RSS21S2 Schmersal Key Switches
Part#:RSS21S2
Manufacturer:Schmersal
Alt. Part#:101195362
Product Lifecycle:Active
Get a quick Quote!
RSS21S2 Schmersal - Keyed Selector Switch
About the manufacturer: Schmersal is one of the manufacturers that offers Key Switches that you can order at Advantage Electric Supply site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the RSS21S2 Schmersal price in the box on the right side or send a quick quote.
Product Details
- Restistance to shock 50 g
- Spacing 50 x 60 mm
- Ambient temperature, minimum +0 °C
- Ambient temperature, maximum +75 °C
- Degree of protection IP65
- Thickness of the front panel, maximum 6 mm
- Thickness, of the front panel, minimum 1 mm
- diameters for the cylinder lock 22 mm
- Diameter hole 22.3 mm
- Height with key inserted 58 mm
- Diameter hole, with tolerance indication 22.3 + 0.4 mm
- Switching angle, right 90 °
- Tightening torque of the screw 0.6 Nm
- Diameter of the front ring 39.5 mm
- Mounting Mounting flange EFM
- Mechanical life, minimum 300,000 Operations
- Diameter total 39.5 mm
- Latching position right
- Fully insulated Yes
- Number of switch positions 2
- Key withdrawal position Position I
- Number of plunger 1
- Unlocking Rotating unlatcher
- Gross weight 100 g
- Latching Yes
- Sealing type Membrane, Lip gaskets, Form seals
- Installation conditions (mechanical) arbitrarily
- Material of the cylinder lock Steel
- Material of the front ring Aluminium
- Colour of the front ring Silver
- Colour of the cylinder lock Silver
- Standards EN 60947-5-1, IEC/EN 60947-1
- Versions Key - Selector switch - Front plate mounting
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
RSS21S2 Description
RSS21S2 Schmersal - Keyed Selector Switch
Related documents RSS21S2 Specs
