W089489 Mersen Fuses
Product Details
- Current Rating 32 A
- Terminal Type Ferrule
- Weight 99.88 g
- UL Certification YES
- Trip Class High Speed
- Country Of Origin FR
- Fuse Class Semiconductor
- Sell Pack Height 1.18 in
- Sell Pack Length 10.63 in
- Sell Pack Width 5.51 in
- Product Weight 0.22 lb
- Product Diameter 0.81 in
- Sell Pack Weight 2.205 lb
- Body/Insulating Material Ceramic
- Product Length 5 in
- Connection/Terminal Type Ferrule
- Sell Pack Quantity 10 EACH
- Connection/Terminal Material Silver-Plated Copper
- Power Dissipation at Rated Current Value 10.5 W
- Mounting Clip
- Speed/Characteristic gR
- Fuse Size 20x127
- Catalogue No. FD20GB100V32
- Max. Rated Breaking Capacity DC 100kA
- Ampere Rating 32 A
- Rated voltage DC IEC 1000 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of W089489 on Advantage Electric Supply is $421.06. Order now.
About the product
W089489 Mersen - High-Speed Cylindrical Fuse Protistor® Size 20x127 gR (gRB) 1000VDC IEC 32A
Product type: Semiconductor Protection Fuses
Specially developed for DC applications, 20x127 gR cylindrical is a fast acting, full range fuse used in the protection of auxiliaries, control circuit and other measuring and monitoring devices.
*International 20x127mm (13/16" x 5") for worldwide acceptance
*gR Class according to VDE 636-23 and IEC 60269-4
*Low I²t for improved semiconductor protection
*Eliminate all overloads
*Extremely fast acting
*Current limiting
*Excellent cycling capability
