20036ET3H447TS-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 575 V
- Output Rating 200 HP
- Rated Speed 3570 rpm
- Flange Type Without
- Terminal box¹ Left position
- Voltage 575 V
- Number of poles 2
- Standard NEMA MG-1
- Flange Without
- Synchronous speed 3600 rpm
- Output rating 200 HP
- Noise level² 81.0 dB(A)
- Approx. weight³ 2041 lb
- Degree of Protection IP55
- Ambient temperature -20°C to +40°C
- Duty Cycle Cont.(S1)
- Starting Method Direct On Line
- Mounting F-1
- Temperature rise 80 K
- Service factor 1.15
- No load current 36.0 A
- Insulation Class F
- Rotation¹ Both (CW and CCW)
- Enclosure IC411 - TEFC
- Altitude 1000 m.a.s.l.
- Design B
- Rated torque 294 ft.lb
- Moment of inertia (J) 44.7 sq.ft.lb
- Locked rotor torque 210 %
- Breakdown torque 229 %
- Locked rotor time 25s (cold) 14s (hot)
- LRC 6.5x(Code G)
- Frequency 60 Hz
- Rated current 175 A
- Rated voltage 575 V
- Slip 0.83 %
- Number of Poles 2
- Output 200 HP (150 kW)
- Frame 445/7TS
- L. R. Amperes 1139 A
- Rated speed 3570 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
