00318ES1B184JP-W22 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 115/208-230 V
- Output Rating 3 HP
- Rated Speed 1745 rpm
- Flange Type C
- Terminal box¹ Left position
- Flange C
- Number of poles 4
- Noise level² 60.0 dB(A)
- Starting Method Direct On Line
- Output rating 3 HP
- Approx. weight³ 103 lb
- Voltage 115/208-230 V
- Synchronous speed 1800 rpm
- Standard NEMA MG-1
- Altitude 1000 m.a.s.l.
- Rotation¹ Both (CW and CCW)
- Degree of Protection IP55
- Duty Cycle Cont.(S1)
- Ambient temperature -20°C to +40°C
- Mounting F-1
- Enclosure IC411 - TEFC
- Insulation Class F
- Temperature rise 80 K
- Moment of inertia (J) 0.3735 sq.ft.lb
- Rated torque 9.03 ft.lb
- Service factor 1.15 (1.00 @ 208V)
- Locked rotor time 14s (cold) 8s (hot)
- Breakdown torque 270 %
- Locked rotor torque 290 %
- No load current 18.0/7.76-9.00 A
- LRC 6.9x(Code J)
- Slip 3.06 %
- L. R. Amperes 208/108-104 A
- Frequency 60 Hz
- Rated current 30.2/15.7-15.1 A
- Number of Poles 4
- Output 3 HP (2.2 kW)
- Rated speed 1745 rpm
- Rated voltage 115/208-230 V
- Frame 182/4JP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
00318ES1B184JP-W22 Related Documents
Manufacturer warranty
00318ES1B184JP-W22 WEG
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
About the manufacturer
Advantage Electric Supply is an authorized WEG distributor, proudly offering a comprehensive range of products from this renowned global manufacturer specializing in electric motors, automation, and energy solutions. WEG stands as a leader in innovation and quality, providing advanced solutions that cater to various industrial needs. Their diverse product portfolio includes low and medium voltage ...
Recently viewed products
Relevant products
FAQ
Out if stock but available for backorder.
We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.
We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.
W22 JP Pump 3 HP 4P 182/4JP 1Ph 115/208-230 V 60 Hz IC411 - TEFC - Foot-mounted
