quote | ||
| XT40.362 PULS XT40.362 is a power supply unit part of the X-series, designed to convert AC to DC power with a semi-regulated 25% power reserve. It features a DC-OK relay contact output and operates on a supply voltage of 3x432-528Vac (440Vac / 480Vac / 500Vac / 525Vac nominal; 47-63Hz), with a turn-on voltage of 3 x 390Vac and a shutdown voltage of 3 x 355Vac. The unit is housed in an aluminium casing, measures W96mm x H124mm x D159mm, and uses screw-clamp connections for installation. It is rated for a current of 26.6A at 36Vdc and is designed for DIN rail mounting in a 3-phase (3AC) network. The ambient air temperature for operation ranges from -25 to +70°C. The XT40.362 has a peak inrush current consumption of 4A (at 3x480Vac input), a rated power of 960W at 36 Vdc (1200W for typ. 15s with derating applicable from +60°C to +70°C), and includes protection functions such as output overvoltage protection (42.5Vdc max.), active input inrush current limiter, and overload/short-circuit current protection. It is not suitable for parallel operation to increase output power but supports 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 41.1V, has an efficiency of 0.955 (at 3x480Vac input), a start-up delay of 350ms, and a rise time of 40ms (70ms with 27mF load capacitance) at nominal input. The fixed output voltage is 36Vdc with a 700mV turn-ON overshoot, a hold time of 2.6ms at 3x480Vdc input, and power dissipation/losses of 45.2W at full output load. Its electrical durability is rated at 55000 hours (at 40°C; 26.6A output; 3AC 480Vdc input), with higher durability at reduced loads or temperatures. The output stage capacitance is 11100µF, and the ripple is 2000mVpp (20Hz...2KHz; 50Ω). | Puls | Quick Quote | ||
| YR40.245 PULS YR40.245 is a redundancy unit within the Y-series, designed for single-input redundancy module applications, featuring 1 x input and 1 x output with built-in decoupling MOSFETs suitable for 1+1 or N+1 redundancy configurations. It has ATEX approval for hot-swappable connectors and operates on a supply voltage range of 8.4Vdc to 36.4Vdc, with nominal voltages of 12Vdc and 24Vdc. The unit measures 46mm in width, 124mm in height, and 127mm in depth, and utilizes screw-clamp connections for secure installation. It is rated for a current of 40A at 28Vdc, with a derating to 1A at temperatures ranging from +60°C to +70°C. Designed for DIN rail mounting, it can operate in ambient air temperatures from -40°C to +70°C. The YR40.245 has a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 22A threshold at 6V. It supports both series and parallel operation for 1+1 and N+1 redundancy, ensuring continued operation through the use of two or more identical power supplies in parallel. The output voltage range is 12-28Vdc, with power dissipation/losses of 1.8W at 20A input and 6.2W at 40A input. Its electrical durability is rated at 557,000 hours at 40°C and 20A output, and 1,576,000 hours at 25°C and 40A output. The output stage capacitance is 320µF, with a ripple of 80mVpp at 1x20A and 150mVpp at 40A, across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| YR80.241 PULS YR80.241 is a redundancy unit belonging to the Y-series, designed with a built-in decoupling MOSFET for 1+1 or N+1 redundancy and ATEX approval. It operates with a supply voltage range of 8.4Vdc to 36.4Vdc, nominally at 12Vdc or 24Vdc, and can handle a rated current of 80A at 28Vdc. The unit features screw-clamp connections for secure installation and is designed for DIN rail mounting. It operates efficiently within an ambient air temperature range of -40 to +70°C. The YR80.241 has dimensions of W46mm x H124mm x D127mm and a net width of 46 mm. It is capable of a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 130A threshold at 6V. This model supports both series and parallel operation for 1+1 redundancy, utilizing two identical power supplies, and N+1 redundancy, using three or more identical power supplies, with all outputs isolated by diodes or other switching arrangements. The output voltage range is 12-28Vdc, nominally at 12Vdc or 24Vdc. Power dissipation/losses are rated at 2.7 W for 8.4-36.4Vdc input with 2x20A input and 3.6 W for 40A input. Its electrical durability is notable, with up to 1450000 hours at 25°C for 80A output with 2x20A input. The output stage capacitance is 320 µF, and the ripple is measured at 49mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| CP5.241-S2 PULS CP5.241-S2 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It offers a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S2 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3W and 8.2W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 1800µF. Electrical durability ranges from 96000 to 775000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and push-in spring connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms. | Puls | Quick Quote | ||
| CP5.242 PULS CP5.242 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac inputs. Efficiency rates are 0.943 at 230Vac input, 0.935 at 120Vac input, and 0.927 at 100Vac input. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.242 provides protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 1800 µF. Electrical durability ranges from 96,000 to 775,000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with an enhanced DC input and a 20% power reserve, featuring a DC-OK relay contact output and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and offers an adjustable output voltage of 24Vdc-28Vdc. The unit is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W, with a hold time of 35ms. | Puls | Quick Quote | ||
