.2518OS1BSPB48 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 115/208-230 V
- Output Rating 0.25 HP
- Rated Speed 1735 rpm
- Flange Type Without
- Terminal box¹ Without Terminal Box
- Flange Without
- Degree of Protection IP21
- Number of poles 4
- Output rating 0.25 HP
- Standard NEMA MG-1
- Synchronous speed 1800 rpm
- Starting Method Direct On Line
- Voltage 115/208-230 V
- Approx. weight³ 17.1 lb
- Rotation¹ Both (CW and CCW)
- Service factor 1.35 (1.00 @ 208V)
- Duty Cycle Cont.(S1)
- Altitude 1000 m.a.s.l.
- Insulation Class B
- Mounting F-1
- Temperature rise 80 K
- Locked rotor time 10s (cold) 6s (hot)
- Breakdown torque 270 %
- Moment of inertia (J) 0.0320 sq.ft.lb
- Locked rotor torque 190 %
- Ambient temperature -20°C to +40°C
- Enclosure IC01 - ODP
- L. R. Amperes 32.2/15.4-16.1 A
- No load current 4.10/1.77-2.05 A
- LRC 6.7x(Code R)
- Rated current 4.80/2.30-2.40 A
- Rated torque 0.757 ft.lb
- Number of Poles 4
- Rated voltage 115/208-230 V
- Rated speed 1735 rpm
- Slip 3.61 %
- Frame B48
- Output 0.25 HP (0.18 kW)
- Frequency 60 Hz
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
