38.62.7.024.0050 Finder Control Relays

38.62.7.024.0050 on Advantage Electric Supply
Finder

Part#:38.62.7.024.0050

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

Product description

Finder 38.62.7.024.0050 is a relay designed for sensitive DC control applications, featuring a spring / push-in connection type. It supports a rated current of 8A at 30Vdc and 0.3A at 110Vdc, with a lower capacity of 0.12A at 220Vdc. This relay is configured with 2C/O or DPDT (Double Pole Double Throw) contacts, suitable for diverse switching needs. It operates within a temperature range of -40 to +70 degrees Celsius and offers a degree of protection classified as IP20, ensuring protection against solid objects larger than 12mm but not against water. The relay's coil voltage is rated at 24Vdc, with a rated impulse voltage (Uimp) of 250Vac and protection functions rated at 4kV. Its rated insulation voltage (Ui) stands at 14mm, and the net depth is designed for 2 Pole(s) integration. The relay is compatible with DIN rail or plug-in mounting options, features contacts coated with AgNi (Silver Nickel) for enhanced conductivity, and adheres to the EN61984 standard.

Product Details

  • Rated current
    8A (30Vdc; DC-1) 0.3A (110Vdc; DC-1) 0.12A (220Vdc; DC-1)
  • Mounting mode
    DIN rail Plug-in
  • Technology used in component
    sensitive DC control coil
  • Net Width (mm)
    14 mm
  • Rated voltage (AC)
    250Vac
  • Contacts type
    2C/O / DPDT (Double Pole Double Throw)
  • Contents
    (Socket) 93.52.7.024 (Relay) 41.52.9.024.0050
  • Main function
    Relay
  • Poles
    2 Pole(s)
  • Ambient air temperature for operation
    -40...+70 °C
  • Mounting location
    EN61984
  • Product series / family name
    38 series
  • Control Voltage (DC)
    24Vdc
  • Compliant with standard(s)
    cURus RINA IMQ CSA EAC CE EN 60664-1 EN 60715 EN 61810-1 EN 61984
  • Contacts coating
    AgNi (Silver Nickel)
  • Primary brand
    Finder
  • Connection type
    Spring / Push-in
  • Degree of protection
    IP20
  • Rated impulse voltage (Uimp)
    4 kV

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
