NHSNH63 Schmersal Disconnect Switches
Part#:NHSNH63
Alt. Part#:101184919
Manufacturer:Schmersal
Category:Disconnect Switches
Product Lifecycle:Active
Product description
NHSNH63 Schmersal - Main Switch from N Series (IP69K)
Product Details
- Switching capacity, AC-23 22,000 W
- Switching capacity, AC-3 22,000 W
- Rated operating voltage 690 V
- Thermal test current 63 A
- Ambient temperature, maximum +80 °C
- Degree of protection IP67, IP69K
- Ambient temperature, minimum +0 °C
- Thickness, of the front panel, minimum 1.5 mm
- Thickness of the front panel, maximum 6 mm
- Diameter hole, with tolerance indication 22.3 + 0.4 mm
- Length of the handle 52 mm
- Diameter hole 22.3 mm
- Diameter of the knob 39 mm
- Diameter of the front ring 44.5 mm
- Length x Width x Height Grid dimensions: 110 mm x 110 mm, Dimensions of the mounting plate: 110 mm x 110 mm
- Mounting depth 85 mm
- Height 29 mm
- Width 48 mm
- Length 48 mm
- Tightening torque of the screw 0.6 Nm
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Cable section, minimum 4 mm², rigid, 2.5 mm², flexible
- Terminal Connector Screw connection
- Cable section, maximum 16 mm², rigid, 10 mm², flexible
- Mounting mounting flange
- switching angle 90 °
- Mechanical life, minimum 1,000,000 Operations
- Unlocking Rotating unlatcher
- Latching Yes
- Number of switch positions 2
- Fully insulated Yes
- Gross weight 700 g
- Colour of the handle Red
- Colour of the front ring Silver
- Colour of the mounting plate Silver
- Colour of the bracket Silver
- Colour of the identification plate Yellow
- Standards IEC 60947
- Material of the front ring ABS, chrome-plated
- Material of the operators ABS
- Material of the bracket Stainless steel (V4A)
- Material of the mounting plate Stainless steel (V4A)
- Sealing type Membrane, Lip gaskets
- Versions Toggle, Main switch - Front plate mounting
- Material of the identification label Stainless steel (V4A)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of NHSNH63 on Advantage Electric Supply is $374.00. Order now.
