25030EP3OFP449TS-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 380 V
- Output Rating 250 HP
- Rated Speed 2965 rpm
- Flange Type Without
- Output 250 HP (185 kW)
- Locked rotor time 45s (cold) 25s (hot)
- Approx. weight³ 2582 lb
- Standard NEMA MG-1
- Rated voltage 380 V
- Frequency 50 Hz
- Breakdown torque 229 %
- Enclosure IC411 - TEFC
- Rotation¹ Both (CW and CCW)
- LRC 7.2x(Code G)
- Design B
- Synchronous speed 3000 rpm
- Rated current 325 A
- Service factor 1.15
- Altitude 1000 m.a.s.l.
- Rated speed 2965 rpm
- Locked rotor torque 170 %
- Temperature rise 80 K
- Mounting F-1
- L. R. Amperes 2340 A
- Rated torque 443 ft.lb
- Ambient temperature -20°C to +40°C
- Flange Without
- No load current 73.0 A
- Voltage 380-400-415 V
- Number of Poles 2
- Duty Cycle Cont.(S1)
- Frame 447/9TS
- Insulation Class F
- Starting Method Direct On Line
- Output rating 250 HP
- Noise level² 79.0 dB(A)
- Slip 1.17 %
- Moment of inertia (J) 38.0 sq.ft.lb
- Degree of Protection IP55
- Number of poles 2
- Terminal box¹ Left position
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
