AZM 200 B SK-T-1P2PWA Schmersal Safety Switch Interlocks
Part#:AZM 200 B SK-T-1P2PWA
Alt. Part#:101195441
Manufacturer:Schmersal
Category:Safety Switch Interlocks
Product Lifecycle:Active
Product description
Solenoid interlock; Actuator monitored; Thermoplastic enclosure; Electronic contact-free, coded system; Max. length of the sensor chain 200 m; Self-monitoring series-wiring; 3 LEDs to show operating conditions; Sensor technology permits an offset between
Product Details
- Voltage drop Ud, maximum 4 V
- Current, Utilisation category DC13 0.05 A
- Switching frequency, approx. 1 Hz
- Protection rating II
- Ambient temperature, minimum -25 °C
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Mechanical life, minimum 1,000,000 Operations
- Power to lock Yes
- Voltage, Utilisation category DC13 24 VDC
- Current leakage Ir 0.5 mA
- Rated operating current (safety outputs) 250 mA
- Operating current 50 mA
- Switching thresholds -3 V … 5 V (Low), 15 V … 30 V (High)
- No-load supply current I0 600 mA
- Operating voltage, maximum 26.4 VDC
- Degree of pollution to VDE 0100 3
- Overvoltage category III
- Operating voltage, minimum 20.4 VDC
- Rated impulse withstand voltage Uimp 0.8 kV
- Rated insulation voltage Ui 32 VDC
- Restistance to shock 30 g / 11 ms
- Resistance to vibrations to EN 60068-2-6 10 … 55 Hz, amplitude 1 mm
- Note (Relative humidity) non-condensing
- Relative humidity, maximum 95 %
- Ambient temperature, maximum +50 °C
- Storage and transport temperature, maximum +85 °C
- Relative humidity, minimum 30 %
- Storage and transport temperature, minimum -25 °C
- Degree of protection IP67 to EN 60529
- Height of sensor 220 mm
- Width of sensor 40 mm
- Length of sensor 50 mm
- Wire cross-section, maximum 15 AWG
- Cable section, maximum 1.5 mm²
- Wire cross-section, minimum 23 AWG
- Cable section, minimum 0.25 mm²
- Terminal Connector Screw connection
- Actuating speed, maximum 0.2 m/s
- Clamping force, maximum Fmax 2,600 N
- Latching force 30 N
- Clamping force in accordance with ISO14119 Fzh 2,000 N
- Series-wiring Yes
- Number of safety contacts 2
- Integral System Diagnostics, status Yes
- Safety functions Yes
- Short circuit detection Yes
- Short-circuit recognition Yes
- Standards IEC 61508, EN 60947-5-1, EN ISO 13849-1
- Duration of risk, maximum 120 ms
- Manual release Yes
- Gross weight 550 g
- Actuator monitored Yes
- Active principle inductive
- Reaction time, maximum 60 ms
- Time to readiness, maximum 4,000 ms
- Enclosure material Glass-fibre, reinforced thermoplastic
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
