TRS500RID Mersen Fuses
Product Details
- Current Rating 500 A
- Terminal Type Blade
- Material PolyTube
- Type Low Voltage UL/CSA Fuses
- Weight 2163.195 g
- Voltage 600 VAC / 600 VDC
- Approvals *UL listed to standard 248-12 File E2137 *CSA certified to standard C22.2 no. 248.12 *DC listed to UL standard 248 TRS only
- UL Certification YES
- Trip Class Time Delay
- Fuse Class Class RK5
- Sell Pack Weight 5.3 lb
- Sell Pack Height 3.12 in
- Sell Pack Width 3.25 in
- Sell Pack Quantity 1 Each
- Sell Pack Length 13.75 in
- Product Weight 5.05 lb
- Product Diameter 3.12 in
- Body/Insulating Material PolyTube
- Connection/Terminal Type Blade
- Connection/Terminal Material Tin-Plated Copper
- Product Length 13.38 in
- Indication System Yes
- Indication System Type SmartSpot®
- AC Max I.R./Breaking Capacity: I1 200 kA
- Speed/Characteristic Time Delay
- ROHS Compliant Yes
- Ampere Rating 500 A
- Mounting Clip
- Fuse Class Class RK5
- Frequency 50/60 Hz
- Rated voltage DC UL 600 V
- Rated voltage AC UL 600 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TRS500RID on Advantage Electric Supply is $1,234.06. Order now.
