35680804D SAB VFD Cables
Part#:35680804D
Manufacturer:SAB
Product Lifecycle:Active
Get a quick Quote!
VFD XLPE TR D - 8 AWG/4c, oil resistant XLPE insulated VFD cable drain wire, foil and braid shield, UL, CSA, WTTC, TC-ER, CE, RoHS
About the manufacturer: SAB is one of the manufacturers that offers VFD Cables that you can order at Advantage Electric Supply site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.
Check out the 35680804D SAB price in the box on the right side or send a quick quote.
Product Details
- Direct Burial YES
- Temperature range -40°C to +105°C
- Weight 281.23 g
- Insulation type XLPE
- Gauge 8 AWG
- Shielded No
- UV Resistant YES
- UOM ft
- Voltage 1000
- Halogen Free NO
- Movement Type Stationary/Flexible
- Cable configuration 8 AWG/4c
- CSA Certification YES
- Oil Resistant Yes
- Application Motor & Drives
- UL Certification YES
- Stranding type tinned copper strands, class K
- Color Black
- CE Certification YES
- Number of conductors 4
- Approvals UL TC-ER, UL WTTC, c(UL) CIC-TC, CSA AWM, CE, RoHS
- Chemical Resistant NO
- Submersible NO
- RoHS YES
- Outside diameter (OD) 0.886 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
35680804D Description
SAB 35680804D VFD Cable is part of VFD XLPE TR D product family, and is designed for Motor & Drives applications. This cable is 8 AWG with 4 conductors, and 8 AWG/4c cable configuration. Featuring Black color jacket, XLPE insulation, and tinned copper strands, class K stranding. It has 0.886 in OD, constructed to support Stationary/Flexible movement type, and rated for 1000 volts. This Motor & Drives cable can operate in -40°C to +105°C temperature range, it is oil resistant, UV resistand, rated for direct burial, and has following approvals: UL TC-ER, UL WTTC, c(UL) CIC-TC, CSA AWM, CE, RoHS. This cable is an excellent choice for Motor & Drives applications.
Related documents 35680804D Specs
