SDG01.3440 Schmersal Electronic Components

Switching element-

Switching principleSnap action

Utilisation category DC-136 A

Thermal test current10 A

Utilisation category AC-152.5 A

Rated insulation voltage Ui250 V

Rated impulse withstand voltage Uimp4 kV

Ambient temperature, maximum+85 °C

Ambient temperature, minimum-30 °C

Degree of protectionIP40

Length of sensor-

Height of sensor-

Width of sensor-

Terminal Connector-

Cable section, minimum-

Cable section, maximum2 x 1.5 mm²

Note (Cable section)-

Note (Positive break force)-

positive break travel-

Enclosure coating material-

Enclosure materialGlass-fibre, reinforced ther...

Positive break force, minimum-

Number of safety contacts-

Gross weight45 g

Mechanical life, minimum1,000,000 Operations

StandardsIEC/EN 60947-5-1

Material of the contacts, electricalGold-plated silver

Depth-

Height-

Width-

Cable entry-

Mounting-

Actuating stroke-

Suitable for elevators-

Actuating panels-

Actuating force, approx.-

Switchover time, maximum5 ms

Bounce duration, maximum3 ms

Switching frequency10,000 /h

Degree of pollution to VDE 01003

Degree of protection of clips or terminalsIP00 (without connector)

Repeat accuracy of switching points0.02

Actuating speed, minimum1 mm/min

Actuating speed1 mm/min

Number of openers1

Number of shutters1

Contact opening> 2 x 1.25 mm

Actuating force12 N

Terminal (mechanical)Screw connection

Material of the actuatorThermoplastic

Switching elementOpener (NC)

Switching principleCreep circuit element

Utilisation category DC-135 A

Thermal test current10 A

Utilisation category AC-158 A

Rated insulation voltage Ui400 V

Rated impulse withstand voltage Uimp2.5 kV

Ambient temperature, maximum+70 °C

Ambient temperature, minimum-25 °C

Degree of protectionIP67 to EN 60529

Length of sensor43 mm

Height of sensor152 mm

Width of sensor50 mm

Terminal ConnectorScrew connection

Cable section, minimum0.5 mm²

Cable section, maximum2.5 mm²

Note (Cable section)All indications about the ca...

Note (Positive break force)per NC

positive break travel14 mm, 15.5 mm

Enclosure coating materialpainted

Enclosure materialAluminium

Positive break force, minimum5 N

Number of safety contacts3

Gross weight400 g

Mechanical life, minimum1,000,000 Operations

StandardsEN 60947-5-1, EN ISO 14119, ...

Material of the contacts, electricalSilver

Depth-

Height-

Width-

Cable entry-

Mounting-

Actuating stroke-

Suitable for elevators-

Actuating panels-

Actuating force, approx.-

Switchover time, maximum-

Bounce duration, maximum-

Switching frequency-

Degree of pollution to VDE 0100-

Degree of protection of clips or terminals-

Repeat accuracy of switching points-

Actuating speed, minimum-

Actuating speed-

Number of openers-

Number of shutters-

Contact opening-

Actuating force-

Terminal (mechanical)-

Material of the actuator-

Switching elementOpener (NC)

Switching principleSelf-cleaning pressure conta...

Utilisation category DC-13200 VDC

Thermal test current4 A

Utilisation category AC-15230 VAC

Rated insulation voltage Ui500 V

Rated impulse withstand voltage Uimp-

Ambient temperature, maximum+80 °C

Ambient temperature, minimum-30 °C

Degree of protectionIP20 to DIN VDE 0470-1, IP20...

Length of sensor-

Height of sensor-

Width of sensor-

Terminal ConnectorScrew terminals M 3

Cable section, minimum0.75 mm²

Cable section, maximum2.5 mm²

Note (Cable section)All indications about the ca...

Note (Positive break force)-

positive break travel-

Enclosure coating material-

Enclosure materialPlastic, glass-fibre reinfor...

Positive break force, minimum-

Number of safety contacts1

Gross weight27 g

Mechanical life, minimum1,000,000 Operations

StandardsEN 81

Material of the contacts, electricalSilver-plated Cu rivets

Depth21.5 mm

Height27 mm

Width73.5 mm

Cable entrySingle conductor version wit...

MountingEnclosure with mounting slot...

Actuating stroke5 mm

Suitable for elevatorsYes

Actuating panels1

Actuating force, approx.2 N

Switchover time, maximum-

Bounce duration, maximum-

Switching frequency-

Degree of pollution to VDE 0100-

Degree of protection of clips or terminals-

Repeat accuracy of switching points-

Actuating speed, minimum-

Actuating speed-

Number of openers-

Number of shutters-

Contact opening-

Actuating force-

Terminal (mechanical)-

Material of the actuator-

Switching element-

Switching principleSnap action

Utilisation category DC-136 A

Thermal test current10 A

Utilisation category AC-152.5 A

Rated insulation voltage Ui250 V

Rated impulse withstand voltage Uimp4 kV

Ambient temperature, maximum+85 °C

Ambient temperature, minimum-30 °C

Degree of protectionIP40

Length of sensor-

Height of sensor-

Width of sensor-

Terminal Connector-

Cable section, minimum-

Cable section, maximum2 x 1.5 mm²

Note (Cable section)-

Note (Positive break force)-

positive break travel-

Enclosure coating material-

Enclosure materialGlass-fibre, reinforced ther...

Positive break force, minimum-

Number of safety contacts-

Gross weight45 g

Mechanical life, minimum1,000,000 Operations

StandardsIEC/EN 60947-5-1

Material of the contacts, electricalGold-plated silver

Depth-

Height-

Width-

Cable entry-

Mounting-

Actuating stroke-

Suitable for elevators-

Actuating panels-

Actuating force, approx.-

Switchover time, maximum5 ms

Bounce duration, maximum3 ms

Switching frequency10,000 /h

Degree of pollution to VDE 01003

Degree of protection of clips or terminalsIP00 (without connector)

Repeat accuracy of switching points0.02

Actuating speed, minimum1 mm/min

Actuating speed1 mm/min

Number of openers1

Number of shutters1

Contact opening> 2 x 1.25 mm

Actuating force12 N

Terminal (mechanical)Screw connection

Material of the actuatorThermoplastic

Switching elementOpener (NC)

Switching principleCreep circuit element

Utilisation category DC-135 A

Thermal test current10 A

Utilisation category AC-158 A

Rated insulation voltage Ui400 V

Rated impulse withstand voltage Uimp2.5 kV

Ambient temperature, maximum+70 °C

Ambient temperature, minimum-25 °C

Degree of protectionIP67 to EN 60529

Length of sensor43 mm

Height of sensor152 mm

Width of sensor50 mm

Terminal ConnectorScrew connection

Cable section, minimum0.5 mm²

Cable section, maximum2.5 mm²

Note (Cable section)All indications about the ca...

Note (Positive break force)per NC

positive break travel14 mm, 15.5 mm

Enclosure coating materialpainted

Enclosure materialAluminium

Positive break force, minimum5 N

Number of safety contacts3

Gross weight400 g

Mechanical life, minimum1,000,000 Operations

StandardsEN 60947-5-1, EN ISO 14119, ...

Material of the contacts, electricalSilver

Depth-

Height-

Width-

Cable entry-

Mounting-

Actuating stroke-

Suitable for elevators-

Actuating panels-

Actuating force, approx.-

Switchover time, maximum-

Bounce duration, maximum-

Switching frequency-

Degree of pollution to VDE 0100-

Degree of protection of clips or terminals-

Repeat accuracy of switching points-

Actuating speed, minimum-

Actuating speed-

Number of openers-

Number of shutters-

Contact opening-

Actuating force-

Terminal (mechanical)-

Material of the actuator-
