ZF 232-11 Schmersal Electronic Components

Name: ZF 232-11
Brand: Schmersal

Part#:ZF 232-11

Alt. Part#:151181537

Manufacturer:Schmersal

Category:Electronic Components

Product Lifecycle:Active

Product description

Foot switch; 2 Contacts; Also available as safety foot switch; Low operating height of pedal; Cable entry M 20 x 1.5; High level of stability; Metal enclosure; single-pedal types

Product Details

Switching element
NO contact, NC contact
Switching principle
Snap action
Rated impulse withstand voltage Uimp
6 kV
Utilisation category AC-15
230 VAC
Utilisation category DC-13
1 A
Thermal test current
10 A
Degree of protection
IP65 to EN 60529
Rated insulation voltage Ui
500 V
Ambient temperature, maximum
+70 °C
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Height
189 mm
Depth
274 mm
Terminal Connector
Screw connection
Material of the protective shield
Aluminium
Number of shutters
1
Material of the cover
Aluminium
Width
170 mm
Mechanical life, minimum
1,000,000 Operations
Standards
IEC 60947-5-1, EN 60947-5-1, DIN VDE 0660-200
Enclosure coating material
powder-coated

Gross weight

1,030 g

Ambient temperature, minimum

-25 °C

Cable section, maximum

1 x 2.5 mm²

Number of openers

Material of the pedal

Glass-fibre, reinforced thermoplastic

Probing possible

Yes

Colour of the housing

RAL 9006 (White aluminum)

Enclosure material

Aluminium

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
