00236ES3E56C-S WEG AC Motors
Product Details
- Terminal box¹ Left position
- Flange C
- Output rating 2 HP
- Noise level² 68.0 dB(A)
- Voltage 230/460//190-220/380-415 V
- Standard NEMA MG-1
- Number of poles 2
- Synchronous speed 3600 rpm
- Approx. weight³ 32.4 lb
- Enclosure IC411 - TEFC
- Mounting F-1
- Rotation¹ Both (CW and CCW)
- Starting Method Direct On Line
- Altitude 1000 m.a.s.l.
- Degree of Protection IP55
- Duty Cycle Cont.(S1)
- Service factor 1.15 (1.00 @ 208V)
- Ambient temperature -20°C to +40°C
- Locked rotor torque 229 %
- Insulation Class F
- No load current 2.07/1.04 A
- Locked rotor time 19s (cold) 11s (hot)
- Rated torque 3.02 ft.lb
- Breakdown torque 290 %
- Temperature rise 80 K
- LRC 7.7x(Code K)
- Design A
- Moment of inertia (J) 0.0963 sq.ft.lb
- Rated voltage 230/460 V
- Rated current 5.24/2.62 A
- Frame 56HC
- Frequency 60 Hz
- Output 2 HP (1.5 kW)
- Rated speed 3475 rpm
- L. R. Amperes 40.3/20.2 A
- Slip 3.47 %
- Number of Poles 2
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
