00209ET3E213T-W22 WEG AC Motors
Product Details
- Number of Poles 8 Pole
- Voltage 230/460 V
- Output Rating 2 HP
- Rated Speed 875 rpm
- Flange Type Without
- Terminal box¹ Left position
- Voltage 230/460//380 V
- Starting Method Direct On Line
- Locked rotor torque 220 %
- Flange Without
- Synchronous speed 900 rpm
- Output rating 2 HP
- Number of poles 8
- Standard NEMA MG-1
- Approx. weight³ 154 lb
- Noise level² 52.0 dB(A)
- Mounting F-1
- Rotation¹ Both (CW and CCW)
- Degree of Protection IP55
- Enclosure IC411 - TEFC
- Duty Cycle Cont.(S1)
- Altitude 1000 m.a.s.l.
- Ambient temperature -20°C to +40°C
- Temperature rise 80 K
- Moment of inertia (J) 1.79 sq.ft.lb
- Insulation Class F
- Locked rotor time 70s (cold) 39s (hot)
- LRC 6.9x(Code L)
- Breakdown torque 290 %
- Rated torque 12.0 ft.lb
- Design B
- Service factor 1.25
- No load current 4.60/2.30 A
- Rated speed 875 rpm
- Rated voltage 230/460 V
- Frame 213/5T
- Rated current 6.78/3.39 A
- Number of Poles 8
- L. R. Amperes 46.8/23.4 A
- Output 2 HP (1.5 kW)
- Frequency 60 Hz
- Slip 2.78 %
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
