12536ET3G444TS-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 460 V
- Output Rating 125 HP
- Rated Speed 3570 rpm
- Flange Type Without
- Terminal box¹ Left position
- Output rating 125 HP
- Flange Without
- Number of poles 2
- Synchronous speed 3600 rpm
- Voltage 460 V
- Standard NEMA MG-1
- Approx. weight³ 1629 lb
- Noise level² 81.0 dB(A)
- Enclosure IC411 - TEFC
- Mounting F-1
- Degree of Protection IP55
- Rotation¹ Both (CW and CCW)
- Altitude 1000 m.a.s.l.
- Duty Cycle Cont.(S1)
- Ambient temperature -20°C to +40°C
- Design B
- Starting Method Direct On Line
- Insulation Class F
- Service factor 1.15
- Temperature rise 80 K
- Locked rotor time 52s (cold) 29s (hot)
- Moment of inertia (J) 33.5 sq.ft.lb
- Breakdown torque 250 %
- Locked rotor torque 200 %
- Rated torque 184 ft.lb
- LRC 6.6x(Code G)
- Frequency 60 Hz
- No load current 34.0 A
- Frame 444/5TS
- Rated speed 3570 rpm
- Slip 0.83 %
- L. R. Amperes 884 A
- Rated voltage 460 V
- Rated current 134 A
- Number of Poles 2
- Output 125 HP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
12536ET3G444TS-W22 Related Documents
Manufacturer warranty
12536ET3G444TS-W22 WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
About the manufacturer
Advantage Electric Supply is an authorized WEG distributor, proudly offering a comprehensive range of products from this renowned global manufacturer specializing in electric motors, automation, and energy solutions. WEG stands as a leader in innovation and quality, providing advanced solutions that cater to various industrial needs. Their diverse product portfolio includes low and medium voltage ...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
W22 NEMA Premium Efficiency 125 HP 2P 444/5TS 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted
