15009ST3QIE447T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 460 V
- Output Rating 150 HP
- Rated Speed 890 rpm
- Flange Type Without
- Noise level² 63.0 dB(A)
- Output rating 150 HP
- Flange Without
- Number of poles 8
- Terminal box¹ Left position
- Synchronous speed 900 rpm
- Voltage 460 V
- Standard NEMA MG-1
- Approx. weight³ 2206 lb
- Mounting F-1
- Service factor 1.15
- Rotation¹ Both (CW and CCW)
- Degree of Protection IP56
- Enclosure IC411 - TEFC
- Temperature rise 80 K
- Altitude 1000 m.a.s.l.
- Ambient temperature -20°C to +40°C
- Starting Method Direct On Line
- Duty Cycle Cont.(S1)
- Rated torque 885 ft.lb
- Insulation Class F
- Design B
- No load current 75.0 A
- Moment of inertia (J) 125 sq.ft.lb
- Locked rotor time 27s (cold) 15s (hot)
- Locked rotor torque 190 %
- Breakdown torque 210 %
- LRC 6.0x(Code G)
- Frequency 60 Hz
- Rated current 185 A
- L. R. Amperes 1110 A
- Rated speed 890 rpm
- Rated voltage 460 V
- Slip 1.11 %
- Number of Poles 8
- Output 150 HP (110 kW)
- Frame 445/7T
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
