PS116-Z11R-LR200-S200 Schmersal Electronic Components
Part#:PS116-Z11R-LR200-S200
Alt. Part#:103006582
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Position switch; PS116; Pre-wired cable right, 2; Snap action 1 Normally open contact (NO) / 1 Opener (NC); with latching; Thermoplastic enclosure; Symmetric enclosure; Protection class IP66, IP67
Product Details
- Switchover time, maximum 5.5 ms
- Bounce duration, maximum 3 ms
- Switching frequency 5,000 /h
- Utilisation category DC-13 1.5 A
- Switching principle Snap action with latch
- Utilisation category AC-15 3 A
- Switching element NO contact, NC contact
- Ambient temperature, minimum -30 °C
- Rated insulation voltage Ui 300 V
- Required rated short-circuit current to EN 60947-5-1 1,000 A
- Thermal test current 5 A
- Rated impulse withstand voltage Uimp 4 kV
- Degree of protection IP66, IP67
- Positive break force, minimum 40 N
- Width of sensor 31 mm
- Height of sensor 64 mm
- Ambient temperature, maximum +80 °C
- Cable type LiYY
- Length of cable 2 m
- Length of sensor 16.6 mm
- Wire cross-section 0.5 mm2
- Actuating element plunger S200
- Mechanical life, minimum 10,000,000 Operations
- Actuating force, minimum 10 N
- Actuating speed, minimum 10 mm/min
- Actuating speed, maximum 0.5 m/s
- Terminal Connector Cable, 4-pole
- Material of the contacts, electrical Silver
- Actuator type to DIN EN 50047 B
- Number of safety contacts 1
- Safety functions Yes
- Enclosure material Plastic, glass-fibre reinforced thermoplastic, zinc die-cast, chromated
- Housing construction form Norm construction design
- Number of auxiliary contacts 1
- Standards IEC 60947-5-1
- Terminal (mechanical) right
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
