04036OT3E286TS-W40 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 230/460 V
- Output Rating 40 HP
- Rated Speed 3540 rpm
- Flange Type Without
- Synchronous speed 3600 rpm
- Terminal box¹ Left position
- Voltage 230/460//380 V
- Flange Without
- Number of poles 2
- Output rating 40 HP
- Standard NEMA MG-1
- Rotation¹ Both (CW and CCW)
- Mounting F-1
- Noise level² 73.0 dB(A)
- Enclosure IC01 - ODP
- Approx. weight³ 339 lb
- Altitude 1000 m.a.s.l.
- Degree of Protection IP23
- Starting Method Direct On Line
- Ambient temperature -20°C to +40°C
- Duty Cycle Cont.(S1)
- Service factor 1.25
- Temperature rise 80 K
- Insulation Class F
- Moment of inertia (J) 2.02 sq.ft.lb
- Design B
- Locked rotor time 14s (cold) 8s (hot)
- Breakdown torque 240 %
- Rated torque 59.3 ft.lb
- Locked rotor torque 190 %
- L. R. Amperes 609/304 A
- No load current 30.8/15.4 A
- LRC 6.5x(Code G)
- Rated current 93.7/46.8 A
- Rated voltage 230/460 V
- Slip 1.67 %
- Number of Poles 2
- Frequency 60 Hz
- Rated speed 3540 rpm
- Output 40 HP (30 kW)
- Frame 284/6TS
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
