2216120 Lapp Industrial Automation Components
Part#:2216120
Manufacturer:Lapp
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
2216120 Lapp - ÖLFLEX TRAY II CY 12G1.5 16/12C
Product Details
- Voltage 600 volts
- Stranding Class 5 Fine Wire
- Jacket Color Black
- Jacket Material Thermoplastic Polymer
- Operating Temperature -25 degrees celsius, 90 degrees celsius
- Gauge 16 american wire gauge
- Conductor Material Finely Stranded Bare Copper
- Insulation Material Nylon, PVC
- Bend Radius 6 X Cable Diameter
- APPLICATION Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used
- STANDARDS/APPROVALS UL Approved CSA Approved CE Approved
- UL STYLE / STANDARD UL 13 UL 1063 UL 1277 UL 1690 UL 2250
- WEIGHT LBS/MFT 287
- MANUFACTURER PART NUMBER 2216120
- ATTRIBUTES UL Oil Res I/IISunlight resistant Direct burialNFPA 79
- TRAY RATINGS UL ITC-ER UL PLTC-ER UL TC-ER
- STATIC TEMPERATURE RATING -40°F to +221°F-40°C to +105°C
- DYNAMIC TEMPERATURE RATING -13°F to +221°F -25°C to +105°C
- TEMPERATURE RANGE -13°F to +194°F -25°C to +90°C
- INSULATION PVC/Nylon
- VOLTAGE 600V
- NOMINAL OD (MM) 15.1
- NOMINAL OD (IN) 0.596
- JACKET MATERIAL Thermoplastic Polymer
- JACKET COLOR Black
- CONDUCTOR MATERIAL Bare copper
- NUMBER OF CONDUCTORS 12
- SERIES ÖLFLEX® TRAY II / TRAY II CY
- SHIELDING Braid
- CONDUCTOR STRANDING Stranded
- AWG/GAUGE 16
- CONDUCTOR COLOR Black with white printing plus green/yellow ground
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Cable, Flexible, ÖLFLEX TRAY II CY, 16 AWG/12C, Shielded, 600V, UL TC-ER, c(UL) CIC/TC FT4
