00509ES3EOW256T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 208-230/460 V
- Output Rating 5 HP
- Rated Speed 825 rpm
- Flange Type Without
- Flange Without
- Terminal box¹ Right position
- Output rating 5 HP
- Number of poles 8
- Synchronous speed 900 rpm
- Voltage 208-230/460 V
- Standard NEMA MG-1
- Approx. weight³ 281 lb
- Rotation¹ Both (CW and CCW)
- Mounting F-2
- Duty Cycle Cont.(S1)
- Noise level² 54.0 dB(A)
- Enclosure IC411 - TEFC
- Altitude 1000 m.a.s.l.
- Temperature rise 80 K
- Starting Method Direct On Line
- Degree of Protection IP55
- Ambient temperature -20°C to +40°C
- Insulation Class F
- No load current 6.63-6.00/3.00 A
- Moment of inertia (J) 3.14 sq.ft.lb
- Locked rotor time 36s (cold) 20s (hot)
- Locked rotor torque 300 %
- Service factor 1.15
- Breakdown torque 0 %
- Design D
- Rated torque 31.8 ft.lb
- LRC 6.3x(Code J)
- Rated speed 825 rpm
- Output 5 HP (3.7 kW)
- Frequency 60 Hz
- Slip 8.33 %
- Rated current 16.1-14.5/7.27 A
- Rated voltage 208-230/460 V
- Frame 254/6T
- Number of Poles 8
- L. R. Amperes 101-91.6/45.8 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
