Pilz PILZ-632360 is a safety light curtain designed for hand protection, detecting opaque objects as small as 30mm. This receiver part of the system operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 300mm. It features a robust design with an aluminium housing, zinc end cap, and a PC front screen, ensuring durability. The device connects via 5-pin M12 connectors for both emitter and receiver, falling under the PSEN opII4H sub-range. With dimensions of 304mm in height, 35mm in width, and 40mm in depth, it supports a maximum cable length of 50m. The safety light curtain operates within a sensing distance of 0.2m to 18m and uses infrared LED light with a wavelength of 850 nm. It has a supply voltage requirement of 18-28.8Vdc (24Vdc nominal) and consumes a maximum of 1.5W (emitter) and 2.5W (receiver without load). The device is IP65 rated, indicating protection against dust ingress and low-pressure water jets from any direction. It features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 5.9ms with beam coding and 11.7ms without. The ambient air temperature for storage is specified as -25 to +70°C.
Quick Quote
Pilz PILZ-632349 is a safety light curtain designed for finger protection, capable of detecting 14mm opaque objects. It operates within an ambient air temperature range of -10 to +60°C and has a net height of 1354 mm. This robust type receiver part of the PSEN opII3F sub-range features a 5-pin M12 connector for both emitter and receiver, ensuring a secure connection. With a protective height of 1350mm and an IP65 degree of protection, it is well-suited for demanding environments. The device is powered by a supply voltage of 18-28.8Vdc (24Vdc nom.) and is constructed from an aluminium housing with zinc end caps and a PC front screen. It supports a maximum cable length of 50m and has a net width of 35 mm. The sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is max 1.5 W for the emitter and max 2.5 W for the receiver without load. The net depth is 40 mm. It also features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 16.1ms with beam coding and 91.4ms. The device can be stored in temperatures ranging from -25 to +70°C.
Quick Quote
Pilz PILZ-632348 is a safety light curtain designed for finger protection, capable of detecting opaque objects as small as 14mm. This robust type receiver part operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1650mm. It features a 5-pin M12 connector for both emitter and receiver connections, falling under the PSEN opII3F sub-range. With dimensions of 1654mm in height, 35mm in width, and 40mm in depth, it is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. The device operates on a supply voltage of 18-28.8Vdc, with a nominal 24Vdc, and supports a maximum cable length of 50m. Its sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is maxed at 1.5W for the emitter and 2.5W for the receiver without load. Additionally, it features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 18.7ms with beam coding and 91.4ms. The device is also designed to withstand storage temperatures ranging from -25 to +70°C.
Quick Quote
Pilz PILZ-632344 is a safety light curtain designed for finger protection, capable of detecting opaque objects as small as 14mm. This receiver part of the robust type light curtain operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 900mm. It features a 5-pin M12 connector for both emitter and receiver connections, falling under the PSEN opII3F sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. It operates on a supply voltage of 18-28.8Vdc, with a nominal voltage of 24Vdc, and has a maximum power consumption of 1.5W for the emitter and 2.5W for the receiver without load. The PILZ-632344 has a net height of 904mm, a width of 35mm, and a depth of 40mm, with a maximum cable length of 50m. Its sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. The light curtain also features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 12.3ms with beam coding and 42.3ms. It is designed for storage in ambient air temperatures ranging from -25 to +70°C.
Quick Quote
Pilz PILZ-632342 is a safety light curtain designed for finger protection, capable of detecting opaque objects as small as 14mm. This receiver part of the robust type light curtain operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 750mm. It features a 5-pin M12 connector for both emitter and receiver connections, falling under the PSEN opII3F sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. It operates on a supply voltage of 18-28.8Vdc, with a nominal voltage of 24Vdc, and has a maximum cable length of 50m. The net dimensions are 754mm in height, 35mm in width, and 40mm in depth. This safety light curtain offers a sensing distance ranging from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is max 1.5 W for the emitter and max 2.5 W for the receiver without load. It also includes 2 digital outputs (100mA) for the receiver OSSD outputs, with a response time of 11ms with beam coding and 42.3ms. The device is also designed to withstand storage temperatures ranging from -25 to +70°C.
Quick Quote
Pilz PILZ-632329 is a safety light curtain designed for hand protection, detecting opaque objects as small as 30mm. This robust type receiver part operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1800mm. It features a 5-pin M12 connector for both emitter and receiver, falling under the PSEN opII3H sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring an IP65 degree of protection against dust and water. It operates on a supply voltage of 18-28.8Vdc, with a nominal 24Vdc, and can accommodate a maximum cable length of 50m. The net dimensions are 1804mm in height, 35mm in width, and 40mm in depth. It offers a sensing distance from 0.2m to 18m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is maximized at 1.5W for the emitter and 2.5W for the receiver without load. The device also includes 2 digital outputs (100mA) for the receiver OSSD outputs and has a response time ranging from 12.3ms with beam coding to 22.3ms. It is designed to operate within a storage temperature range of -25 to +70°C.
Quick Quote
Pilz PILZ-632328 is a safety light curtain designed for hand protection, capable of detecting opaque objects as small as 30mm. This robust type receiver part operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1500mm. It features a 5-pin M12 connector for both emitter and receiver, falling under the PSEN opII3H sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring durability. Dimensions include a net height of 1504mm, width of 35mm, and depth of 40mm. It supports a sensing distance from 0.2m to 18m with an infrared LED light source at a wavelength of 850 nm. The safety light curtain operates on a supply voltage of 18-28.8Vdc (24Vdc nominal) and has a maximum power consumption of 1.5W for the emitter and 2.5W for the receiver without load. It is designed to withstand storage temperatures ranging from -25 to +70°C. Additionally, it features two digital outputs (100mA) for the receiver OSSD outputs and offers a response time of 11ms with beam coding and 22.3ms without, all within an IP65 degree of protection.
Quick Quote
Pilz PILZ-632325 is a safety light curtain designed for hand protection, detecting opaque objects as small as 30mm. It operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1050mm. This robust type receiver part features a 5-pin M12 connector for both emitter and receiver, falling under the PSEN opII3H sub-range. With dimensions of 1054mm in height, 35mm in width, and 40mm in depth, it is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. The device supports a supply voltage of 18-28.8Vdc, with a nominal 24Vdc, and can accommodate a maximum cable length of 50m. Its sensing distance ranges from 0.2m to 18m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is maximized at 1.5W for the emitter and 2.5W for the receiver without load. Additionally, it features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 9.1ms with beam coding and 22.3ms otherwise. The device is also designed to withstand storage temperatures ranging from -25 to +70°C.
Quick Quote
Pilz PILZ-632284 is a safety light curtain designed for finger protection, capable of detecting 14mm opaque objects. It operates within an ambient air temperature range of -10 to +60°C and has a net height of 904 mm. This robust type emitter part of the PSEN opII4F sub-range features a 5-pin M12 connector for both emitter and receiver, ensuring a secure connection. With a protective height of 900mm and an IP65 degree of protection, it is well-suited for demanding environments. The device requires a supply voltage of 18-28.8Vdc, with 24Vdc nominal, and is constructed from an aluminium housing with zinc end caps and a PC front screen. It supports a maximum cable length of 50m and has a net width of 35 mm. The sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm for operation. Power consumption is maximized at 1.5 W for the emitter and 2.5 W for the receiver without load. The net depth is 40 mm, and it can be stored in temperatures ranging from -25 to +70°C. It features 2 x digital outputs (100mA) for the receiver OSSD outputs and has a response time of 12.3ms with beam coding and 42.3ms without.
Quick Quote
Pilz PILZ-632271 is a safety light curtain designed for finger protection, capable of detecting 14mm opaque objects. This emitter part of the robust type safety light curtain operates within an ambient air temperature range of -10 to +60°C and has a net height of 229 mm. It features a 5-pin M12 connector for both the emitter and receiver, falling under the PSEN opII4F sub-range. With a protective height of 150mm and an IP65 degree of protection, it is suited for various industrial environments. The supply voltage required is 18-28.8Vdc, with a nominal 24Vdc. Constructed with an aluminium housing, zinc end cap, and PC front screen, it ensures durability. The maximum cable length is 50m, and it has a net width of 35 mm. Its sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is max 1.5 W for the emitter and max 2.5 W for the receiver without load. The net depth is 40 mm. It can operate within an ambient air temperature range for storage of -25 to +70°C. It includes 2 x digital outputs (100mA) for the receiver OSSD outputs, with a response time of 5.9ms with beam coding and 11.7ms without.
Quick Quote
| Item | Manufacturer | Price | Stock | Delivery | |
|---|---|---|---|---|---|
| PILZ-632360 Pilz PILZ-632360 is a safety light curtain designed for hand protection, detecting opaque objects as small as 30mm. This receiver part of the system operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 300mm. It features a robust design with an aluminium housing, zinc end cap, and a PC front screen, ensuring durability. The device connects via 5-pin M12 connectors for both emitter and receiver, falling under the PSEN opII4H sub-range. With dimensions of 304mm in height, 35mm in width, and 40mm in depth, it supports a maximum cable length of 50m. The safety light curtain operates within a sensing distance of 0.2m to 18m and uses infrared LED light with a wavelength of 850 nm. It has a supply voltage requirement of 18-28.8Vdc (24Vdc nominal) and consumes a maximum of 1.5W (emitter) and 2.5W (receiver without load). The device is IP65 rated, indicating protection against dust ingress and low-pressure water jets from any direction. It features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 5.9ms with beam coding and 11.7ms without. The ambient air temperature for storage is specified as -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632349 Pilz PILZ-632349 is a safety light curtain designed for finger protection, capable of detecting 14mm opaque objects. It operates within an ambient air temperature range of -10 to +60°C and has a net height of 1354 mm. This robust type receiver part of the PSEN opII3F sub-range features a 5-pin M12 connector for both emitter and receiver, ensuring a secure connection. With a protective height of 1350mm and an IP65 degree of protection, it is well-suited for demanding environments. The device is powered by a supply voltage of 18-28.8Vdc (24Vdc nom.) and is constructed from an aluminium housing with zinc end caps and a PC front screen. It supports a maximum cable length of 50m and has a net width of 35 mm. The sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is max 1.5 W for the emitter and max 2.5 W for the receiver without load. The net depth is 40 mm. It also features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 16.1ms with beam coding and 91.4ms. The device can be stored in temperatures ranging from -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632348 Pilz PILZ-632348 is a safety light curtain designed for finger protection, capable of detecting opaque objects as small as 14mm. This robust type receiver part operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1650mm. It features a 5-pin M12 connector for both emitter and receiver connections, falling under the PSEN opII3F sub-range. With dimensions of 1654mm in height, 35mm in width, and 40mm in depth, it is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. The device operates on a supply voltage of 18-28.8Vdc, with a nominal 24Vdc, and supports a maximum cable length of 50m. Its sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is maxed at 1.5W for the emitter and 2.5W for the receiver without load. Additionally, it features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 18.7ms with beam coding and 91.4ms. The device is also designed to withstand storage temperatures ranging from -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632344 Pilz PILZ-632344 is a safety light curtain designed for finger protection, capable of detecting opaque objects as small as 14mm. This receiver part of the robust type light curtain operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 900mm. It features a 5-pin M12 connector for both emitter and receiver connections, falling under the PSEN opII3F sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. It operates on a supply voltage of 18-28.8Vdc, with a nominal voltage of 24Vdc, and has a maximum power consumption of 1.5W for the emitter and 2.5W for the receiver without load. The PILZ-632344 has a net height of 904mm, a width of 35mm, and a depth of 40mm, with a maximum cable length of 50m. Its sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. The light curtain also features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 12.3ms with beam coding and 42.3ms. It is designed for storage in ambient air temperatures ranging from -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632342 Pilz PILZ-632342 is a safety light curtain designed for finger protection, capable of detecting opaque objects as small as 14mm. This receiver part of the robust type light curtain operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 750mm. It features a 5-pin M12 connector for both emitter and receiver connections, falling under the PSEN opII3F sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. It operates on a supply voltage of 18-28.8Vdc, with a nominal voltage of 24Vdc, and has a maximum cable length of 50m. The net dimensions are 754mm in height, 35mm in width, and 40mm in depth. This safety light curtain offers a sensing distance ranging from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is max 1.5 W for the emitter and max 2.5 W for the receiver without load. It also includes 2 digital outputs (100mA) for the receiver OSSD outputs, with a response time of 11ms with beam coding and 42.3ms. The device is also designed to withstand storage temperatures ranging from -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632329 Pilz PILZ-632329 is a safety light curtain designed for hand protection, detecting opaque objects as small as 30mm. This robust type receiver part operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1800mm. It features a 5-pin M12 connector for both emitter and receiver, falling under the PSEN opII3H sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring an IP65 degree of protection against dust and water. It operates on a supply voltage of 18-28.8Vdc, with a nominal 24Vdc, and can accommodate a maximum cable length of 50m. The net dimensions are 1804mm in height, 35mm in width, and 40mm in depth. It offers a sensing distance from 0.2m to 18m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is maximized at 1.5W for the emitter and 2.5W for the receiver without load. The device also includes 2 digital outputs (100mA) for the receiver OSSD outputs and has a response time ranging from 12.3ms with beam coding to 22.3ms. It is designed to operate within a storage temperature range of -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632328 Pilz PILZ-632328 is a safety light curtain designed for hand protection, capable of detecting opaque objects as small as 30mm. This robust type receiver part operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1500mm. It features a 5-pin M12 connector for both emitter and receiver, falling under the PSEN opII3H sub-range. The device is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring durability. Dimensions include a net height of 1504mm, width of 35mm, and depth of 40mm. It supports a sensing distance from 0.2m to 18m with an infrared LED light source at a wavelength of 850 nm. The safety light curtain operates on a supply voltage of 18-28.8Vdc (24Vdc nominal) and has a maximum power consumption of 1.5W for the emitter and 2.5W for the receiver without load. It is designed to withstand storage temperatures ranging from -25 to +70°C. Additionally, it features two digital outputs (100mA) for the receiver OSSD outputs and offers a response time of 11ms with beam coding and 22.3ms without, all within an IP65 degree of protection. | Pilz | Quick Quote | ||
| PILZ-632325 Pilz PILZ-632325 is a safety light curtain designed for hand protection, detecting opaque objects as small as 30mm. It operates within an ambient air temperature range of -10 to +60°C and offers a protective height of 1050mm. This robust type receiver part features a 5-pin M12 connector for both emitter and receiver, falling under the PSEN opII3H sub-range. With dimensions of 1054mm in height, 35mm in width, and 40mm in depth, it is encased in an aluminium housing with zinc end caps and a PC front screen, ensuring a degree of protection rated at IP65. The device supports a supply voltage of 18-28.8Vdc, with a nominal 24Vdc, and can accommodate a maximum cable length of 50m. Its sensing distance ranges from 0.2m to 18m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is maximized at 1.5W for the emitter and 2.5W for the receiver without load. Additionally, it features two digital outputs (100mA) for the receiver OSSD outputs and has a response time of 9.1ms with beam coding and 22.3ms otherwise. The device is also designed to withstand storage temperatures ranging from -25 to +70°C. | Pilz | Quick Quote | ||
| PILZ-632284 Pilz PILZ-632284 is a safety light curtain designed for finger protection, capable of detecting 14mm opaque objects. It operates within an ambient air temperature range of -10 to +60°C and has a net height of 904 mm. This robust type emitter part of the PSEN opII4F sub-range features a 5-pin M12 connector for both emitter and receiver, ensuring a secure connection. With a protective height of 900mm and an IP65 degree of protection, it is well-suited for demanding environments. The device requires a supply voltage of 18-28.8Vdc, with 24Vdc nominal, and is constructed from an aluminium housing with zinc end caps and a PC front screen. It supports a maximum cable length of 50m and has a net width of 35 mm. The sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm for operation. Power consumption is maximized at 1.5 W for the emitter and 2.5 W for the receiver without load. The net depth is 40 mm, and it can be stored in temperatures ranging from -25 to +70°C. It features 2 x digital outputs (100mA) for the receiver OSSD outputs and has a response time of 12.3ms with beam coding and 42.3ms without. | Pilz | Quick Quote | ||
| PILZ-632271 Pilz PILZ-632271 is a safety light curtain designed for finger protection, capable of detecting 14mm opaque objects. This emitter part of the robust type safety light curtain operates within an ambient air temperature range of -10 to +60°C and has a net height of 229 mm. It features a 5-pin M12 connector for both the emitter and receiver, falling under the PSEN opII4F sub-range. With a protective height of 150mm and an IP65 degree of protection, it is suited for various industrial environments. The supply voltage required is 18-28.8Vdc, with a nominal 24Vdc. Constructed with an aluminium housing, zinc end cap, and PC front screen, it ensures durability. The maximum cable length is 50m, and it has a net width of 35 mm. Its sensing distance ranges from 0.2m to 8m, utilizing infrared LED light with a wavelength of 850 nm. Power consumption is max 1.5 W for the emitter and max 2.5 W for the receiver without load. The net depth is 40 mm. It can operate within an ambient air temperature range for storage of -25 to +70°C. It includes 2 x digital outputs (100mA) for the receiver OSSD outputs, with a response time of 5.9ms with beam coding and 11.7ms without. | Pilz | Quick Quote | ||
