TESK-LA-11L1-3M Schmersal Safety Switches
Part#:TESK-LA-11L1-3M
Alt. Part#:103005712
Manufacturer:Schmersal
Category:Safety Switches
Product Lifecycle:Active
Product description
TESK-LA-11L1-3M Schmersal - Safety switch for hinged guards; Hinge safety switch; cable bottom; with fixed switching angle; pre-set for front mounting; long hinge part; pre-set for front mounting; Metal enclosure
Product Details
- Switching principle Creep circuit element
- Switching frequency 1,200 /h
- Switching element NO contact, NC contact
- Utilisation category AC-15 2 A
- Utilisation category DC-13 24 VDC
- Rated insulation voltage Ui 300 V
- Ambient temperature, maximum +65 °C
- Rated impulse withstand voltage Uimp 2.5 kV
- Thermal test current 2.5 A
- Width of sensor 98 mm
- Ambient temperature, minimum -25 °C
- Length of cable 3 m
- Cable section, maximum 1 mm²
- Height of sensor 116 mm
- Degree of protection IP65
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Length of sensor 20 mm
- Number of auxiliary contacts 1
- Cable section, minimum 0.5 mm²
- Number of safety contacts 1
- Terminal Connector cable
- Material of the contacts, electrical Silver-nickel alloy 10
- Alignment aid Yes
- Enclosure material Zinc die-cast
- Mechanical life, minimum 1,000,000 Operations
- Mounting outside Yes
- Colour of the housing Silver
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TESK-LA-11L1-3M on Advantage Electric Supply is $282.00. Order now.
