03089EP3PCT324V-W22 WEG AC Motors
Product Details
- Number of Poles 45508 Pole
- Voltage 200 V
- Output Rating 7.5/30 HP
- Rated Speed 1780 rpm
- Flange Type Without
- Synchronous speed 900/1800 rpm
- Noise level² 69.0 dB(A)
- Approx. weight³ 2.2 lb
- Degree of Protection IP55
- Voltage 200 V
- Terminal box¹ Right position
- Number of poles 8/4
- Flange Without
- Standard NEMA MG-1
- Output rating 7.5/30 HP
- Rotation¹ Both (CW and CCW)
- Enclosure IC411 - TEFC
- Mounting F-2
- Altitude 1000 m.a.s.l.
- Duty Cycle Cont.(S1)
- Starting Method Direct On Line
- Temperature rise 80 K
- Service factor 1.15
- Ambient temperature -20°C to +40°C
- Locked rotor time 19s (cold) 11s (hot)
- Rated torque 88.5 ft.lb
- Insulation Class F
- Breakdown torque 280 %
- Moment of inertia (J) 7.85 sq.ft.lb
- LRC 8.1x(Code J)
- Locked rotor torque 270 %
- L. R. Amperes 693 A
- No load current 39.1 A
- Rated current 85.5 A
- Rated speed 1780 rpm
- Rated voltage 200 V
- Slip 1.11 %
- Frequency 60 Hz
- Number of Poles 8/4
- Output 30 HP (22 kW)
- Frame 324T
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
