T218241 Mersen Fuse Holders
Part#:T218241
Alt. Part#:8430399002859
Manufacturer:Mersen
Category:Fuse Holders
Product Lifecycle:Active
Product description
T218241 Mersen - NH plastic base Size NH0 1000VAC 1000VDC 160A 1-Pole DIN Rail Connection Screw PP Type
Product Details
- Number of Poles 1 Pole
- Current Rating 160 A
- Weight 210.202 g
- Sell Pack Width 6.5 in
- Sell Pack Height 2.76 in
- Sell Pack Length 6.89 in
- Sell Pack Weight 1.389 lb
- Product Height 6.61 in
- Product Weight 0.463 lb
- Power Acceptance 25 W
- Sell Pack Quantity 3 EACH
- Product Length 2.4 in
- Installation Mounting DIN Rail
- Product Width 1.81 in
- Design Details Type PP (clip contacts)
- Ampere Rating 160 A
- Rated voltage AC IEC 690 V
- ROHS Compliant Yes
- Rated voltage DC IEC 440 V
- Fuse Size NH0
- Number of Poles 1-Pole
- Catalogue No. BB01PPR
- Torque Rating 88.51 lb-in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of T218241 on Advantage Electric Supply is $157.49. Order now.
About the product
T218241 Mersen - NH plastic base Size NH0 1000VAC 1000VDC 160A 1-Pole DIN Rail Connection Screw PP Type | NH fuse-bases are available for delivery in single-pole and three-pole designs and can be closely mounted in parallel rows. Each three-pole base is upplied with two phase-partition walls. NH fuse-links plugon covers which clip onto the contact springs can also be supplied for these bases.
Plastic fuse-bases sizes 00 to 3 have a single-part plastic base while size 4 has a metal baseplate with 2 ceramic bases.
The stable silver-plated contact springs are made of electrolytic copper and formed from one piece. Separate springing is provided by highly resilient captive steel springs, making the contact invulnerable to high thermal stress. Size 4 NH fuse-bases are designed for size 4 fuse-links with 8 mm contact blades.
A microswitch (250VAC/10A, terminal size 6.3x0.8mm) can be used with NH fuse-links with striker, it operates when fuse melts or where there is no fuse-link.
Indirect touch protection fuse bases: no microswitch possible.
Rated impulse withstand voltage Uimp: 6kV / 8kV (sizes 00 / 0-4) | Features: *Polyamide insulating bases
*Silver-plated contacts
*High-pressure spring contacts
*Screw or rail mounting
*Connecting cable: 50mm
*Multipolar bases possible by direct linkage in 00 size and with separator accessory in sizes 0, 1, 2 and 3
*Variety of options for protecting active parts through use of accessories: separating plates, separator, cover shields and fuse cover
*Dual cable-connection system on 00 size: by screw or clamp | Application: *For fuse-links with rated voltages up to 1000VAC and 1000VDC
