01009AT3E284T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 208-230/460 V
- Output Rating 10 HP
- Rated Speed 880 rpm
- Flange Type Without
- Terminal box¹ Left position
- Flange Without
- Output rating 10 HP
- Voltage 208-230/460//380 V
- Number of poles 8
- Synchronous speed 900 rpm
- Standard NEMA MG-1
- Approx. weight³ 0.0 lb
- Enclosure IC418 - TEAO
- Noise level² 54.0 dB(A)
- Mounting F-1
- Degree of Protection IP55
- Rotation¹ Both (CW and CCW)
- Ambient temperature -20°C to +40°C
- Altitude 1000 m.a.s.l.
- Starting Method Direct On Line
- Duty Cycle Cont.(S1)
- Temperature rise 80 K
- Design B
- Service factor 1.25
- Insulation Class F
- Moment of inertia (J) 7.20 sq.ft.lb
- Breakdown torque 240 %
- Locked rotor time 57s (cold) 32s (hot)
- Rated torque 59.7 ft.lb
- No load current 11.2-13.0/6.50 A
- Locked rotor torque 200 %
- LRC 5.6x(Code G)
- Output 10 HP (7.5 kW)
- Slip 2.22 %
- Number of Poles 8
- L. R. Amperes 166-150/75.0 A
- Frequency 60 Hz
- Rated current 29.6-26.8/13.4 A
- Rated voltage 208-230/460 V
- Rated speed 880 rpm
- Frame 284/6T
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
