02089EP3HCT256V-W22 WEG AC Motors
Product Details
- Number of Poles 45508 Pole
- Voltage 575 V
- Output Rating 5.0/20 HP
- Rated Speed 1770 rpm
- Flange Type Without
- Altitude 1000 m.a.s.l.
- Degree of Protection IP55
- Terminal box¹ Right position
- Locked rotor torque 270 %
- Flange Without
- Temperature rise 80 K
- Moment of inertia (J) 3.10 sq.ft.lb
- Output rating 5.0/20 HP
- Rotation¹ Both (CW and CCW)
- Mounting F-2
- Enclosure IC411 - TEFC
- Synchronous speed 900/1800 rpm
- Number of poles 8/4
- Ambient temperature -20°C to +40°C
- Voltage 575 V
- Standard NEMA MG-1
- Service factor 1.15
- Approx. weight³ 2.2 lb
- Noise level² 64.0 dB(A)
- Insulation Class F
- Starting Method Direct On Line
- Locked rotor time 14s (cold) 8s (hot)
- Breakdown torque 280 %
- Duty Cycle Cont.(S1)
- No load current 9.04 A
- Rated torque 59.3 ft.lb
- LRC 7.1x(Code J)
- Rated voltage 575 V
- Rated current 20.9 A
- Number of Poles 8/4
- Rated speed 1770 rpm
- L. R. Amperes 148 A
- Frame 254/6T
- Output 20 HP (15 kW)
- Slip 1.67 %
- Frequency 60 Hz
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
