01089EP3QCT256V2-W22 WEG AC Motors
Product Details
- Number of Poles 45508 Pole
- Voltage 460 V
- Output Rating 2.5/10 HP
- Rated Speed 1775 rpm
- Flange Type Without
- Flange Without
- Number of poles 8/4
- Terminal box¹ Right position
- Altitude 1000 m.a.s.l.
- Noise level² 64.0 dB(A)
- Rotation¹ Both (CW and CCW)
- Locked rotor time 30s (cold) 17s (hot)
- Output rating 2.5/10 HP
- Voltage 460 V
- Synchronous speed 900/1800 rpm
- Standard NEMA MG-1
- Approx. weight³ 341 lb
- Enclosure IC411 - TEFC
- Mounting F-2
- Degree of Protection IP55
- Ambient temperature -20°C to +40°C
- Starting Method Direct On Line
- Duty Cycle Cont.(S1)
- Insulation Class F
- Locked rotor torque 220 %
- Service factor 1.15
- Moment of inertia (J) 2.96 sq.ft.lb
- Breakdown torque 290 %
- Temperature rise 80 K
- No load current 4.50 A
- Rated torque 29.6 ft.lb
- LRC 7.2x(Code H)
- Slip 1.39 %
- Frequency 60 Hz
- Frame 254/6T
- Rated speed 1775 rpm
- Rated voltage 460 V
- Number of Poles 8/4
- L. R. Amperes 88.2 A
- Output 10 HP (7.5 kW)
- Rated current 12.3 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
01089EP3QCT256V2-W22 Related Documents
Manufacturer warranty
01089EP3QCT256V2-W22 WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
About the manufacturer
Advantage Electric Supply is an authorized WEG distributor, proudly offering a comprehensive range of products from this renowned global manufacturer specializing in electric motors, automation, and energy solutions. WEG stands as a leader in innovation and quality, providing advanced solutions that cater to various industrial needs. Their diverse product portfolio includes low and medium voltage ...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
W22 Cooling Tower High Efficiency 2.5/10 HP 8/4P 254/6T 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted
