10009ET3E445T-W22 WEG AC Motors

10009ET3E445T-W22 on Advantage Electric Supply
WEG

Part#:10009ET3E445T-W22

Manufacturer:WEG

Category:AC Motors

Alt. Part#:7899058026376

Product Lifecycle:Active

Get a quick Quote!

W22 NEMA Premium Efficiency 100 HP 8P 444/5T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted

Check out the 10009ET3E445T-W22 WEG price in the box on the right side or send a quick quote.

Product Details

  • Number of Poles
    8 Pole
  • Voltage
    230/460 V
  • Output Rating
    100 HP
  • Rated Speed
    890 rpm
  • Flange Type
    Without
  • Output rating
    100 HP
  • Terminal box¹
    Left position
  • Synchronous speed
    900 rpm
  • Flange
    Without
  • Number of poles
    8
  • Voltage
    230/460//380 V
  • Approx. weight³
    1761 lb
  • Standard
    NEMA MG-1
  • Rotation¹
    Both (CW and CCW)
  • Noise level²
    63.0 dB(A)
  • Temperature rise
    80 K
  • Enclosure
    IC411 - TEFC
  • Mounting
    F-1
  • Degree of Protection
    IP55
  • Altitude
    1000 m.a.s.l.
  • Starting Method
    Direct On Line
  • Ambient temperature
    -20°C to +40°C
  • Duty Cycle
    Cont.(S1)
  • Service factor
    1.25
  • LRC
    6.0x(Code G)
  • Insulation Class
    F
  • Moment of inertia (J)
    87.3 sq.ft.lb
  • Locked rotor torque
    190 %
  • Locked rotor time
    27s (cold) 15s (hot)
  • Design
    B
  • Breakdown torque
    220 %
  • Rated torque
    590 ft.lb
  • No load current
    112/56.0 A
  • Rated speed
    890 rpm
  • Frame
    444/5T
  • Slip
    1.11 %
  • Frequency
    60 Hz
  • Rated current
    254/127 A
  • Rated voltage
    230/460 V
  • L. R. Amperes
    1524/762 A
  • Output
    100 HP (75 kW)
  • Number of Poles
    8

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
