01509ES3EOW324T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 208-230/460 V
- Output Rating 15 HP
- Rated Speed 840 rpm
- Flange Type Without
- Terminal box¹ Right position
- Standard NEMA MG-1
- Synchronous speed 900 rpm
- Output rating 15 HP
- Flange Without
- Voltage 208-230/460 V
- Starting Method Direct On Line
- Noise level² 56.0 dB(A)
- Number of poles 8
- Approx. weight³ 522 lb
- Mounting F-2
- Degree of Protection IP55
- Rotation¹ Both (CW and CCW)
- Ambient temperature -20°C to +40°C
- Temperature rise 80 K
- Altitude 1000 m.a.s.l.
- Service factor 1.15
- Enclosure IC411 - TEFC
- Duty Cycle Cont.(S1)
- Design D
- LRC 5.2x(Code G)
- Rated torque 93.8 ft.lb
- Locked rotor time 36s (cold) 20s (hot)
- Locked rotor torque 280 %
- Insulation Class F
- No load current 26.5-24.0/12.0 A
- Moment of inertia (J) 9.63 sq.ft.lb
- Breakdown torque 0 %
- Number of Poles 8
- L. R. Amperes 251-227/113 A
- Rated speed 840 rpm
- Rated current 48.2-43.6/21.8 A
- Slip 6.67 %
- Output 15 HP (11 kW)
- Rated voltage 208-230/460 V
- Frame 324/6T
- Frequency 60 Hz
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
