BN 325-R-1279 Schmersal Electronic Components
Part#:BN 325-R-1279
Alt. Part#:101147091
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Magnetic reed switch; Cable output left and 2 shielding plates; Actuation from front; Non-contact principle; 1 Reed contakts; Long life; Actuating surface and direction of actuation marked by switch symbol; 85 mm x 26 mm x 24 mm; Thermoplastic enclosure;
Product Details
- Switching capacity, maximum 120 VA
- Ambient temperature, minimum -25 °C
- Switch distance Sn 5 mm … 55 mm, 2 x BP 21S = 20 ... 55 mm, BP 34S = 10 ... 25 mm
- Mechanical life, minimum 1,000,000,000 Operations
- Versions Reed contacts
- Switching frequency, maximum 300 Hz
- Bounce duration, maximum 0.6 ms
- Switching element bistable contact
- Bounce duration, minimum 0.3 ms
- Switching current, maximum 3 A
- Resistance to vibrations to EN 60068-2-6 10 … 55 Hz, amplitude 1 mm
- Switching voltage, maximum 250 VAC
- Restistance to shock 50 g / 11 ms
- Ambient temperature, maximum +70 °C
- Width of sensor 85 mm
- Height of sensor 26 mm
- Degree of protection IP67
- Length of cable 1 m
- Terminal Connector Cable outlet left and 2 shielding plates
- Length of sensor 24 mm
- Number of snap-in contacts 1
- Notice (Switch distance Sn) Actuating distance up to 55 mm depending on actuating magnet and version. The specified switching distances are applicable for the actuation of individually mounted components without ferromagnetic influence. A change of the distance, either positive or n
- Repeat accuracy R R 0.3 mm
- Actuating speed, maximum 18 m/s
- Enclosure material Glass-fibre, reinforced thermoplastic
- Latching Yes
- Mounting rear with 2 threaded bolts
- Actuating panels front side
- Gross weight 98 g
- Actuating element Magnet
- Suitable for elevators Yes
- Housing construction form rectangular
- Active principle Magnetic drive
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
