15018OT3H444TSDF2-W4 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 575 V
- Output Rating 150 HP
- Rated Speed 1784 rpm
- Flange Type D
- Terminal box¹ Right position
- Flange D
- Number of poles 4
- Voltage 575 V
- Synchronous speed 1800 rpm
- Output rating 150 HP
- Mounting F-2
- Standard NEMA MG-1
- Approx. weight³ 1350 lb
- Rotation¹ Both (CW and CCW)
- Noise level² 78.0 dB(A)
- Starting Method Direct On Line
- Altitude 1000 m.a.s.l.
- Enclosure IC01 - ODP
- Duty Cycle Cont.(S1)
- Ambient temperature -20°C to +40°C
- Degree of Protection IP23
- Temperature rise 80 K
- Service factor 1.25
- Insulation Class F
- Design B
- Moment of inertia (J) 42.1 sq.ft.lb
- Locked rotor time 39s (cold) 22s (hot)
- Rated torque 442 ft.lb
- Locked rotor torque 200 %
- Breakdown torque 240 %
- No load current 46.4 A
- LRC 6.5x(Code G)
- Number of Poles 4
- Output 150 HP (110 kW)
- Frame 444/5TSD
- Frequency 60 Hz
- Rated voltage 575 V
- Rated speed 1784 rpm
- L. R. Amperes 884 A
- Slip 0.89 %
- Rated current 136 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
