TRS90R Mersen Industrial Automation Components

Mersen TRS90R 1.31" x 7.88", 600 VAC/VDC, 50/60 Hz, 90 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Voltage, Current Limiting, Time Delay Fuse
Mersen

Part#:TRS90R

Manufacturer:Mersen

Alt. Part#:782001749101

Product Lifecycle:Active

In-stock parts: 2

Sep 19, 2024

1.31" x 7.88", 600 VAC/VDC, 50/60 Hz, 90 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Voltage, Current Limiting, Time Delay Fuse

About the manufacturer: Mersen is one of the manufacturers that offers Industrial Automation Components that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the TRS90R Mersen price in the box on the right side or send a quick quote.

Product Details

  • Terminal Type:
    Blade
  • Type:
    Class RK5
  • Time Delay:
    Voltage Rating
  • Series:
    TRS-R
  • Volts:
    600 VAC/DC
  • Length:
    7-7/8 Inch
  • Interrupting Rating:
    200 Kiloamp (AC)
  • Diameter:
    1-5/16 Inch
  • Shipping Height:
    2.00 In.
  • Amps:
    90 A
  • Approval:
    UL 248-12
  • Shipping Weight:
    0.60 lbs.
  • Characteristics:
    Time Delay
  • Shipping Width:
    2.00 In.
  • Shipping Length:
    8.00 In.
  • UPC:
    782001749101
  • Sell Pack Width
    6.66 in
  • Sell Pack Length
    8 in
  • Sell Pack Height
    1.38 in
  • Product Length
    7.88 in
  • Sell Pack Weight
    3.57 lb
  • Sell Pack Quantity
    5 Each
  • Product Diameter
    1.31 in
  • Product Weight
    0.68 lb
  • Body/Insulating Material
    PolyTube
  • Connection/Terminal Type
    Blade
  • Ampere Rating
    90 A
  • Rated voltage AC UL
    600 V
  • Mounting
    Clip
  • Speed/Characteristic
    Time Delay
  • AC Max I.R./Breaking Capacity: I1
    200 kA
  • Connection/Terminal Material
    Tin-Plated Copper
  • Frequency
    50/60 Hz
  • Rated voltage DC UL
    600 V
  • Fuse Class
    Class RK5

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents TRS90R Specs

TRS90R CAD Drawing:.pdf

This item can ship within 24h!

Manufacturer warranty

$11.75

Stock:

2

Select Qty:

$11.75

$11.75 each
