HP10J200 Mersen Fuses

Name: HP10J200
Brand: Mersen
Price: 554.69 USD
Availability: InStock

Part#:HP10J200

Manufacturer:Mersen

Category:Fuses

Alt. Part#:782001446000

Product Lifecycle:Active

In-stock parts: 2

Jan 17, 2025

HP10J200 Mersen Photovoltaic fuse gPV 1000VDC UL 200A With Blade For Clip or Bolted

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the HP10J200 Mersen price in the box on the right side or send a quick quote.

Product Details

Current Rating
200 A
Terminal Type
Blade
Type
Photovoltaic Fuses
Weight
0.25 lb
Voltage
600 VAC / 1000 VDC
UL Certification
YES
Trip Class
Photovoltaic
Country Of Origin
MX
Fuse Class
Special Purpose Fuses
Sell Pack Length
6 in
Sell Pack Height
1.69 in
Sell Pack Quantity
1 Each
Product Length
5.75 in
Product Weight
0.25 lb
Body/Insulating Material
GMG
Connection/Terminal Type
Blade
Product Diameter
1.63 in
Sell Pack Width
1.69 in
Sell Pack Weight
0.26 lb
Rated voltage AC UL
600 V

ROHS Compliant

Yes

Connection/Terminal Material

Brass

Rated voltage DC UL

1000 V

Mounting

Clip or Bolted

Speed/Characteristic

gPV

AC Max I.R./Breaking Capacity: I1

200 kA

Ampere Rating

200 A

Fuse Class

Photovoltaic

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

HP10J200 Description

HP10J200 Mersen Photovoltaic fuse gPV 1000VDC UL 200A With Blade For Clip or Bolted

Mersen’s HP10J photovoltaic (PV) fuse series is designed specifically for DC Recombiner Boxes in the protection of 1000VDC photovoltaic systems. Its robust construction makes it ideal for continuous temperature and current cycling withstand adding to system longevity. The 1000VDC rated HP10J designed for low minimum breaking capacity capabilities of 1.35 times the fuse rated current value, allows for safe circuit interruption under typical low fault current conditions produced by PV arrays. Protect your off-grid or grid tied PV system from unexpected ground faults and line faults using Mersen’s HelioProtection® fuse line.

*UL Listed to standard 2579 – Photovoltaic Fuses

*Smallest available footprint in the industry

*Enlarged mounting holes

*Low fault current interrupting capability

*Durable construction for enhanced system longevity

*Temperature cycle withstand capability

*Guaranteed operation at temperature extremes

*Blown fuse indicator options available (EI option)

*200A to 400A available in NH3 mounting

*Re-combiner box (sub-combiner, array combiner, master combiner) applications

*Inverter DC input

*Battery charge controllers
