PULS QS10.241-D1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and includes an extended DC input for the same power reserve, along with a DC-OK relay contact output. The unit provides a rated current of 10A at 24Vdc and 9A at 28Vdc, utilizing spring-clamp connections for secure attachment. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, ensuring flexibility across different power networks. The QS10.241-D1, part of the Q-series, measures 60mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing for durability. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 240W at 24V, 252W at 28V, and a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, with comprehensive protection functions against overvoltage, overload, and short-circuit conditions. Efficiency rates vary with input voltage, achieving up to 0.935 at 230Vac. The unit exhibits a start-up delay between 340-800ms, with a hold time of 28ms at 230Vac input, and demonstrates electrical durability up to 200,000 hours at 25°C with a 10A output and 1AC 230Vac input. Output ripple is maintained at 50mVpp, with an output stage capacitance of 7000µF.
Quick Quote
PULS QS10.481-D1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and includes an extended DC input for enhanced versatility. The unit provides a rated current of 5A at 48Vdc and 4.3A at 56Vdc, with a derating of 6W from +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 88Vdc-188Vdc for DC, with specific nominal values across a broad spectrum. The QS10.481-D1, part of the Q-series, measures 60mm in width, 124mm in height, and 117mm in depth, and is housed in aluminium for durability. It is compatible with single-phase AC or DC networks and offers a rated power of 240W, with a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 56Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation for increased output power. Efficiency rates vary by input voltage, achieving up to 0.92 at 230Vac. The unit exhibits a peak inrush current consumption of 10A, with a start-up delay between 340-800ms and a hold time of 28ms at 230Vac input. Power dissipation is noted at 20.9W for 230Vac input under full load. Electrical durability spans up to 228000 hours under specific conditions, with a ripple of 100mVpp and an output stage capacitance of 3000µF.
Quick Quote
PULS QS20.241-A1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and boasts ATEX approval and conformal coating for enhanced durability in harsh environments. The unit provides a rated current of 20A at 24Vdc and 17A at 28Vdc, with spring-clamp connections facilitating secure and reliable connectivity. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, ensuring flexibility across different power networks. The QS20.241-A1, part of the Q-series, measures 82mm in width, 124mm in height, and 127mm in depth, with an aluminium housing that contributes to its robustness. It delivers a rated power of 480W, with a short-term capacity of 720W for up to 4 seconds, and an adjustable output voltage between 24Vdc and 28Vdc. Protection features include output overvoltage protection and active input inrush current limiting, alongside capabilities for overload, short-circuit protection, and series or parallel operation for increased output power. The unit demonstrates high efficiency rates up to 93.9% depending on the input voltage and is designed for single-phase or DC networks. Electrical durability is rated up to 200,000 hours at 25°C with a 20A output, and the power supply unit includes a comprehensive protection function suite to ensure stable operation under various conditions.
Quick Quote
PULS QS20.244 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 24Vdc and 17A at 28Vdc, with spring-clamp connections for secure and efficient connectivity. It supports a supply voltage range of 180Vac to 264Vac, with specific nominal values including 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz. The QS20.244, part of the Q-series, measures 70mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase networks and offers a rated power of 480W, with a short-term capacity of 720W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, featuring protection functions against overvoltage, overload, and short-circuit conditions. It allows for series or parallel operation to increase output power, with a notable efficiency of 0.945 at 230Vac input. The unit's current consumption peaks at 52A max during inrush at 230Vac, with a start-up delay of 140ms, and offers a hold time of 46ms at 230Vac input. Power dissipation is calculated at 28.3W under full output load at 230Vac input. Its electrical durability spans up to 307,000 hours at 40°C with a 10A output. The QS20.244 also features a ripple of 100mVpp across a 20Hz to 20MHz range and an output stage capacitance of 8500µF.
Quick Quote
PULS QS20.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and features a DC-OK relay contact output for monitoring purposes. The unit provides a rated current of 13.3A at 36Vdc and 11.4A at 42Vdc, with spring-clamp connections facilitating secure and reliable connectivity. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, ensuring flexibility across different power networks. The QS20.361, part of the Q-series, measures 82mm in width, 124mm in height, and 127mm in depth, housed in a durable aluminium casing. It delivers a rated power of 480W, with a short-term capacity of 720W for up to 4 seconds, and an adjustable output voltage between 36Vdc and 42Vdc. Protection features include output overvoltage protection and active input inrush current limiting, alongside capabilities for overload and short-circuit management. The unit is designed for both single-phase AC or DC networks and offers high efficiency rates up to 0.94 depending on the input voltage. It also allows for series or parallel operation to increase output power, with specific attention to maintaining uniform output voltage across paralleled units. The QS20.361 exhibits a low power dissipation, high electrical durability across various conditions, and minimal ripple, alongside a significant output capacitance of 8500µF, ensuring stable and consistent power supply performance.
Quick Quote
PULS QT40.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It features DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. The unit is equipped with a DC-OK relay contact output and offers a rated current of 26.7A at 36Vdc and 22.9A at 42Vdc, with a power derating of 24W at temperatures from +60°C to +70°C. Connection is facilitated through screw-clamp connections. The supply voltage accommodates a wide range of 323Vac to 576Vac (with nominal values including 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac; 47-63Hz), featuring a 3-phase input, a turn-ON voltage of 3 x 305Vac, and a shutdown voltage of 3 x 275Vac in steady-state conditions. This part of the Q-series measures W110mm x H124mm x D127mm and is housed in aluminium. It is designed for a 3-phase network, with a net width of 110 mm. The rated power is 960W at both 36Vdc and 42Vdc, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with a turn-ON overshoot of 750mV. Protection functions include output overvoltage protection, active input inrush current limiter, and overload/short-circuit protection. It supports series or parallel operation for increased output power and is resistant to back-feeding loads up to 50V. The efficiency rates are 0.952 at 3x480Vac input and 0.953 at 3x400Vac input. Peak inrush current consumption is 6A at both 3x400Vac and 3x480Vac inputs. The unit has a start-up delay of 500-600s, with rise times of 40ms and 45ms under specified conditions, and a hold time of 25ms. Power dissipation losses are 48.4W and 47.3W for 3x480Vac and 3x400Vac inputs, respectively, under full output load. Electrical durability spans from 363000 hours to 72000 hours across various conditions, with a ripple of 130mVpp at 20Hz to 20MHz and an output stage capacitance of 4700µF.
Quick Quote
PULS QT40.481 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It supports DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. This unit features a design that includes a 50% power reserve and a DC-OK relay contact output. It offers a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. The QT40.481 utilizes screw-clamp connections for its inputs and outputs and is designed to work with a supply voltage (AC) ranging from 323Vac to 576Vac across various nominal voltages, accommodating a wide range of 3-phase inputs. It belongs to the Q-series and is housed in an aluminium casing with dimensions of W110mm x H124mm x D127mm. This unit is compatible with 3-phase networks and has a net width of 110 mm. Its rated power is 960W at both 48Vdc and 54Vdc, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and active input inrush current limiting, with overload and short-circuit protection ensuring operational stability. The QT40.481 supports series or parallel operation for increased output power and is resistant to back-feeding loads up to 63V. It boasts high efficiency rates of 0.952 and 0.954 for 3x480Vac and 3x400Vac inputs, respectively. Peak inrush current consumption is capped at 6A for both 3x400Vac and 3x480Vac inputs. The unit exhibits a start-up delay of 500-600s and rise times of 23ms and 47ms under specified conditions, with a hold time of 25ms. Power dissipation losses are noted at 48.4W and 46.3W for full output loads at 3x480Vac and 3x400Vac inputs, respectively. Its electrical durability spans up to 324000 hours at 25°C and 10A output for a 3AC 400Vac input, with varying durability at different temperatures and outputs. The ripple is specified at 150mVpp across a 20Hz to 20MHz range, and the output stage capacitance is 3700 µF.
Quick Quote
PULS SLA4.100 is a power supply unit designed with a PFC compliant to EN 61000-3-2 standards, featuring a DC-OK relay contact output. It serves as an AS-Interface power supply unit (PSU) encased in a robust metal housing. This unit offers screw-clamp connections for secure installation and measures W73mm x H124mm x D102mm. It supports a wide range of supply voltages, including AC inputs from 85Vac-132Vac / 187Vac-264Vac across various nominal values and a DC input range of 240Vdc-300Vdc, with a rated current of 4A at 30.5Vdc. Designed for DIN rail mounting, it operates efficiently within an ambient air temperature range of -10...+70 °C. The SLA4.100 experiences a peak inrush current consumption of 49.7A at 230Vac input and 44.7A at 120Vac input, suitable for single-phase (1AC) or DC networks. It incorporates multiple protection functions, including output overvoltage protection up to 55Vdc max., NTC for input inrush current limiting, and overload/short-circuit protection with a current range of min. 4.2A to max. 6.5A, though it does not support series or parallel operation or ground-fault monitoring. The output voltage is fixed at 30.5Vdc, with an efficiency of 0.9 at 230Vac input, a hold time of 30ms at 100Vac input, power dissipation/losses at 13.5 W under full output load at 230Vac input, and a ripple of 50mVpp across 20Hz to 20MHz at 50Ω.
Quick Quote
PULS CD5.241-S1 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit consumes 5.5A current at a 24Vdc input to deliver a full 24Vdc output at 5A, with a peak inrush current of 1.6A. It boasts an efficiency of 0.902 under a 24Vdc, 5A input condition. The dimensions of this power supply unit are W32mm x H124mm x D102mm. It includes a 290ms start-up delay and a 520ms rise time under nominal input with a constant full current load. The CD5.241-S1 is equipped with protection functions including output overvoltage protection, low input voltage signalling via relay contact, and short-circuit current protection. It supports series or parallel operation for increased output power or 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 30V and includes reverse polarity protection. Power dissipation/losses are 13.3 W under a 24Vdc input with a 24V output load at 5A. The output stage capacitance is 2200 µF, and the electrical durability ranges from 33,000 to 180,000 hours depending on the operating conditions. Ripple is maintained at 50mVpp. This PSU/DC-DC Converter offers a 20% power reserve and features ATEX approval, galvanic isolation, and a DC-OK relay contact output. Connection is facilitated through spring-clamp connections. The supply voltage ranges from 18Vdc to 32.4Vdc, with a rated current of 6A at 24Vdc in temperatures up to 45°C, and a rated power of 144W in ambient temperatures less than 45°C. The output voltage is adjustable between 23-28Vdc, with a 500mV turn-ON overshoot, and a hold time of 6ms at 24Vdc input.
Quick Quote
PULS CS5.241-S1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers various current consumption rates depending on the input voltage: 1.23A at 230Vac, 2A at 120Vac, and 2.33A at 100Vac, with a peak inrush current of 10A across all input voltages. The unit boasts an efficiency of up to 90.2% at 230Vac input. Its dimensions are W32mm x H124mm x D117mm, and it features a start-up delay between 740-900ms and a rise time of 8ms to 25ms depending on the load capacitance. The CS5.241-S1 provides output overvoltage protection, active input inrush current limiting, and overload/short-circuit protection. It supports series or parallel operation for redundancy, ensuring higher system availability, and can handle back-feeding loads up to 35V without malfunctioning. Power dissipation is 13.2W at full output load with 230Vac input. The output stage capacitance is 1800µF, and the electrical durability ranges from 34,000 to 408,000 hours depending on the operating conditions. Ripple is maintained at 50mVpp. This AC/DC power supply unit, part of the C-Line series, is designed with a 20% power reserve and features a DC-OK relay contact output. It utilizes spring-clamp connections for easy installation and is compatible with a supply voltage range of 85Vac-132Vac / 184Vac-264Vac, automatically selecting the appropriate input. The rated current is 6A at 24Vdc in environments up to 45°C and 5A at 24Vdc up to 60°C, with a rated power of 144W at less than 45°C ambient temperature and 120W at less than 60°C. The output voltage is adjustable between 24Vdc and 28Vdc, with minimal turn-on overshoot, and the hold time is 78ms to 80ms depending on the input voltage. This unit is designed for single-phase networks.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| QS10.241-D1 PULS QS10.241-D1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and includes an extended DC input for the same power reserve, along with a DC-OK relay contact output. The unit provides a rated current of 10A at 24Vdc and 9A at 28Vdc, utilizing spring-clamp connections for secure attachment. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, ensuring flexibility across different power networks. The QS10.241-D1, part of the Q-series, measures 60mm in width, 124mm in height, and 117mm in depth, housed in an aluminium casing for durability. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 240W at 24V, 252W at 28V, and a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, with comprehensive protection functions against overvoltage, overload, and short-circuit conditions. Efficiency rates vary with input voltage, achieving up to 0.935 at 230Vac. The unit exhibits a start-up delay between 340-800ms, with a hold time of 28ms at 230Vac input, and demonstrates electrical durability up to 200,000 hours at 25°C with a 10A output and 1AC 230Vac input. Output ripple is maintained at 50mVpp, with an output stage capacitance of 7000µF. | Puls | Quick Quote | ||
| QS10.481-D1 PULS QS10.481-D1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and includes an extended DC input for enhanced versatility. The unit provides a rated current of 5A at 48Vdc and 4.3A at 56Vdc, with a derating of 6W from +60°C to +70°C. Connection is facilitated through spring-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 88Vdc-188Vdc for DC, with specific nominal values across a broad spectrum. The QS10.481-D1, part of the Q-series, measures 60mm in width, 124mm in height, and 117mm in depth, and is housed in aluminium for durability. It is compatible with single-phase AC or DC networks and offers a rated power of 240W, with a short-term capacity of 360W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 56Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation for increased output power. Efficiency rates vary by input voltage, achieving up to 0.92 at 230Vac. The unit exhibits a peak inrush current consumption of 10A, with a start-up delay between 340-800ms and a hold time of 28ms at 230Vac input. Power dissipation is noted at 20.9W for 230Vac input under full load. Electrical durability spans up to 228000 hours under specific conditions, with a ripple of 100mVpp and an output stage capacitance of 3000µF. | Puls | Quick Quote | ||
| QS20.241-A1 PULS QS20.241-A1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and boasts ATEX approval and conformal coating for enhanced durability in harsh environments. The unit provides a rated current of 20A at 24Vdc and 17A at 28Vdc, with spring-clamp connections facilitating secure and reliable connectivity. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, ensuring flexibility across different power networks. The QS20.241-A1, part of the Q-series, measures 82mm in width, 124mm in height, and 127mm in depth, with an aluminium housing that contributes to its robustness. It delivers a rated power of 480W, with a short-term capacity of 720W for up to 4 seconds, and an adjustable output voltage between 24Vdc and 28Vdc. Protection features include output overvoltage protection and active input inrush current limiting, alongside capabilities for overload, short-circuit protection, and series or parallel operation for increased output power. The unit demonstrates high efficiency rates up to 93.9% depending on the input voltage and is designed for single-phase or DC networks. Electrical durability is rated up to 200,000 hours at 25°C with a 20A output, and the power supply unit includes a comprehensive protection function suite to ensure stable operation under various conditions. | Puls | Quick Quote | ||
| QS20.244 PULS QS20.244 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 24Vdc and 17A at 28Vdc, with spring-clamp connections for secure and efficient connectivity. It supports a supply voltage range of 180Vac to 264Vac, with specific nominal values including 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at a frequency of 47-63Hz. The QS20.244, part of the Q-series, measures 70mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase networks and offers a rated power of 480W, with a short-term capacity of 720W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, featuring protection functions against overvoltage, overload, and short-circuit conditions. It allows for series or parallel operation to increase output power, with a notable efficiency of 0.945 at 230Vac input. The unit's current consumption peaks at 52A max during inrush at 230Vac, with a start-up delay of 140ms, and offers a hold time of 46ms at 230Vac input. Power dissipation is calculated at 28.3W under full output load at 230Vac input. Its electrical durability spans up to 307,000 hours at 40°C with a 10A output. The QS20.244 also features a ripple of 100mVpp across a 20Hz to 20MHz range and an output stage capacitance of 8500µF. | Puls | Quick Quote | ||
| QS20.361 PULS QS20.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and features a DC-OK relay contact output for monitoring purposes. The unit provides a rated current of 13.3A at 36Vdc and 11.4A at 42Vdc, with spring-clamp connections facilitating secure and reliable connectivity. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 188Vdc, ensuring flexibility across different power networks. The QS20.361, part of the Q-series, measures 82mm in width, 124mm in height, and 127mm in depth, housed in a durable aluminium casing. It delivers a rated power of 480W, with a short-term capacity of 720W for up to 4 seconds, and an adjustable output voltage between 36Vdc and 42Vdc. Protection features include output overvoltage protection and active input inrush current limiting, alongside capabilities for overload and short-circuit management. The unit is designed for both single-phase AC or DC networks and offers high efficiency rates up to 0.94 depending on the input voltage. It also allows for series or parallel operation to increase output power, with specific attention to maintaining uniform output voltage across paralleled units. The QS20.361 exhibits a low power dissipation, high electrical durability across various conditions, and minimal ripple, alongside a significant output capacitance of 8500µF, ensuring stable and consistent power supply performance. | Puls | Quick Quote | ||
| QT40.361 PULS QT40.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It features DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. The unit is equipped with a DC-OK relay contact output and offers a rated current of 26.7A at 36Vdc and 22.9A at 42Vdc, with a power derating of 24W at temperatures from +60°C to +70°C. Connection is facilitated through screw-clamp connections. The supply voltage accommodates a wide range of 323Vac to 576Vac (with nominal values including 380Vac, 400Vac, 415Vac, 440Vac, 480Vac, 500Vac, and 525Vac; 47-63Hz), featuring a 3-phase input, a turn-ON voltage of 3 x 305Vac, and a shutdown voltage of 3 x 275Vac in steady-state conditions. This part of the Q-series measures W110mm x H124mm x D127mm and is housed in aluminium. It is designed for a 3-phase network, with a net width of 110 mm. The rated power is 960W at both 36Vdc and 42Vdc, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 36Vdc and 42Vdc, with a turn-ON overshoot of 750mV. Protection functions include output overvoltage protection, active input inrush current limiter, and overload/short-circuit protection. It supports series or parallel operation for increased output power and is resistant to back-feeding loads up to 50V. The efficiency rates are 0.952 at 3x480Vac input and 0.953 at 3x400Vac input. Peak inrush current consumption is 6A at both 3x400Vac and 3x480Vac inputs. The unit has a start-up delay of 500-600s, with rise times of 40ms and 45ms under specified conditions, and a hold time of 25ms. Power dissipation losses are 48.4W and 47.3W for 3x480Vac and 3x400Vac inputs, respectively, under full output load. Electrical durability spans from 363000 hours to 72000 hours across various conditions, with a ripple of 130mVpp at 20Hz to 20MHz and an output stage capacitance of 4700µF. | Puls | Quick Quote | ||
| QT40.481 PULS QT40.481 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It supports DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. This unit features a design that includes a 50% power reserve and a DC-OK relay contact output. It offers a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. The QT40.481 utilizes screw-clamp connections for its inputs and outputs and is designed to work with a supply voltage (AC) ranging from 323Vac to 576Vac across various nominal voltages, accommodating a wide range of 3-phase inputs. It belongs to the Q-series and is housed in an aluminium casing with dimensions of W110mm x H124mm x D127mm. This unit is compatible with 3-phase networks and has a net width of 110 mm. Its rated power is 960W at both 48Vdc and 54Vdc, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and active input inrush current limiting, with overload and short-circuit protection ensuring operational stability. The QT40.481 supports series or parallel operation for increased output power and is resistant to back-feeding loads up to 63V. It boasts high efficiency rates of 0.952 and 0.954 for 3x480Vac and 3x400Vac inputs, respectively. Peak inrush current consumption is capped at 6A for both 3x400Vac and 3x480Vac inputs. The unit exhibits a start-up delay of 500-600s and rise times of 23ms and 47ms under specified conditions, with a hold time of 25ms. Power dissipation losses are noted at 48.4W and 46.3W for full output loads at 3x480Vac and 3x400Vac inputs, respectively. Its electrical durability spans up to 324000 hours at 25°C and 10A output for a 3AC 400Vac input, with varying durability at different temperatures and outputs. The ripple is specified at 150mVpp across a 20Hz to 20MHz range, and the output stage capacitance is 3700 µF. | Puls | Quick Quote | ||
| SLA4.100 PULS SLA4.100 is a power supply unit designed with a PFC compliant to EN 61000-3-2 standards, featuring a DC-OK relay contact output. It serves as an AS-Interface power supply unit (PSU) encased in a robust metal housing. This unit offers screw-clamp connections for secure installation and measures W73mm x H124mm x D102mm. It supports a wide range of supply voltages, including AC inputs from 85Vac-132Vac / 187Vac-264Vac across various nominal values and a DC input range of 240Vdc-300Vdc, with a rated current of 4A at 30.5Vdc. Designed for DIN rail mounting, it operates efficiently within an ambient air temperature range of -10...+70 °C. The SLA4.100 experiences a peak inrush current consumption of 49.7A at 230Vac input and 44.7A at 120Vac input, suitable for single-phase (1AC) or DC networks. It incorporates multiple protection functions, including output overvoltage protection up to 55Vdc max., NTC for input inrush current limiting, and overload/short-circuit protection with a current range of min. 4.2A to max. 6.5A, though it does not support series or parallel operation or ground-fault monitoring. The output voltage is fixed at 30.5Vdc, with an efficiency of 0.9 at 230Vac input, a hold time of 30ms at 100Vac input, power dissipation/losses at 13.5 W under full output load at 230Vac input, and a ripple of 50mVpp across 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| CD5.241-S1 PULS CD5.241-S1 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit consumes 5.5A current at a 24Vdc input to deliver a full 24Vdc output at 5A, with a peak inrush current of 1.6A. It boasts an efficiency of 0.902 under a 24Vdc, 5A input condition. The dimensions of this power supply unit are W32mm x H124mm x D102mm. It includes a 290ms start-up delay and a 520ms rise time under nominal input with a constant full current load. The CD5.241-S1 is equipped with protection functions including output overvoltage protection, low input voltage signalling via relay contact, and short-circuit current protection. It supports series or parallel operation for increased output power or 1+1 redundancy for higher system availability. The unit is resistant to back-feeding loads up to 30V and includes reverse polarity protection. Power dissipation/losses are 13.3 W under a 24Vdc input with a 24V output load at 5A. The output stage capacitance is 2200 µF, and the electrical durability ranges from 33,000 to 180,000 hours depending on the operating conditions. Ripple is maintained at 50mVpp. This PSU/DC-DC Converter offers a 20% power reserve and features ATEX approval, galvanic isolation, and a DC-OK relay contact output. Connection is facilitated through spring-clamp connections. The supply voltage ranges from 18Vdc to 32.4Vdc, with a rated current of 6A at 24Vdc in temperatures up to 45°C, and a rated power of 144W in ambient temperatures less than 45°C. The output voltage is adjustable between 23-28Vdc, with a 500mV turn-ON overshoot, and a hold time of 6ms at 24Vdc input. | Puls | Quick Quote | ||
| CS5.241-S1 PULS CS5.241-S1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers various current consumption rates depending on the input voltage: 1.23A at 230Vac, 2A at 120Vac, and 2.33A at 100Vac, with a peak inrush current of 10A across all input voltages. The unit boasts an efficiency of up to 90.2% at 230Vac input. Its dimensions are W32mm x H124mm x D117mm, and it features a start-up delay between 740-900ms and a rise time of 8ms to 25ms depending on the load capacitance. The CS5.241-S1 provides output overvoltage protection, active input inrush current limiting, and overload/short-circuit protection. It supports series or parallel operation for redundancy, ensuring higher system availability, and can handle back-feeding loads up to 35V without malfunctioning. Power dissipation is 13.2W at full output load with 230Vac input. The output stage capacitance is 1800µF, and the electrical durability ranges from 34,000 to 408,000 hours depending on the operating conditions. Ripple is maintained at 50mVpp. This AC/DC power supply unit, part of the C-Line series, is designed with a 20% power reserve and features a DC-OK relay contact output. It utilizes spring-clamp connections for easy installation and is compatible with a supply voltage range of 85Vac-132Vac / 184Vac-264Vac, automatically selecting the appropriate input. The rated current is 6A at 24Vdc in environments up to 45°C and 5A at 24Vdc up to 60°C, with a rated power of 144W at less than 45°C ambient temperature and 120W at less than 60°C. The output voltage is adjustable between 24Vdc and 28Vdc, with minimal turn-on overshoot, and the hold time is 78ms to 80ms depending on the input voltage. This unit is designed for single-phase networks. | Puls | Quick Quote | ||
