AZM300B-I2-ST-AS-A-P Schmersal Safety Switches
Part#:AZM300B-I2-ST-AS-A-P
Alt. Part#:103005904
Manufacturer:Schmersal
Category:Safety Switches
Product Lifecycle:Active
Product description
AZM300B-I2-ST-AS-A-P Schmersal - Electronic Solenoid Interlock with AS-I
Product Details
- Note (AS-i Input module address) Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
- Rated operating voltage 24 VDC -15% / +10% (stabilised PELV)
- Operating current 300 mA
- AS-i Input module address 0
- Note (AS-i Parameter bits) Set the parameter outputs to "1111" (0xF), FID: periphery error
- AS-i Parameter bits, P2 Auxiliary voltage in
- AS-i Parameter bits, P3 Internal device error (FID)
- AS-i Parameter bits, P1 Solenoid interlock locked
- AS-i Outputs, DO 1 No Function
- AS-i Outputs, DO 3 No Function
- AS-i Outputs, DO 0 Solenoid control
- AS-i Parameter bits, P0 Safety guard closed and can be locked
- AS-i Outputs, DO 2 No Function
- AS-i Input, Channel 1 Data bits DI 0 / DI 1 = dynamic code transmission
- Note (AS-i Operating voltage) Protection against polarity reversal
- AS-i Input, Channel 2 Data bits DI 2 / DI 3 = dynamic code transmission
- AS-i Profile S-7.B.F.E
- AS-i Current consumption, maximum 100 mA
- AS-i Specification Safety-Slave
- AS-i Operating voltage, minimum 18 VDC
- AS-i Version V 3.0
- AS-i Operating voltage AS-i maximum 31.6 VDC
- Degree of pollution to VDE 0100 3
- Protection rating II
- Overvoltage category III
- Rated insulation voltage Ui 32 VDC
- Rated impulse withstand voltage Uimp 0.8 kV
- Resistance to vibrations to EN 60068-2-6 10 … 150 Hz, amplitude 0.35 mm
- Storage and transport temperature, maximum +90 °C
- Restistance to shock 30 g / 11 ms
- Storage and transport temperature, minimum -10 °C
- Ambient temperature, maximum +60 °C
- Ambient temperature, minimum +0 °C
- Height of sensor 102.6 mm
- Degree of protection IP66 to EN 60529, IP67 to EN 60529, IP69K to DIN 40050-9
- Length of sensor 34.4 mm
- Width of sensor 87.4 mm
- Switch distance 2 mm
- Terminal Connector Connector plug M12, 4-pole, (A-coding)
- Ensured switch distance OFF Sar 20 mm
- Ensured switch distance ON Sao 1 mm
- Latching force, adjustable, position 2 50 N
- Integral System Diagnostics, status Yes
- Latching force, adjustable, position 1 25 N
- Mechanical life, minimum 1,000,000 Operations
- Clamping force 1,150 N
- Note (Mechanical lifetime) When using as door stop: ≥ 50.000 operations (door mass ≤ 5 kg and actuating speed ≤ 0.5 m/s)
- Number of actuating directions 3
- Safety functions Yes
- Latching Yes
- Manual release Yes
- Actuator monitored Yes
- Duration of risk, maximum 200 ms
- Power to lock Yes
- Time to readiness, maximum 5,000 ms
- Gross weight 595 g
- Coding level according to ISO 14119 High
- Reaction time, maximum 120 ms
- Enclosure material Glass-fibre, reinforced thermoplastic
- Standards IEC 61508, EN 60947-5-1, EN ISO 14119
- Active principle RFID
- general information Individual coding, multiple teaching
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of AZM300B-I2-ST-AS-A-P on Advantage Electric Supply is $956.00. Order now.
