AM1648 Allied Moulded Products Electrical Enclosures
Part#:AM1648
Manufacturer:Allied Moulded Products
Product Lifecycle:Active
Get a quick Quote!
16"x14"x8" AM Series fiberglass wall mount enclosure assembly with 4-screw lift-off cover
About the manufacturer: Allied Moulded Products is one of the manufacturers that offers Electrical Enclosures that you can order at Advantage Electric Supply site. Allied Moulded offers a wide range of products for residential and manufactured housing, including fiberglass range/dryer receptacle boxes, floor boxes, lampholders, luminaires, and more. These products are designed to meet the needs of both electrical professionals and DIY enthusiasts.
Check out the AM1648 Allied Moulded Products price in the box on the right side or send a quick quote.
Product Details
- UL Standard 508A
- UL CCN NITW
- UL File No. E120175
- Width 14.4 in
- Height 16.27 in
- Depth 8 in
- NEMA Rating 4X
- Material Fiberglass
- Color Gray
- Type Wallmount
- Door Qty 1
- UNSPSC: 39121324
- Brand: AM Series
- Additional Materials: 316 stainless steel external hardware (hinges/latches/fasteners), 316 stainless steel mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
- Application: Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.
- Features: Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus stainless steel mounting brackets and a gasket system encased in a continuous chann
- Country of Origin: United States of America
- Material: ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
- Color: Gray (RAL 7035)
- Closure Type: 4-Screw Lift-Off
- Standards: UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
- UPC: 85339916482
- Carton Quantity: 1
- Carton Weight: 14 lbs
- Usable Depth: 7.68 in
- Height: 16.27 in
- Depth: 8 in
- Volume: 1905 cu. in.
- Mounting Description: Stainless steel feet fastened to back side brass inserts
- Cover Type: Opaque
- Enclosure Type: JIC Size
- Width: 14.4 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents AM1648 Specs
