35036EP3G449TS-W22 WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  460 V
• Output Rating
  350 HP
• Rated Speed
  3565 rpm
• Flange Type
  Without
• Flange
  Without
• Synchronous speed
  3600 rpm
• Voltage
  460 V
• Number of poles
  2
• Output rating
  350 HP
• Standard
  NEMA MG-1
• Approx. weight³
  2945 lb
• Rotation¹
  Both (CW and CCW)
• Terminal box¹
  Left position
• Mounting
  F-1
• Ambient temperature
  -20°C to +40°C
• Duty Cycle
  Cont.(S1)
• Enclosure
  IC411 - TEFC
• Degree of Protection
  IP55
• Altitude
  1000 m.a.s.l.
Starting Method
Direct On Line
Temperature rise
80 K
Service factor
1.15
Locked rotor time
18s (cold) 10s (hot)
Insulation Class
F
Locked rotor torque
229 %
Design
B
Moment of inertia (J)
68.1 sq.ft.lb
Rated torque
516 ft.lb
No load current
75.0 A
Breakdown torque
240 %
LRC
6.5x(Code G)
L. R. Amperes
2470 A
Rated voltage
460 V
Slip
0.97 %
Frame
447/9TS
Rated speed
3565 rpm
Output
350 HP (260 kW)
Rated current
380 A
Number of Poles
2
Frequency
60 Hz
