PULS YR80.241 is a redundancy unit belonging to the Y-series, designed with a built-in decoupling MOSFET for 1+1 or N+1 redundancy and ATEX approval. It operates with a supply voltage range of 8.4Vdc to 36.4Vdc, nominally at 12Vdc or 24Vdc, and can handle a rated current of 80A at 28Vdc. The unit features screw-clamp connections for secure installation and is designed for DIN rail mounting. It operates efficiently within an ambient air temperature range of -40 to +70°C. The YR80.241 has dimensions of W46mm x H124mm x D127mm and a net width of 46 mm. It is capable of a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 130A threshold at 6V. This model supports both series and parallel operation for 1+1 redundancy, utilizing two identical power supplies, and N+1 redundancy, using three or more identical power supplies, with all outputs isolated by diodes or other switching arrangements. The output voltage range is 12-28Vdc, nominally at 12Vdc or 24Vdc. Power dissipation/losses are rated at 2.7 W for 8.4-36.4Vdc input with 2x20A input and 3.6 W for 40A input. Its electrical durability is notable, with up to 1450000 hours at 25°C for 80A output with 2x20A input. The output stage capacitance is 320 µF, and the ripple is measured at 49mVpp across a frequency range of 20Hz to 20MHz at 50Ω.
Quick Quote
PULS CP5.241-S2 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It offers a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S2 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3W and 8.2W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 1800µF. Electrical durability ranges from 96000 to 775000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and push-in spring connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms.
Quick Quote
PULS CP5.242 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac inputs. Efficiency rates are 0.943 at 230Vac input, 0.935 at 120Vac input, and 0.927 at 100Vac input. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.242 provides protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 1800 µF. Electrical durability ranges from 96,000 to 775,000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with an enhanced DC input and a 20% power reserve, featuring a DC-OK relay contact output and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and offers an adjustable output voltage of 24Vdc-28Vdc. The unit is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W, with a hold time of 35ms.
Quick Quote
Power Supply, 480W, AC 100-240V | DC 110-150V input, 1 phase, 24-28Vdc output, 20A, monitoring display
Quick Quote
PULS CP10.241-R1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 39mm. The unit consumes 1.14A at 230Vac input and full output, 2.17A at 120Vac input and full output, and 2.63A at 100Vac input and full output, with a peak inrush current of 11A at 230Vac input and 7A at 120Vac input. It features an IP20 degree of protection and achieves an efficiency of 0.947 at 230Vac input. The dimensions of the CP10.241-R1 are W39mm x H124mm x D117mm. It has a start-up delay time of 240-300ms for 100-230Vac input and a rise time of 30ms to 75ms depending on the load capacitance. The power supply unit includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or redundancy. It is equipped with a built-in MOSFET as a decoupling device to prevent a faulty unit from affecting others in the system. The unit can handle back-feeding loads up to 35V without malfunctioning. Power dissipation losses are 13.4W at 230Vac input and full output load. The output stage capacitance is 4400µF, and the electrical durability ranges from 47,000 to 531,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series and features spring-clamp connections, a supply voltage range of 85Vac-264Vac for AC and 88Vdc-180Vdc for DC, with a rated current of 12A at 48Vdc up to +45°C. The rated power is 288W at -25 to +45°C, and the output voltage is adjustable between 24Vdc and 25.4Vdc, with a hold time of 37ms at 120/230Vac input.
Quick Quote
DC/DC Converter, 200W, DC 110V input, 24-28Vdc output, 8.3A, railway applications
Quick Quote
Power Supply, 120W, AC 200-240V input, 1 phase, 24-28Vdc output, 5A, DC-OK relay contact
Quick Quote
PULS CP5.241-S1 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S1 provides protection functions such as output overvoltage and overload/short-circuit current protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The unit's output stage capacitance is 1800 µF, and it demonstrates electrical durability across various conditions, with the longest lifespan reaching up to 775000 hours. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve and includes a DC-OK relay contact output. It features spring-clamp connections and supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc. The output voltage is adjustable between 24Vdc and 28Vdc, and the unit offers a hold time of 35ms. It is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W.
Quick Quote
PULS UB10.241 is an Uninterruptible Power Supply (UPS) control module from the UB-series, featuring an external battery before time limiter and end-of-charge voltage control with a 50% power reserve and a green status LED. It is housed in aluminium and utilizes spring-clamp connections for connectivity. The dimensions of this unit are W49mm x H124mm x D117mm. It operates on a supply voltage range of 22.5Vdc to 30Vdc, with a nominal 24Vdc, and supports a rated current of 10A at 22.5Vdc and 15A in buffer mode for less than 5 seconds at full output voltage. The output in normal mode is 15A, and in buffer mode, it can deliver 10A/15A (360W). Designed for DIN rail mounting, it can operate in ambient air temperatures ranging from -25 to +70°C. The current consumption is 1.1A at a 24Vdc input, and it is designed for DC networks. Visual position indicators include Ready, Buffering, Inhibit, and Replace Battery. It features protection functions against output overvoltage (32Vdc typical, 35Vdc maximum) and overload/short-circuit conditions, with a minimum of 17.9A and a maximum of 21A at load impedance. It is not suitable for parallel use to increase output power but can be paralleled for 1+1 redundancy. The output voltage is regulated at 22.5Vdc in buffer mode with a 23Vdc turn-ON. The efficiency is rated at 0.978 with a 24Vdc input. The rated power is 360W at 24Vdc and 240W/360W in buffer mode. Power dissipation/losses are 2.9W with a 24Vdc input at 0A output current and 5.5W at 10A output current. Ripple is maintained at 20mVpp from 20Hz to 20MHz at 50Ω. The electrical durability is rated at 137400 hours at 40°C with a 10A output and 24Vdc input, and 15 years/131400 hours at both 40°C with a 5A output and 25°C with a 10A output, all at 24Vdc input.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| YR80.241 PULS YR80.241 is a redundancy unit belonging to the Y-series, designed with a built-in decoupling MOSFET for 1+1 or N+1 redundancy and ATEX approval. It operates with a supply voltage range of 8.4Vdc to 36.4Vdc, nominally at 12Vdc or 24Vdc, and can handle a rated current of 80A at 28Vdc. The unit features screw-clamp connections for secure installation and is designed for DIN rail mounting. It operates efficiently within an ambient air temperature range of -40 to +70°C. The YR80.241 has dimensions of W46mm x H124mm x D127mm and a net width of 46 mm. It is capable of a peak inrush current consumption of 1500A and offers protection functions including short-circuit protection with a 130A threshold at 6V. This model supports both series and parallel operation for 1+1 redundancy, utilizing two identical power supplies, and N+1 redundancy, using three or more identical power supplies, with all outputs isolated by diodes or other switching arrangements. The output voltage range is 12-28Vdc, nominally at 12Vdc or 24Vdc. Power dissipation/losses are rated at 2.7 W for 8.4-36.4Vdc input with 2x20A input and 3.6 W for 40A input. Its electrical durability is notable, with up to 1450000 hours at 25°C for 80A output with 2x20A input. The output stage capacitance is 320 µF, and the ripple is measured at 49mVpp across a frequency range of 20Hz to 20MHz at 50Ω. | Puls | Quick Quote | ||
| CP5.241-S2 PULS CP5.241-S2 is a DIN rail mounting power supply unit with an aluminium housing, designed for an ambient air temperature range of -25 to +70°C. It features a net width of 32mm and dimensions of W32mm x H124mm x D102mm. This unit has a current consumption of 7A peak max inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It offers a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S2 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3W and 8.2W for 230Vac and 120Vac inputs at full load, respectively. The output stage capacitance is 1800µF. Electrical durability ranges from 96000 to 775000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve, DC-OK relay contact output, and push-in spring connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and a rated power of 120W. The output voltage is adjustable from 24Vdc to 28Vdc, with a 200mV turn-ON overshoot and a hold time of 35ms. | Puls | Quick Quote | ||
| CP5.242 PULS CP5.242 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac inputs. Efficiency rates are 0.943 at 230Vac input, 0.935 at 120Vac input, and 0.927 at 100Vac input. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.242 provides protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The output stage capacitance is 1800 µF. Electrical durability ranges from 96,000 to 775,000 hours under various conditions. Ripple is specified at 50mVpp. This AC/DC power supply unit, part of the CP-series, is designed with an enhanced DC input and a 20% power reserve, featuring a DC-OK relay contact output and screw-clamp connections. It supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc, and offers an adjustable output voltage of 24Vdc-28Vdc. The unit is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W, with a hold time of 35ms. | Puls | Quick Quote | ||
| CP20.248 Power Supply, 480W, AC 100-240V | DC 110-150V input, 1 phase, 24-28Vdc output, 20A, monitoring display | Puls | Quick Quote | ||
| CP10.241-R1 PULS CP10.241-R1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 39mm. The unit consumes 1.14A at 230Vac input and full output, 2.17A at 120Vac input and full output, and 2.63A at 100Vac input and full output, with a peak inrush current of 11A at 230Vac input and 7A at 120Vac input. It features an IP20 degree of protection and achieves an efficiency of 0.947 at 230Vac input. The dimensions of the CP10.241-R1 are W39mm x H124mm x D117mm. It has a start-up delay time of 240-300ms for 100-230Vac input and a rise time of 30ms to 75ms depending on the load capacitance. The power supply unit includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or redundancy. It is equipped with a built-in MOSFET as a decoupling device to prevent a faulty unit from affecting others in the system. The unit can handle back-feeding loads up to 35V without malfunctioning. Power dissipation losses are 13.4W at 230Vac input and full output load. The output stage capacitance is 4400µF, and the electrical durability ranges from 47,000 to 531,000 hours depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit is part of the CP-series and features spring-clamp connections, a supply voltage range of 85Vac-264Vac for AC and 88Vdc-180Vdc for DC, with a rated current of 12A at 48Vdc up to +45°C. The rated power is 288W at -25 to +45°C, and the output voltage is adjustable between 24Vdc and 25.4Vdc, with a hold time of 37ms at 120/230Vac input. | Puls | Quick Quote | ||
| QS10.241-60 DC/DC Converter, 200W, DC 110V input, 24-28Vdc output, 8.3A, railway applications | Puls | Quick Quote | ||
| PIC120.242C Power Supply, 120W, AC 200-240V input, 1 phase, 24-28Vdc output, 5A, DC-OK relay contact | Puls | Quick Quote | ||
| CP5.241-S1 PULS CP5.241-S1 is a power supply unit designed for DIN rail mounting, featuring an aluminium housing and dimensions of W32mm x H124mm x D102mm. It operates within an ambient air temperature range of -25 to +70°C and has a net width of 32 mm. The unit offers a current consumption of 7A peak max. inrush at both 230Vac and 120Vac input, with efficiencies of 0.943, 0.935, and 0.927 at 230Vac, 120Vac, and 100Vac inputs respectively. It includes a time delay of 380-420ms for start-up and rise times of 80ms and 100ms under specified conditions. The CP5.241-S1 provides protection functions such as output overvoltage and overload/short-circuit current protection, with the capability for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation/losses are 7.3 W and 8.2 W for 230Vac and 120Vac inputs at full output load, respectively. The unit's output stage capacitance is 1800 µF, and it demonstrates electrical durability across various conditions, with the longest lifespan reaching up to 775000 hours. The ripple is specified at 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series, is designed with a 20% power reserve and includes a DC-OK relay contact output. It features spring-clamp connections and supports a supply voltage range of 85Vac-264Vac for AC and 110Vdc-180Vdc for DC, with a rated current of 5A at 24Vdc. The output voltage is adjustable between 24Vdc and 28Vdc, and the unit offers a hold time of 35ms. It is suitable for single-phase (1AC) or DC networks and provides a rated power of 120W. | Puls | Quick Quote | ||
| QS10.241-NPI Dimension Q-Series Power Supply, 240W | Puls | Quick Quote | ||
| UB10.241 PULS UB10.241 is an Uninterruptible Power Supply (UPS) control module from the UB-series, featuring an external battery before time limiter and end-of-charge voltage control with a 50% power reserve and a green status LED. It is housed in aluminium and utilizes spring-clamp connections for connectivity. The dimensions of this unit are W49mm x H124mm x D117mm. It operates on a supply voltage range of 22.5Vdc to 30Vdc, with a nominal 24Vdc, and supports a rated current of 10A at 22.5Vdc and 15A in buffer mode for less than 5 seconds at full output voltage. The output in normal mode is 15A, and in buffer mode, it can deliver 10A/15A (360W). Designed for DIN rail mounting, it can operate in ambient air temperatures ranging from -25 to +70°C. The current consumption is 1.1A at a 24Vdc input, and it is designed for DC networks. Visual position indicators include Ready, Buffering, Inhibit, and Replace Battery. It features protection functions against output overvoltage (32Vdc typical, 35Vdc maximum) and overload/short-circuit conditions, with a minimum of 17.9A and a maximum of 21A at load impedance. It is not suitable for parallel use to increase output power but can be paralleled for 1+1 redundancy. The output voltage is regulated at 22.5Vdc in buffer mode with a 23Vdc turn-ON. The efficiency is rated at 0.978 with a 24Vdc input. The rated power is 360W at 24Vdc and 240W/360W in buffer mode. Power dissipation/losses are 2.9W with a 24Vdc input at 0A output current and 5.5W at 10A output current. Ripple is maintained at 20mVpp from 20Hz to 20MHz at 50Ω. The electrical durability is rated at 137400 hours at 40°C with a 10A output and 24Vdc input, and 15 years/131400 hours at both 40°C with a 5A output and 25°C with a 10A output, all at 24Vdc input. | Puls | Quick Quote | ||
